Definitions of the GIOP specific stuff. More...
#include <GIOP_Message_Base.h>
Definitions of the GIOP specific stuff.
This class will hold the specific details common to all the GIOP versions. Some of them which are here may be shifted if things start changing between versions.
Definition at line 51 of file GIOP_Message_Base.h.
| TAO_GIOP_Message_Base::TAO_GIOP_Message_Base | ( | TAO_ORB_Core * | orb_core, | |
| TAO_Transport * | transport, | |||
| size_t | input_cdr_size = ACE_CDR::DEFAULT_BUFSIZE | |||
| ) |
Constructor.
Definition at line 29 of file GIOP_Message_Base.cpp.
: orb_core_ (orb_core) , fragmentation_strategy_ (orb_core->fragmentation_strategy (transport)) , out_stream_ (0, input_cdr_size, TAO_ENCAP_BYTE_ORDER, orb_core->output_cdr_buffer_allocator (), orb_core->output_cdr_dblock_allocator (), orb_core->output_cdr_msgblock_allocator (), orb_core->orb_params ()->cdr_memcpy_tradeoff (), fragmentation_strategy_.get (), TAO_DEF_GIOP_MAJOR, TAO_DEF_GIOP_MINOR) { #if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1) const int nibbles = 2 * sizeof (size_t); char hex_string[nibbles + 1]; ACE_OS::sprintf (hex_string, "%8.8X", transport->id ()); hex_string[nibbles] = '\0'; ACE_CString monitor_name ("OutputCDR_"); monitor_name += hex_string; this->out_stream_.register_monitor (monitor_name.c_str ()); #endif /* TAO_HAS_MONITOR_POINTS==1 */ }
| TAO_GIOP_Message_Base::~TAO_GIOP_Message_Base | ( | void | ) |
Dtor.
Definition at line 59 of file GIOP_Message_Base.cpp.
{
#if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1)
this->out_stream_.unregister_monitor ();
#endif /* TAO_HAS_MONITOR_POINTS==1 */
}
| int TAO_GIOP_Message_Base::consolidate_fragmented_message | ( | TAO_Queued_Data * | qd, | |
| TAO_Queued_Data *& | msg | |||
| ) |
Consolidate fragmented message with associated fragments, being stored withi this class. If reliable transport is used (like TCP) fragments are partialy ordered on stack, last fragment on top. Otherwise If un-reliable transport is used (like UDP) fragments may be dis-ordered, and must be ordered before consolidation.
Definition at line 1794 of file GIOP_Message_Base.cpp.
{
TAO::Incoming_Message_Stack reverse_stack;
TAO_Queued_Data *tail = 0;
TAO_Queued_Data *head = 0;
//
// CONSOLIDATE FRAGMENTED MESSAGE
//
// check for error-condition
if (qd == 0)
{
return -1;
}
if (qd->giop_version ().major == 1 && qd->giop_version ().minor == 0)
{
TAO_Queued_Data::release (qd);
return -1; // error: GIOP-1.0 does not support fragments
}
// If this is not the last fragment, push it onto stack for later processing
if (qd->more_fragments ())
{
this->fragment_stack_.push (qd);
msg = 0; // no consolidated message available yet
return 1; // status: more messages expected.
}
tail = qd; // init
// Add the current message block to the end of the chain
// after adjusting the read pointer to skip the header(s)
size_t const header_adjustment =
this->header_length () +
this->fragment_header_length (tail->giop_version ().major_version ());
if (tail->msg_block ()->length () < header_adjustment)
{
// buffer length not sufficient
TAO_Queued_Data::release (qd);
return -1;
}
// duplicate code to speed up both processes, for GIOP-1.1 and GIOP-1.2
if (tail->giop_version ().major_version () == 1 && tail->giop_version ().minor_version () == 1)
{
// GIOP-1.1
while (this->fragment_stack_.pop (head) != -1)
{
if (head->more_fragments () &&
head->giop_version ().major_version () == 1 &&
head->giop_version ().minor_version () == 1 &&
head->msg_block ()->length () >= header_adjustment)
{
// adjust the read-pointer, skip the fragment header
tail->msg_block ()->rd_ptr(header_adjustment);
head->msg_block ()->cont (tail->msg_block ());
tail->msg_block (0);
TAO_Queued_Data::release (tail);
tail = head;
}
else
{
reverse_stack.push (head);
}
}
}
else
{
// > GIOP-1.2
CORBA::ULong tmp_request_id = 0;
if (this->parse_request_id (tail, tmp_request_id) == -1)
{
return -1;
}
CORBA::ULong const request_id = tmp_request_id;
while (this->fragment_stack_.pop (head) != -1)
{
CORBA::ULong head_request_id = 0;
int parse_status = 0;
if (head->more_fragments () &&
head->giop_version ().major_version () >= 1 &&
head->giop_version ().minor_version () >= 2 &&
head->msg_block ()->length () >= header_adjustment &&
(parse_status = this->parse_request_id (head, head_request_id)) != -1 &&
request_id == head_request_id)
{
// adjust the read-pointer, skip the fragment header
tail->msg_block ()->rd_ptr(header_adjustment);
head->msg_block ()->cont (tail->msg_block ());
tail->msg_block (0);
TAO_Queued_Data::release (tail);
tail = head;
}
else
{
if (parse_status == -1)
{
TAO_Queued_Data::release (head);
return -1;
}
reverse_stack.push (head);
}
}
}
// restore stack
while (reverse_stack.pop (head) != -1)
{
this->fragment_stack_.push (head);
}
if (tail->consolidate () == -1)
{
// memory allocation failed
TAO_Queued_Data::release (tail);
return -1;
}
// set out value
msg = tail;
return 0;
}
| int TAO_GIOP_Message_Base::consolidate_node | ( | TAO_Queued_Data * | qd, | |
| ACE_Message_Block & | incoming | |||
| ) |
Check whether the node qd needs consolidation from incoming.
Definition at line 470 of file GIOP_Message_Base.cpp.
{
// Look to see whether we had atleast parsed the GIOP header ...
if (qd->missing_data () == TAO_MISSING_DATA_UNDEFINED)
{
// The data length that has been stuck in there during the last
// read ....
size_t const len = qd->msg_block ()->length ();
// paranoid check
if (len >= TAO_GIOP_MESSAGE_HEADER_LEN)
{
// inconsistency - this code should have parsed the header
// so far
return -1;
}
// We know that we would have space for
// TAO_GIOP_MESSAGE_HEADER_LEN here. So copy that much of data
// from the <incoming> into the message block in <qd>
size_t const available = incoming.length ();
size_t const desired = TAO_GIOP_MESSAGE_HEADER_LEN - len;
size_t const n_copy = ace_min (available, desired);
// paranoid check, but would cause endless looping
if (n_copy == 0)
{
return -1;
}
if (qd->msg_block ()->copy (incoming.rd_ptr (), n_copy) == -1)
{
return -1;
}
// Move the rd_ptr () in the incoming message block..
incoming.rd_ptr (n_copy);
// verify sufficient data to parse GIOP header
if (qd->msg_block ()->length () < TAO_GIOP_MESSAGE_HEADER_LEN)
{
return 0; /* continue */
}
TAO_GIOP_Message_State state;
// Parse the message header now...
if (state.parse_message_header (*qd->msg_block ()) == -1)
{
if (TAO_debug_level > 0)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - TAO_GIOP_Message_Base::consolidate_node, ")
ACE_TEXT ("error parsing header\n") ));
}
return -1;
}
// Now grow the message block so that we can copy the rest of
// the data, the message_block must be able to hold complete message
if (ACE_CDR::grow (qd->msg_block (),
state.message_size ()) == -1) /* GIOP_Header + Payload */
{
// on mem-error get rid of context silently, try to avoid
// system calls that might allocate additional memory
return -1;
}
// Copy the pay load..
// Calculate the bytes that needs to be copied in the queue...
size_t copy_len = state.payload_size ();
// If the data that needs to be copied is more than that is
// available to us ..
if (copy_len > incoming.length ())
{
// Calculate the missing data..
qd->missing_data (copy_len - incoming.length ());
// Set the actual possible copy_len that is available...
copy_len = incoming.length ();
}
else
{
qd->missing_data (0);
}
// ..now we are set to copy the right amount of data to the
// node..
if (qd->msg_block ()->copy (incoming.rd_ptr (), copy_len) == -1)
{
return -1;
}
// Set the <rd_ptr> of the <incoming>..
incoming.rd_ptr (copy_len);
// Get the other details...
qd->state (state);
}
else
{
// @todo: Need to abstract this out to a seperate method...
size_t copy_len = qd->missing_data ();
if (copy_len > incoming.length ())
{
// Calculate the missing data..
qd->missing_data (copy_len - incoming.length ());
// Set the actual possible copy_len that is available...
copy_len = incoming.length ();
}
// paranoid check for endless-event-looping
if (copy_len == 0)
{
return -1;
}
// Copy the right amount of data in to the node...
if (qd->msg_block ()->copy (incoming.rd_ptr (), copy_len) == -1)
{
return -1;
}
// Set the <rd_ptr> of the <incoming>..
qd->msg_block ()->rd_ptr (copy_len);
}
return 0;
}
| int TAO_GIOP_Message_Base::discard_fragmented_message | ( | const TAO_Queued_Data * | cancel_request | ) |
Discard all fragments associated to request-id encoded in cancel_request. This operation will never be called concurrently by multiplpe threads nor concurrently to consolidate_fragmented_message
Definition at line 1941 of file GIOP_Message_Base.cpp.
{
// We must extract the specific request-id from message-buffer
// and remove all fragments from stack that match this request-id.
TAO::Incoming_Message_Stack reverse_stack;
CORBA::ULong cancel_request_id;
if (this->parse_request_id (cancel_request, cancel_request_id) == -1)
{
return -1;
}
TAO_Queued_Data *head = 0;
// Revert stack
while (this->fragment_stack_.pop (head) != -1)
{
reverse_stack.push (head);
}
bool discard_all_GIOP11_messages = false;
// Now we are able to process message in order they have arrived.
// If the cancel_request_id matches to GIOP-1.1 message, all succeeding
// fragments belong to this message and must be discarded.
// Note: GIOP-1.1 fragment header dont have any request-id encoded. If the
// cancel_request_id matches GIOP-1.2 messages, all GIOP-1.2 fragments
// having encoded the request id will be discarded.
while (reverse_stack.pop (head) != -1)
{
CORBA::ULong head_request_id;
if (head->giop_version ().major_version () == 1 &&
head->giop_version ().minor_version () <= 1 &&
head->msg_type () != GIOP::Fragment && // GIOP11 fragment does not provide request id
this->parse_request_id (head, head_request_id) >= 0 &&
cancel_request_id == head_request_id)
{
TAO_Queued_Data::release (head);
discard_all_GIOP11_messages = true;
}
else if (head->giop_version ().major_version () == 1 &&
head->giop_version ().minor_version () <= 1 &&
discard_all_GIOP11_messages)
{
TAO_Queued_Data::release (head);
}
else if (head->giop_version ().major_version () >= 1 &&
head->giop_version ().minor_version () >= 2 &&
this->parse_request_id (head, head_request_id) >= 0 &&
cancel_request_id == head_request_id)
{
TAO_Queued_Data::release (head);
}
else
{
this->fragment_stack_.push (head);
}
}
return 0;
}
| int TAO_GIOP_Message_Base::dump_consolidated_msg | ( | TAO_OutputCDR & | stream | ) | [private] |
Print out consolidate messages.
Definition at line 240 of file GIOP_Message_Base.cpp.
{
// Check whether the output cdr stream is build up of multiple
// messageblocks. If so, consolidate them to one block that can be
// dumped
ACE_Message_Block* consolidated_block = 0;
char *buf = const_cast <char*> (stream.buffer ());
size_t const total_len = stream.total_length ();
if (stream.begin()->cont () != 0)
{
ACE_NEW_RETURN (consolidated_block, ACE_Message_Block, 0);
ACE_CDR::consolidate (consolidated_block, stream.begin ());
buf = (char *) (consolidated_block->rd_ptr ());
}
this->dump_msg ("send", reinterpret_cast <u_char *> (buf), total_len);
delete consolidated_block;
consolidated_block = 0;
return 0;
}
| void TAO_GIOP_Message_Base::dump_msg | ( | const char * | label, | |
| const u_char * | ptr, | |||
| size_t | len | |||
| ) | [private] |
Print out a debug messages..
Definition at line 1505 of file GIOP_Message_Base.cpp.
{
if (TAO_debug_level < 10)
{
return;
}
static const char digits[] = "0123456789ABCD";
static const char *names[] =
{
"Request",
"Reply",
"CancelRequest",
"LocateRequest",
"LocateReply",
"CloseConnection",
"MessageError",
"Fragment"
};
// Message name.
const char *message_name = "UNKNOWN MESSAGE";
u_long slot = ptr[TAO_GIOP_MESSAGE_TYPE_OFFSET];
if (slot < sizeof (names) / sizeof (names[0]))
message_name = names[slot];
// Byte order.
int const byte_order = ptr[TAO_GIOP_MESSAGE_FLAGS_OFFSET] & 0x01;
// Get the version info
CORBA::Octet const major = ptr[TAO_GIOP_VERSION_MAJOR_OFFSET];
CORBA::Octet const minor = ptr[TAO_GIOP_VERSION_MINOR_OFFSET];
// request/reply id.
CORBA::ULong tmp = 0;
CORBA::ULong *id = &tmp;
char *tmp_id = 0;
if (ptr[TAO_GIOP_MESSAGE_TYPE_OFFSET] == GIOP::Request ||
ptr[TAO_GIOP_MESSAGE_TYPE_OFFSET] == GIOP::Reply ||
ptr[TAO_GIOP_MESSAGE_TYPE_OFFSET] == GIOP::Fragment)
{
if (major == 1 && minor < 2)
{
// @@ Only works if ServiceContextList is empty....
tmp_id = (char * ) (ptr + TAO_GIOP_MESSAGE_HEADER_LEN + 4);
}
else
{
tmp_id = (char * ) (ptr + TAO_GIOP_MESSAGE_HEADER_LEN);
}
#if !defined (ACE_DISABLE_SWAP_ON_READ)
if (byte_order == TAO_ENCAP_BYTE_ORDER)
{
id = reinterpret_cast <ACE_CDR::ULong*> (tmp_id);
}
else
{
ACE_CDR::swap_4 (tmp_id, reinterpret_cast <char*> (id));
}
#else
id = reinterpret_cast <ACE_CDR::ULong*> (tmp_id);
#endif /* ACE_DISABLE_SWAP_ON_READ */
}
else if (ptr[TAO_GIOP_MESSAGE_TYPE_OFFSET] == GIOP::CancelRequest ||
ptr[TAO_GIOP_MESSAGE_TYPE_OFFSET] == GIOP::LocateRequest ||
ptr[TAO_GIOP_MESSAGE_TYPE_OFFSET] == GIOP::LocateReply)
{
tmp_id = (char * ) (ptr + TAO_GIOP_MESSAGE_HEADER_LEN);
#if !defined (ACE_DISABLE_SWAP_ON_READ)
if (byte_order == TAO_ENCAP_BYTE_ORDER)
{
id = reinterpret_cast <ACE_CDR::ULong*> (tmp_id);
}
else
{
ACE_CDR::swap_4 (tmp_id, reinterpret_cast <char*> (id));
}
#else
id = reinterpret_cast <ACE_CDR::ULong*> (tmp_id);
#endif /* ACE_DISABLE_SWAP_ON_READ */
}
// Print.
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT("TAO (%P|%t) - GIOP_Message_Base::dump_msg, ")
ACE_TEXT("%C GIOP message v%c.%c, %d data bytes, %s endian, ")
ACE_TEXT("Type %C[%u]\n"),
label,
digits[ptr[TAO_GIOP_VERSION_MAJOR_OFFSET]],
digits[ptr[TAO_GIOP_VERSION_MINOR_OFFSET]],
len - TAO_GIOP_MESSAGE_HEADER_LEN ,
(byte_order == TAO_ENCAP_BYTE_ORDER) ? ACE_TEXT("my") : ACE_TEXT("other"),
message_name,
*id));
ACE_HEX_DUMP ((LM_DEBUG,
(const char *) ptr,
len,
ACE_TEXT ("GIOP message")));
}
| int TAO_GIOP_Message_Base::extract_next_message | ( | ACE_Message_Block & | incoming, | |
| TAO_Queued_Data *& | qd | |||
| ) |
Extract the details of the next message from the incoming through qd. Returns 0 if the message header could not be parsed completely, returns a 1 if the message header could be parsed completely and returns -1 on error.
Definition at line 382 of file GIOP_Message_Base.cpp.
{
if (incoming.length () < TAO_GIOP_MESSAGE_HEADER_LEN)
{
if (incoming.length () > 0)
{
// Optimize memory usage, we dont know actual message size
// so far, but allocate enough space to hold small GIOP
// messages. This way we avoid expensive "grow" operation
// for small messages.
size_t const default_buf_size = ACE_CDR::DEFAULT_BUFSIZE;
// Make a node which has at least message block of the size
// of MESSAGE_HEADER_LEN.
size_t const buf_size = ace_max (TAO_GIOP_MESSAGE_HEADER_LEN,
default_buf_size);
// POST: buf_size >= TAO_GIOP_MESSAGE_HEADER_LEN
qd = this->make_queued_data (buf_size);
if (qd == 0)
{
if (TAO_debug_level > 0)
{
ACE_ERROR((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - TAO_GIOP_Message_Base::extract_next_message, ")
ACE_TEXT ("out of memory\n")));
}
return -1;
}
qd->msg_block ()->copy (incoming.rd_ptr (), incoming.length ());
incoming.rd_ptr (incoming.length ()); // consume all available data
qd->missing_data (TAO_MISSING_DATA_UNDEFINED);
}
else
{
// handle not initialized variables
qd = 0; // reset
}
return 0;
}
TAO_GIOP_Message_State state;
if (state.parse_message_header (incoming) == -1)
{
return -1;
}
size_t copying_len = state.message_size ();
qd = this->make_queued_data (copying_len);
if (qd == 0)
{
if (TAO_debug_level > 0)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - TAO_GIOP_Message_Base::extract_next_message, ")
ACE_TEXT ("out of memory\n")));
}
return -1;
}
if (copying_len > incoming.length ())
{
qd->missing_data (copying_len - incoming.length ());
copying_len = incoming.length ();
}
else
{
qd->missing_data (0);
}
qd->msg_block ()->copy (incoming.rd_ptr (), copying_len);
incoming.rd_ptr (copying_len);
qd->state (state);
return 1;
}
| int TAO_GIOP_Message_Base::format_message | ( | TAO_OutputCDR & | cdr, | |
| TAO_Stub * | stub | |||
| ) |
Format the message. As we have not written the message length in the header, we make use of this oppurtunity to insert and format the message.
Definition at line 264 of file GIOP_Message_Base.cpp.
{
this->set_giop_flags (stream);
bool log_msg = TAO_debug_level > 9;
#if defined (TAO_HAS_ZIOP) && TAO_HAS_ZIOP ==1
TAO_ZIOP_Adapter* ziop_adapter = this->orb_core_->ziop_adapter ();
// Ziop adapter found and not compressed yet
if (ziop_adapter)
{
if (TAO_debug_level > 9)
{
this->dump_consolidated_msg (stream);
}
bool compressed;
if (stub)
{
compressed = ziop_adapter->marshal_data (stream, *stub);
}
else
{
compressed = ziop_adapter->marshal_data (stream, *this->orb_core_);
}
if (TAO_debug_level > 9)
{
if (!compressed)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - ")
ACE_TEXT ("TAO_GIOP_Message_Base::format_message, ")
ACE_TEXT ("GIOP message not compressed\n")));
// no need to log. If compressed->ZIOP library dumps message
// if not compressed (due to failure or policy settings)
// message hasn't changed and was allready dumped
// prior to compression...
log_msg = false;
}
}
#else
ACE_UNUSED_ARG (stub);
#endif
// Length of all buffers.
size_t const total_len = stream.total_length ();
// NOTE: Here would also be a fine place to calculate a digital
// signature for the message and place it into a preallocated slot
// in the "ServiceContext". Similarly, this is a good spot to
// encrypt messages (or just the message bodies) if that's needed in
// this particular environment and that isn't handled by the
// networking infrastructure (e.g., IPSEC).
char *buf = const_cast <char*> (stream.buffer ());
CORBA::ULong bodylen = static_cast <CORBA::ULong>
(total_len - TAO_GIOP_MESSAGE_HEADER_LEN);
#if !defined (ACE_ENABLE_SWAP_ON_WRITE)
*(reinterpret_cast <CORBA::ULong *> (buf +
TAO_GIOP_MESSAGE_SIZE_OFFSET)) = bodylen;
#else
if (!stream.do_byte_swap ())
*(reinterpret_cast <CORBA::ULong *>
(buf + TAO_GIOP_MESSAGE_SIZE_OFFSET)) = bodylen;
else
ACE_CDR::swap_4 (reinterpret_cast <char *> (&bodylen),
buf + TAO_GIOP_MESSAGE_SIZE_OFFSET);
#endif /* ACE_ENABLE_SWAP_ON_WRITE */
if (log_msg)
{
this->dump_consolidated_msg (stream);
}
return 0;
}
| size_t TAO_GIOP_Message_Base::fragment_header_length | ( | const TAO_GIOP_Message_Version & | giop_version | ) | const |
The header length of a fragment.
Definition at line 1676 of file GIOP_Message_Base.cpp.
{
// Get the parser we need to use
TAO_GIOP_Message_Generator_Parser *generator_parser =
this->get_parser (giop_version);
return generator_parser->fragment_header_length ();
}
| TAO_GIOP_Fragmentation_Strategy * TAO_GIOP_Message_Base::fragmentation_strategy | ( | void | ) |
Outgoing GIOP message fragmentation strategy.
Definition at line 2007 of file GIOP_Message_Base.cpp.
{
return this->fragmentation_strategy_.get ();
}
| int TAO_GIOP_Message_Base::generate_exception_reply | ( | TAO_OutputCDR & | cdr, | |
| TAO_Pluggable_Reply_Params_Base & | params, | |||
| const CORBA::Exception & | x | |||
| ) |
Generate a reply message with the exception ex.
Definition at line 864 of file GIOP_Message_Base.cpp.
{
// A new try/catch block, but if something goes wrong now we have no
// hope, just abort.
try
{
// Make the GIOP & reply header.
this->generate_reply_header (cdr, params);
x._tao_encode (cdr);
}
catch (const ::CORBA::BAD_PARAM&)
{
throw;
}
catch (const ::CORBA::Exception&)
{
// Now we know that while handling the error an other error
// happened -> no hope, close connection.
// Close the handle.
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("(%P|%t|%N|%l) cannot marshal exception, ")
ACE_TEXT ("generate_exception_reply ()\n")));
return -1;
}
return 0;
}
| int TAO_GIOP_Message_Base::generate_fragment_header | ( | TAO_OutputCDR & | cdr, | |
| CORBA::ULong | request_id | |||
| ) |
Definition at line 208 of file GIOP_Message_Base.cpp.
{
TAO_GIOP_Message_Version giop_version;
cdr.get_version (giop_version);
// GIOP fragments are supported in GIOP 1.1 and better, but TAO only
// supports them in 1.2 or better since GIOP 1.1 fragments do not
// have a fragment message header.
if (giop_version.major == 1 && giop_version.minor < 2)
return -1;
// Get the parser we need to use
TAO_GIOP_Message_Generator_Parser *generator_parser =
this->get_parser (giop_version);
// Write the GIOP header first
if (!this->write_protocol_header (GIOP::Fragment, giop_version, cdr)
|| !generator_parser->write_fragment_header (cdr, request_id))
{
if (TAO_debug_level)
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("(%P|%t) Error in writing GIOP header\n")));
return -1;
}
return 0;
}
| int TAO_GIOP_Message_Base::generate_locate_reply_header | ( | TAO_OutputCDR & | cdr, | |
| TAO_Pluggable_Reply_Params_Base & | params | |||
| ) | [private] |
| int TAO_GIOP_Message_Base::generate_locate_request_header | ( | TAO_Operation_Details & | op, | |
| TAO_Target_Specification & | spec, | |||
| TAO_OutputCDR & | cdr | |||
| ) |
Write the RequestHeader in to the cdr stream.
Definition at line 120 of file GIOP_Message_Base.cpp.
{
TAO_GIOP_Message_Version giop_version;
cdr.get_version (giop_version);
// Get the parser we need to use
TAO_GIOP_Message_Generator_Parser *generator_parser =
this->get_parser (giop_version);
// Write the GIOP header first
if (!this->write_protocol_header (GIOP::LocateRequest, giop_version, cdr))
{
if (TAO_debug_level)
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("(%P|%t) Error in writing GIOP header\n")));
return -1;
}
// Now call the implementation for the rest of the header
if (!generator_parser->write_locate_request_header
(op.request_id (), spec, cdr))
{
if (TAO_debug_level)
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("(%P|%t) Error in writing locate request header\n")));
return -1;
}
return 0;
}
| int TAO_GIOP_Message_Base::generate_reply_header | ( | TAO_OutputCDR & | cdr, | |
| TAO_Pluggable_Reply_Params_Base & | params | |||
| ) |
Write the reply header.
Definition at line 160 of file GIOP_Message_Base.cpp.
{
TAO_GIOP_Message_Version giop_version;
cdr.get_version (giop_version);
// Write the GIOP header first
if (!this->write_protocol_header (GIOP::Reply, giop_version, cdr))
{
if (TAO_debug_level)
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("(%P|%t) Error in writing GIOP header\n")));
return -1;
}
try
{
// Get the parser we need to use
TAO_GIOP_Message_Generator_Parser *generator_parser =
this->get_parser (giop_version);
// Now call the implementation for the rest of the header
if (!generator_parser->write_reply_header (cdr, params))
{
if (TAO_debug_level > 4)
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("(%P|%t) Error in writing reply ")
ACE_TEXT ("header\n")));
return -1;
}
}
catch (const ::CORBA::Exception& ex)
{
if (TAO_debug_level > 4)
ex._tao_print_exception (
ACE_TEXT ("TAO_GIOP_Message_Base::generate_reply_header"));
return -1;
}
return 0;
}
| int TAO_GIOP_Message_Base::generate_request_header | ( | TAO_Operation_Details & | op, | |
| TAO_Target_Specification & | spec, | |||
| TAO_OutputCDR & | cdr | |||
| ) |
Write the RequestHeader in to the cdr stream. The underlying implementation of the mesaging should do the right thing.
Definition at line 80 of file GIOP_Message_Base.cpp.
{
// Get a parser for us
TAO_GIOP_Message_Version giop_version;
cdr.get_version (giop_version);
// Write the GIOP header first
if (!this->write_protocol_header (GIOP::Request, giop_version, cdr))
{
if (TAO_debug_level)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("(%P|%t) Error in writing GIOP header\n")));
}
return -1;
}
// Get the parser we need to use
TAO_GIOP_Message_Generator_Parser *generator_parser =
this->get_parser (giop_version);
// Now call the implementation for the rest of the header
if (!generator_parser->write_request_header (op, spec, cdr))
{
if (TAO_debug_level)
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("(%P|%t) Error in writing request header\n")));
return -1;
}
return 0;
}
| TAO_GIOP_Message_Generator_Parser * TAO_GIOP_Message_Base::get_parser | ( | const TAO_GIOP_Message_Version & | version | ) | const [private] |
Get the parser.
Definition at line 1355 of file GIOP_Message_Base.cpp.
{
switch (version.major)
{
case 1:
switch (version.minor)
{
case 0:
return
const_cast<TAO_GIOP_Message_Generator_Parser_10 *> (
&this->tao_giop_impl_.tao_giop_10);
break;
case 1:
return
const_cast<TAO_GIOP_Message_Generator_Parser_11 *> (
&this->tao_giop_impl_.tao_giop_11);
break;
case 2:
return
const_cast<TAO_GIOP_Message_Generator_Parser_12 *> (
&this->tao_giop_impl_.tao_giop_12);
break;
default:
throw ::CORBA::INTERNAL (0, CORBA::COMPLETED_NO);
break;
}
break;
default:
throw ::CORBA::INTERNAL (0, CORBA::COMPLETED_NO);
break;
}
}
| size_t TAO_GIOP_Message_Base::header_length | ( | void | ) | const |
Header length.
Definition at line 1670 of file GIOP_Message_Base.cpp.
{
return TAO_GIOP_MESSAGE_HEADER_LEN;
}
| void TAO_GIOP_Message_Base::init | ( | CORBA::Octet | major, | |
| CORBA::Octet | minor | |||
| ) |
Initialize the underlying state object based on the major and minor revision numbers
Definition at line 67 of file GIOP_Message_Base.cpp.
{
// Set the giop version of the out stream
this->out_stream_.set_version (major, minor);
}
| bool TAO_GIOP_Message_Base::is_ready_for_bidirectional | ( | TAO_OutputCDR & | msg | ) | const |
Is the messaging object ready for processing BiDirectional request/response?
Definition at line 1618 of file GIOP_Message_Base.cpp.
{
TAO_GIOP_Message_Version giop_version;
msg.get_version (giop_version);
// Get the parser we need to use
TAO_GIOP_Message_Generator_Parser *generator_parser =
this->get_parser (giop_version);
// We dont really know.. So ask the generator and parser objects that
// we know.
// @@ TODO: Need to make this faster, instead of making virtual
// call, try todo the check within this class
return generator_parser->is_ready_for_bidirectional ();
}
| TAO_Queued_Data * TAO_GIOP_Message_Base::make_queued_data | ( | size_t | sz | ) | [private] |
Creates a new node for the queue with a message block in the node of size sz.
Definition at line 1637 of file GIOP_Message_Base.cpp.
{
// Make a datablock for the size requested + something. The
// "something" is required because we are going to align the data
// block in the message block. During alignment we could loose some
// bytes. As we may not know how many bytes will be lost, we will
// allocate ACE_CDR::MAX_ALIGNMENT extra.
ACE_Data_Block *db =
this->orb_core_->create_input_cdr_data_block (sz +
ACE_CDR::MAX_ALIGNMENT);
TAO_Queued_Data *qd =
TAO_Queued_Data::make_queued_data (
this->orb_core_->transport_message_buffer_allocator (),
this->orb_core_->input_cdr_msgblock_allocator (),
db);
if (qd == 0)
{
if (TAO_debug_level > 0)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - TAO_GIOP_Message_Base::make_queued_data, ")
ACE_TEXT ("out of memory, failed to allocate queued data object\n")));
}
db->release ();
return 0; // NULL pointer
}
return qd;
}
| int TAO_GIOP_Message_Base::make_send_locate_reply | ( | TAO_Transport * | transport, | |
| TAO_GIOP_Locate_Request_Header & | request, | |||
| TAO_GIOP_Locate_Status_Msg & | status, | |||
| TAO_OutputCDR & | output, | |||
| TAO_GIOP_Message_Generator_Parser * | parser | |||
| ) | [private] |
Make a GIOP_LOCATEREPLY and hand that over to the transport so that it can be sent over the connection.
Definition at line 1260 of file GIOP_Message_Base.cpp.
{
TAO_GIOP_Message_Version giop_version;
output.get_version (giop_version);
// Note here we are making the Locate reply header which is *QUITE*
// different from the reply header made by the make_reply () call..
// Make the GIOP message header
this->write_protocol_header (GIOP::LocateReply, giop_version, output);
// This writes the header & body
parser->write_locate_reply_mesg (output,
request.request_id (),
status_info);
output.more_fragments (false);
// Send the message
int const result = transport->send_message (output,
0,
TAO_REPLY);
// Print out message if there is an error
if (result == -1)
{
if (TAO_debug_level > 0)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO: (%P|%t) %p: cannot send reply\n"),
ACE_TEXT ("TAO_GIOP_Message_Base::make_send_locate_reply")));
}
}
return result;
}
| TAO_OutputCDR & TAO_GIOP_Message_Base::out_stream | ( | void | ) |
Definition at line 74 of file GIOP_Message_Base.cpp.
{
return this->out_stream_;
}
| int TAO_GIOP_Message_Base::parse_next_message | ( | TAO_Queued_Data & | qd, | |
| size_t & | mesg_length | |||
| ) |
Parse the details of the next message from the incoming and initializes attributes of qd.
| 0 | If the message header could not be parsed completely, | |
| 1 | If the message header could be parsed completely | |
| -1 | On error. |
Definition at line 344 of file GIOP_Message_Base.cpp.
{
if (qd.msg_block ()->length () < TAO_GIOP_MESSAGE_HEADER_LEN)
{
qd.missing_data (TAO_MISSING_DATA_UNDEFINED);
return 0; /* incomplete header */
}
else
{
TAO_GIOP_Message_State state;
if (state.parse_message_header (*(qd.msg_block ())) == -1)
{
return -1;
}
size_t const message_size = state.message_size (); /* Header + Payload */
if (message_size > qd.msg_block ()->length ())
{
qd.missing_data (message_size - qd.msg_block ()->length ());
}
else
{
qd.missing_data (0);
}
/* init out-parameters */
qd.state (state);
mesg_length = message_size;
return 1; /* complete header */
}
}
| int TAO_GIOP_Message_Base::parse_request_id | ( | const TAO_Queued_Data * | qd, | |
| CORBA::ULong & | request_id | |||
| ) | const [private] |
Parse GIOP request-id of TAO_Queued_Data qd
Definition at line 1687 of file GIOP_Message_Base.cpp.
{
// Get the read and write positions before we steal data.
size_t rd_pos = qd->msg_block ()->rd_ptr () - qd->msg_block ()->base ();
size_t wr_pos = qd->msg_block ()->wr_ptr () - qd->msg_block ()->base ();
rd_pos += TAO_GIOP_MESSAGE_HEADER_LEN;
// Create a input CDR stream. We do the following
// 1 - If the incoming message block has a data block with a flag
// DONT_DELETE (for the data block) we create an input CDR
// stream the same way.
// 2 - If the incoming message block had a datablock from heap just
// use it by duplicating it and make the flag 0.
// NOTE: We use the same data block in which we read the message and
// we pass it on to the higher layers of the ORB. So we dont to any
// copies at all here. The same is also done in the higher layers.
ACE_Message_Block::Message_Flags flg = 0;
ACE_Data_Block *db = 0;
// Get the flag in the message block
flg = qd->msg_block ()->self_flags ();
if (ACE_BIT_ENABLED (flg, ACE_Message_Block::DONT_DELETE))
{
// Use the same datablock
db = qd->msg_block ()->data_block ();
}
else
{
// Use a duplicated datablock as the datablock has come off the
// heap.
db = qd->msg_block ()->data_block ()->duplicate ();
}
TAO_InputCDR input_cdr (db,
flg,
rd_pos,
wr_pos,
qd->byte_order (),
qd->giop_version ().major_version (),
qd->giop_version ().minor_version (),
this->orb_core_);
if (qd->giop_version ().major == 1 &&
(qd->giop_version ().minor == 0 || qd->giop_version ().minor == 1))
{
switch (qd->msg_type ())
{
case GIOP::Request:
case GIOP::Reply:
{
IOP::ServiceContextList service_context;
if ((input_cdr >> service_context)
&& (input_cdr >> request_id))
{
return 0;
}
}
break;
case GIOP::CancelRequest:
case GIOP::LocateRequest:
case GIOP::LocateReply:
{
if ((input_cdr >> request_id))
{
return 0;
}
}
break;
default:
break;
}
}
else
{
switch (qd->msg_type ())
{
case GIOP::Request:
case GIOP::Reply:
case GIOP::Fragment:
case GIOP::CancelRequest:
case GIOP::LocateRequest:
case GIOP::LocateReply:
{
// Dealing with GIOP-1.2, the request-id is located directly
// behind the GIOP-Header. This is true for all message
// types that might be sent in form of fragments or
// cancel-requests.
if ((input_cdr >> request_id))
{
return 0;
}
}
break;
default:
break;
}
}
return -1;
}
| int TAO_GIOP_Message_Base::parse_request_id | ( | const TAO_InputCDR & | cdr, | |
| CORBA::ULong & | request_id | |||
| ) | const [private] |
Parse GIOP request-id of TAO_InputCDR cdr.
| int TAO_GIOP_Message_Base::process_locate_request | ( | TAO_Transport * | transport, | |
| TAO_InputCDR & | input, | |||
| TAO_OutputCDR & | output, | |||
| TAO_GIOP_Message_Generator_Parser * | parser | |||
| ) | [private] |
Processes the GIOP_LOCATE_REQUEST messages.
Definition at line 1145 of file GIOP_Message_Base.cpp.
{
// This will extract the request header, set <response_required> as
// appropriate.
TAO_GIOP_Locate_Request_Header locate_request (input, this->orb_core_);
TAO_GIOP_Locate_Status_Msg status_info;
// Defaulting.
status_info.status = GIOP::UNKNOWN_OBJECT;
CORBA::Boolean response_required = true;
try
{
int parse_error = parser->parse_locate_header (locate_request);
if (parse_error != 0)
{
throw ::CORBA::MARSHAL (0, CORBA::COMPLETED_NO);
}
TAO::ObjectKey tmp_key (locate_request.object_key ().length (),
locate_request.object_key ().length (),
locate_request.object_key ().get_buffer (),
0);
// Set it to an error state
parse_error = 1;
CORBA::ULong req_id = locate_request.request_id ();
// We will send the reply. The ServerRequest class need not send
// the reply
CORBA::Boolean deferred_reply = true;
TAO_ServerRequest server_request (this,
req_id,
response_required,
deferred_reply,
tmp_key,
"_non_existent",
output,
transport,
this->orb_core_,
parse_error);
if (parse_error != 0)
{
throw ::CORBA::MARSHAL (0, CORBA::COMPLETED_NO);
}
CORBA::Object_var forward_to;
this->orb_core_->request_dispatcher ()->dispatch (
this->orb_core_,
server_request,
forward_to);
if (server_request.is_forwarded ())
{
status_info.status = GIOP::OBJECT_FORWARD;
status_info.forward_location_var = forward_to;
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - TAO_GIOP_Message_Base::process_locate_request, ")
ACE_TEXT ("called: forwarding\n")));
}
else if (server_request.reply_status () == GIOP::NO_EXCEPTION)
{
// We got no exception, so the object is here.
status_info.status = GIOP::OBJECT_HERE;
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - TAO_GIOP_Message_Base::process_locate_request, ")
ACE_TEXT ("found\n")));
}
else
{
// Normal exception, so the object is not here
status_info.status = GIOP::UNKNOWN_OBJECT;
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - TAO_GIOP_Message_Base::process_locate_request, ")
ACE_TEXT ("not here\n")));
}
}
catch (const ::CORBA::Exception&)
{
// Normal exception, so the object is not here
status_info.status = GIOP::UNKNOWN_OBJECT;
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - TAO_GIOP_Message_Base::process_locate_request, ")
ACE_TEXT ("CORBA exception raised\n")));
}
catch (...)
{
// Normal exception, so the object is not here
status_info.status = GIOP::UNKNOWN_OBJECT;
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) TAO_GIOP_Message_Base::process_locate_request - ")
ACE_TEXT ("C++ exception raised\n")));
}
return this->make_send_locate_reply (transport,
locate_request,
status_info,
output,
parser);
}
| int TAO_GIOP_Message_Base::process_reply_message | ( | TAO_Pluggable_Reply_Params & | reply_info, | |
| TAO_Queued_Data * | qd | |||
| ) |
Parse the reply message that we received and return the reply information through reply_info
Definition at line 763 of file GIOP_Message_Base.cpp.
{
// Get the parser we need to use
TAO_GIOP_Message_Generator_Parser *generator_parser =
this->get_parser (qd->giop_version ());
// Get the read and write positions before we steal data.
size_t rd_pos = qd->msg_block ()->rd_ptr () - qd->msg_block ()->base ();
size_t wr_pos = qd->msg_block ()->wr_ptr () - qd->msg_block ()->base ();
rd_pos += TAO_GIOP_MESSAGE_HEADER_LEN;
ACE_Data_Block *db = 0;
// Get the flag in the message block
ACE_Message_Block::Message_Flags flg = qd->msg_block ()->self_flags ();
if (ACE_BIT_ENABLED (flg, ACE_Message_Block::DONT_DELETE))
{
// Use the same datablock
db = qd->msg_block ()->data_block ();
}
else
{
// Use a duplicated datablock as the datablock has come off the
// heap.
db = qd->msg_block ()->data_block ()->duplicate ();
}
db->size (qd->msg_block ()->length ());
#if defined (TAO_HAS_ZIOP) && TAO_HAS_ZIOP ==1
if (qd->state ().compressed ())
{
if (!this->decompress (&db, *qd, rd_pos, wr_pos))
return -1;
}
#endif
if (TAO_debug_level > 9)
{
this->dump_msg ("recv",
reinterpret_cast <u_char *> (db->base () + rd_pos - TAO_GIOP_MESSAGE_HEADER_LEN),
db->size () + rd_pos - TAO_GIOP_MESSAGE_HEADER_LEN);
}
// Create a empty buffer on stack
// NOTE: We use the same data block in which we read the message and
// we pass it on to the higher layers of the ORB. So we dont to any
// copies at all here.
TAO_InputCDR input_cdr (db,
db->flags (),
rd_pos,
wr_pos,
qd->byte_order (),
qd->giop_version ().major_version (),
qd->giop_version ().minor_version (),
this->orb_core_);
// We know we have some reply message. Check whether it is a
// GIOP_REPLY or GIOP_LOCATE_REPLY to take action.
// Once we send the InputCDR stream we need to just forget about
// the stream and never touch that again for anything. We basically
// loose ownership of the data_block.
int retval = 0;
switch (qd->msg_type ())
{
case GIOP::Reply:
// Should be taken care by the state specific parsing
retval = generator_parser->parse_reply (input_cdr, params);
break;
case GIOP::LocateReply:
retval = generator_parser->parse_locate_reply (input_cdr, params);
break;
default:
retval = -1;
}
if (retval == -1)
return retval;
params.input_cdr_ = &input_cdr;
params.transport_->assign_translators (params.input_cdr_, 0);
retval = params.transport_->tms ()->dispatch_reply (params);
if (retval == -1)
{
// Something really critical happened, we will forget about
// every reply on this connection.
if (TAO_debug_level > 0)
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - GIOP_Message_Base[%d]::process_reply_message, ")
ACE_TEXT ("dispatch reply failed\n"),
params.transport_->id ()));
}
return retval;
}
| int TAO_GIOP_Message_Base::process_request | ( | TAO_Transport * | transport, | |
| TAO_InputCDR & | input, | |||
| TAO_OutputCDR & | output, | |||
| TAO_GIOP_Message_Generator_Parser * | parser | |||
| ) | [private] |
Processes the GIOP_REQUEST messages.
Definition at line 936 of file GIOP_Message_Base.cpp.
{
// This will extract the request header, set <response_required>
// and <sync_with_server> as appropriate.
TAO_ServerRequest request (this,
cdr,
output,
transport,
this->orb_core_);
CORBA::ULong request_id = 0;
CORBA::Boolean response_required = false;
try
{
int const parse_error = parser->parse_request_header (request);
// Throw an exception if the
if (parse_error != 0)
throw ::CORBA::MARSHAL (0, CORBA::COMPLETED_NO);
TAO_Codeset_Manager *csm = request.orb_core ()->codeset_manager ();
if (csm)
{
csm->process_service_context (request);
transport->assign_translators (&cdr, &output);
}
request_id = request.request_id ();
response_required = request.response_expected ();
CORBA::Object_var forward_to;
/*
* Hook to specialize request processing within TAO
* This hook will be replaced by specialized request
* processing implementation.
*/
//@@ TAO_DISPATCH_RESOLUTION_OPT_COMMENT_HOOK_START
// Do this before the reply is sent.
this->orb_core_->request_dispatcher ()->dispatch (
this->orb_core_,
request,
forward_to);
//@@ TAO_DISPATCH_RESOLUTION_OPT_COMMENT_HOOK_END
if (request.is_forwarded ())
{
CORBA::Boolean const permanent_forward_condition =
this->orb_core_->is_permanent_forward_condition
(forward_to.in (),
request.request_service_context ());
// We should forward to another object...
TAO_Pluggable_Reply_Params_Base reply_params;
reply_params.request_id_ = request_id;
reply_params.reply_status (
permanent_forward_condition
? GIOP::LOCATION_FORWARD_PERM
: GIOP::LOCATION_FORWARD);
reply_params.svc_ctx_.length (0);
// Send back the reply service context.
reply_params.service_context_notowned (
&request.reply_service_info ());
output.message_attributes (request_id,
0,
TAO_REPLY,
0);
// Make the GIOP header and Reply header
this->generate_reply_header (output, reply_params);
if (!(output << forward_to.in ()))
{
if (TAO_debug_level > 0)
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) ERROR: Unable to marshal ")
ACE_TEXT ("forward reference.\n")));
return -1;
}
output.more_fragments (false);
int const result = transport->send_message (output,
0,
TAO_REPLY);
if (result == -1)
{
if (TAO_debug_level > 0)
{
// No exception but some kind of error, yet a
// response is required.
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO: (%P|%t|%N|%l) %p: ")
ACE_TEXT ("cannot send reply\n"),
ACE_TEXT ("TAO_GIOP_Message_Base::process_request")));
}
}
return result;
}
}
// Only CORBA exceptions are caught here.
catch ( ::CORBA::Exception& ex)
{
int result = 0;
if (response_required)
{
result = this->send_reply_exception (transport,
output,
request_id,
&request.reply_service_info (),
&ex);
if (result == -1)
{
if (TAO_debug_level > 0)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO: (%P|%t|%N|%l) %p: ")
ACE_TEXT ("cannot send exception\n"),
ACE_TEXT ("process_connector_request ()")));
ex._tao_print_exception (
"TAO_GIOP_Message_Base::process_request[1]");
}
}
}
else if (TAO_debug_level > 0)
{
// It is unfortunate that an exception (probably a system
// exception) was thrown by the upcall code (even by the
// user) when the client was not expecting a response.
// However, in this case, we cannot close the connection
// down, since it really isn't the client's fault.
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("(%P|%t) exception thrown ")
ACE_TEXT ("but client is not waiting a response\n")));
ex._tao_print_exception (
"TAO_GIOP_Message_Base::process_request[2]");
}
return result;
}
catch (...)
{
// @@ TODO some c++ exception or another, but what do we do with
// it?
// We are supposed to map it into a CORBA::UNKNOWN exception.
// BTW, this cannot be detected if using the <env> mapping. If
// we have native exceptions but no support for them in the ORB
// we should still be able to catch it. If we don't have native
// exceptions it couldn't have been raised in the first place!
int result = 0;
if (response_required)
{
CORBA::UNKNOWN exception (CORBA::SystemException::_tao_minor_code
(TAO_UNHANDLED_SERVER_CXX_EXCEPTION, 0),
CORBA::COMPLETED_MAYBE);
if (this->send_reply_exception (transport,
output,
request_id,
&request.reply_service_info (),
&exception) == -1
&& TAO_debug_level > 0)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - TAO_GIOP_Message_Base::process_request[3], ")
ACE_TEXT ("%p: ")
ACE_TEXT ("cannot send exception\n"),
ACE_TEXT ("process_request ()")));
exception._tao_print_exception (
"TAO_GIOP_Message_Base::process_request[3]");
}
}
else if (TAO_debug_level > 0)
{
// It is unfotunate that an exception (probably a system
// exception) was thrown by the upcall code (even by the
// user) when the client was not expecting a response.
// However, in this case, we cannot close the connection
// down, since it really isn't the client's fault.
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) exception thrown ")
ACE_TEXT ("but client is not waiting a response\n")));
}
return result;
}
return 0;
}
| int TAO_GIOP_Message_Base::process_request_message | ( | TAO_Transport * | transport, | |
| TAO_Queued_Data * | qd | |||
| ) |
Process the request message that we have received on the connection
Definition at line 605 of file GIOP_Message_Base.cpp.
{
// Set the upcall thread
this->orb_core_->lf_strategy ().set_upcall_thread (this->orb_core_->leader_follower ());
// Get the parser we need to use
TAO_GIOP_Message_Generator_Parser *generator_parser =
this->get_parser (qd->giop_version ());
// A buffer that we will use to initialise the CDR stream. Since we're
// allocating the buffer on the stack, we may as well allocate the data
// block on the stack too and avoid an allocation inside the message
// block of the CDR.
#if defined (ACE_INITIALIZE_MEMORY_BEFORE_USE)
char repbuf[ACE_CDR::DEFAULT_BUFSIZE] = { 0 };
#else
char repbuf[ACE_CDR::DEFAULT_BUFSIZE];
#endif /* ACE_INITIALIZE_MEMORY_BEFORE_USE */
ACE_Data_Block out_db (sizeof (repbuf),
ACE_Message_Block::MB_DATA,
repbuf,
this->orb_core_->input_cdr_buffer_allocator (),
0,
ACE_Message_Block::DONT_DELETE,
this->orb_core_->input_cdr_dblock_allocator ());
// Initialize an output CDR on the stack
// NOTE: Don't jump to a conclusion as to why we are using the
// input_cdr and hence the global pool here. These pools will move
// to the lanes anyway at some point of time. Further, it would have
// been awesome to have this in TSS. But for some reason the cloning
// that happens when the ORB gets flow controlled while writing a
// reply is messing things up. We crash horribly. Doing this adds a
// lock, we need to set things like this -- put stuff in TSS here
// and transfer to global memory when we get flow controlled. We
// need to work on the message block to get it right!
TAO_OutputCDR output (&out_db,
TAO_ENCAP_BYTE_ORDER,
this->orb_core_->input_cdr_msgblock_allocator (),
this->orb_core_->orb_params ()->cdr_memcpy_tradeoff (),
this->fragmentation_strategy_.get (),
qd->giop_version ().major_version (),
qd->giop_version ().minor_version ());
// Get the read and write positions and header before we steal data.
size_t rd_pos = qd->msg_block ()->rd_ptr () - qd->msg_block ()->base ();
size_t wr_pos = qd->msg_block ()->wr_ptr () - qd->msg_block ()->base ();
rd_pos += TAO_GIOP_MESSAGE_HEADER_LEN;
// Create a input CDR stream. We do the following
// 1 - If the incoming message block has a data block with a flag
// DONT_DELETE (for the data block) we create an input CDR
// stream the same way.
// 2 - If the incoming message block had a datablock from heap just
// use it by duplicating it and make the flag 0.
// NOTE: We use the same data block in which we read the message and
// we pass it on to the higher layers of the ORB. So we dont to any
// copies at all here. The same is also done in the higher layers.
ACE_Data_Block *db = 0;
// Get the flag in the message block
ACE_Message_Block::Message_Flags flg = qd->msg_block ()->self_flags ();
if (ACE_BIT_ENABLED (flg, ACE_Message_Block::DONT_DELETE))
{
// Use the same datablock
db = qd->msg_block ()->data_block ();
}
else
{
// Use a duplicated datablock as the datablock has come off the
// heap.
db = qd->msg_block ()->data_block ()->duplicate ();
}
db->size (qd->msg_block ()->length ());
#if defined (TAO_HAS_ZIOP) && TAO_HAS_ZIOP ==1
if (qd->state ().compressed ())
{
if (!this->decompress (&db, *qd, rd_pos, wr_pos))
return -1;
}
#endif
if (TAO_debug_level > 9)
{ //due to alignment data block has an offset which needs to be corrected
this->dump_msg ("recv",
reinterpret_cast <u_char *> (db->base () + rd_pos - TAO_GIOP_MESSAGE_HEADER_LEN),
db->size () + rd_pos - TAO_GIOP_MESSAGE_HEADER_LEN);
}
TAO_InputCDR input_cdr (db,
db->flags (),
rd_pos,
wr_pos,
qd->byte_order (),
qd->giop_version ().major_version (),
qd->giop_version ().minor_version (),
this->orb_core_);
transport->assign_translators(&input_cdr,&output);
// We know we have some request message. Check whether it is a
// GIOP_REQUEST or GIOP_LOCATE_REQUEST to take action.
// Once we send the InputCDR stream we need to just forget about
// the stream and never touch that again for anything. We basically
// loose ownership of the data_block.
switch (qd->msg_type ())
{
case GIOP::Request:
// Should be taken care by the state specific invocations. They
// could raise an exception or write things in the output CDR
// stream
return this->process_request (transport,
input_cdr,
output,
generator_parser);
case GIOP::LocateRequest:
return this->process_locate_request (transport,
input_cdr,
output,
generator_parser);
default:
return -1;
}
}
| void TAO_GIOP_Message_Base::send_close_connection | ( | const TAO_GIOP_Message_Version & | version, | |
| TAO_Transport * | transport | |||
| ) | [private] |
Close a connection, first sending GIOP::CloseConnection.
Definition at line 1406 of file GIOP_Message_Base.cpp.
{
// static CORBA::Octet
// I hate this in every method. Till the time I figure out a way
// around I will have them here hanging around.
const char close_message [TAO_GIOP_MESSAGE_HEADER_LEN] =
{
// The following works on non-ASCII platforms, such as MVS (which
// uses EBCDIC).
0x47, // 'G'
0x49, // 'I'
0x4f, // 'O'
0x50, // 'P'
version.major,
version.minor,
TAO_ENCAP_BYTE_ORDER,
GIOP::CloseConnection,
0, 0, 0, 0
};
// It's important that we use a reliable shutdown after we send this
// message, so we know it's received.
//
// @@ should recv and discard queued data for portability; note
// that this won't block (long) since we never set SO_LINGER
if (TAO_debug_level > 9)
{
this->dump_msg ("send_close_connection",
reinterpret_cast <const u_char *> (close_message),
TAO_GIOP_MESSAGE_HEADER_LEN);
}
ACE_Data_Block data_block (TAO_GIOP_MESSAGE_HEADER_LEN,
ACE_Message_Block::MB_DATA,
close_message,
0,
0,
ACE_Message_Block::DONT_DELETE,
0);
ACE_Message_Block message_block(&data_block);
message_block.wr_ptr (TAO_GIOP_MESSAGE_HEADER_LEN);
size_t bt;
int const result = transport->send_message_block_chain (&message_block, bt);
if (result == -1)
{
if (TAO_debug_level > 0)
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("(%P|%t) error closing connection %u, errno = %d\n"),
transport->id (), ACE_ERRNO_GET));
}
transport->close_connection ();
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("(%P|%t) shut down transport, handle %d\n"),
transport-> id ()));
}
| int TAO_GIOP_Message_Base::send_error | ( | TAO_Transport * | transport | ) | [private] |
Send error messages.
Definition at line 1306 of file GIOP_Message_Base.cpp.
{
const char error_message [TAO_GIOP_MESSAGE_HEADER_LEN] =
{
// The following works on non-ASCII platforms, such as MVS (which
// uses EBCDIC).
0x47, // 'G'
0x49, // 'I'
0x4f, // 'O'
0x50, // 'P'
(CORBA::Octet) 1, // Use the lowest GIOP version
(CORBA::Octet) 0,
TAO_ENCAP_BYTE_ORDER,
GIOP::MessageError,
0, 0, 0, 0
};
if (TAO_debug_level > 9)
{
this->dump_msg ("send_error",
reinterpret_cast <const u_char *> (error_message),
TAO_GIOP_MESSAGE_HEADER_LEN);
}
ACE_Data_Block data_block (TAO_GIOP_MESSAGE_HEADER_LEN,
ACE_Message_Block::MB_DATA,
error_message,
0,
0,
ACE_Message_Block::DONT_DELETE,
0);
ACE_Message_Block message_block(&data_block,
ACE_Message_Block::DONT_DELETE);
message_block.wr_ptr (TAO_GIOP_MESSAGE_HEADER_LEN);
size_t bt;
int const result = transport->send_message_block_chain (&message_block, bt);
if (result == -1)
{
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%N|%l|%P|%t) error sending error to transport %u\n"),
transport->id ()));
}
return result;
}
| int TAO_GIOP_Message_Base::send_reply_exception | ( | TAO_Transport * | transport, | |
| TAO_OutputCDR & | cdr, | |||
| CORBA::ULong | request_id, | |||
| IOP::ServiceContextList * | svc_info, | |||
| CORBA::Exception * | x | |||
| ) | [private] |
We must send a LocateReply through transport, this request resulted in some kind of exception.
Definition at line 1468 of file GIOP_Message_Base.cpp.
{
TAO_Pluggable_Reply_Params_Base reply_params;
reply_params.request_id_ = request_id;
reply_params.svc_ctx_.length (0);
// We are going to send some data
reply_params.argument_flag_ = true;
// Send back the service context we received. (RTCORBA relies on
// this).
reply_params.service_context_notowned (svc_info);
if (CORBA::SystemException::_downcast (x) != 0)
{
reply_params.reply_status (GIOP::SYSTEM_EXCEPTION);
}
else
{
reply_params.reply_status (GIOP::USER_EXCEPTION);
}
if (this->generate_exception_reply (output, reply_params, *x) == -1)
return -1;
output.more_fragments (false);
return transport->send_message (output, 0, TAO_REPLY);
}
| void TAO_GIOP_Message_Base::set_giop_flags | ( | TAO_OutputCDR & | msg | ) | const [private] |
Set GIOP message flags in message that has been marshaled into the output CDR stream msg.
Definition at line 2013 of file GIOP_Message_Base.cpp.
{
CORBA::Octet * const buf =
reinterpret_cast<CORBA::Octet *> (const_cast<char *> (msg.buffer ()));
CORBA::Octet const & major = buf[TAO_GIOP_VERSION_MAJOR_OFFSET];
CORBA::Octet const & minor = buf[TAO_GIOP_VERSION_MINOR_OFFSET];
// Flags for the GIOP protocol header "flags" field.
CORBA::Octet & flags = buf[TAO_GIOP_MESSAGE_FLAGS_OFFSET];
// Least significant bit: Byte order
ACE_SET_BITS (flags, TAO_ENCAP_BYTE_ORDER ^ msg.do_byte_swap ());
// Second least significant bit: More fragments
//
// Only supported in GIOP 1.1 or better.
if (!(major <= 1 && minor == 0))
ACE_SET_BITS (flags, msg.more_fragments () << 1);
}
| int TAO_GIOP_Message_Base::write_protocol_header | ( | GIOP::MsgType | t, | |
| const TAO_GIOP_Message_Version & | version, | |||
| TAO_OutputCDR & | msg | |||
| ) | [private] |
Writes the GIOP header in to msg
Definition at line 899 of file GIOP_Message_Base.cpp.
{
// Reset the message type
msg.reset ();
CORBA::Octet header[12] =
{
// The following works on non-ASCII platforms, such as MVS (which
// uses EBCDIC).
0x47, // 'G'
0x49, // 'I'
0x4f, // 'O'
0x50 // 'P'
};
header[4] = version.major;
header[5] = version.minor;
// "flags" octet, i.e. header[6] will be set up later when message
// is formatted by the transport.
header[7] = static_cast <CORBA::Octet> (type); // Message type
static ACE_CDR::ULong const header_size =
sizeof (header) / sizeof (header[0]);
// Fragmentation should not occur at this point since there are only
// 12 bytes in the stream, and fragmentation may only occur when
// the stream length >= 16.
msg.write_octet_array (header, header_size);
return msg.good_bit ();
}
TAO::Incoming_Message_Stack TAO_GIOP_Message_Base::fragment_stack_ [private] |
All Fragments being received are stored on stack in reverse order, last top
Definition at line 258 of file GIOP_Message_Base.h.
auto_ptr<TAO_GIOP_Fragmentation_Strategy> TAO_GIOP_Message_Base::fragmentation_strategy_ [protected] |
Strategy that sends data currently marshaled into this TAO_OutputCDR stream if necessary.
Definition at line 270 of file GIOP_Message_Base.h.
TAO_ORB_Core* TAO_GIOP_Message_Base::orb_core_ [private] |
Cached ORB_Core pointer...
Definition at line 251 of file GIOP_Message_Base.h.
TAO_OutputCDR TAO_GIOP_Message_Base::out_stream_ [protected] |
Buffer where the request is placed.
Definition at line 273 of file GIOP_Message_Base.h.
All the implementations of GIOP message generator and parsers.
Definition at line 254 of file GIOP_Message_Base.h.
1.7.0
