Implementation for GIOP v1.2. More...
#include <GIOP_Message_Generator_Parser_12.h>
Public Member Functions | |
| virtual bool | write_request_header (const TAO_Operation_Details &opdetails, TAO_Target_Specification &spec, TAO_OutputCDR &msg) |
| Write the request header in to msg. | |
| virtual bool | write_locate_request_header (CORBA::ULong request_id, TAO_Target_Specification &spec, TAO_OutputCDR &msg) |
| Write the LocateRequest header. | |
| virtual bool | write_reply_header (TAO_OutputCDR &output, TAO_Pluggable_Reply_Params_Base &reply) |
| Write the reply header in to output. | |
| virtual bool | write_locate_reply_mesg (TAO_OutputCDR &output, CORBA::ULong request_id, TAO_GIOP_Locate_Status_Msg &status) |
| Writes the locate _reply message in to the output. | |
| virtual bool | write_fragment_header (TAO_OutputCDR &cdr, CORBA::ULong request_id) |
| virtual int | parse_request_header (TAO_ServerRequest &) |
| virtual int | parse_locate_header (TAO_GIOP_Locate_Request_Header &) |
| virtual int | parse_reply (TAO_InputCDR &input, TAO_Pluggable_Reply_Params ¶ms) |
| Parse the reply message. | |
| virtual int | parse_locate_reply (TAO_InputCDR &input, TAO_Pluggable_Reply_Params ¶ms) |
| Parse the locate reply message. | |
| virtual CORBA::Octet | major_version (void) const |
| Our versions. | |
| virtual CORBA::Octet | minor_version (void) const |
| virtual bool | is_ready_for_bidirectional (void) const |
| virtual size_t | fragment_header_length (void) const |
| The header length of a fragment. | |
Private Member Functions | |
| bool | marshall_target_spec (TAO_Target_Specification &spec, TAO_OutputCDR &msg) |
| Marshall the TargetSpecification. | |
Implementation for GIOP v1.2.
Definition at line 36 of file GIOP_Message_Generator_Parser_12.h.
| size_t TAO_GIOP_Message_Generator_Parser_12::fragment_header_length | ( | void | ) | const [virtual] |
The header length of a fragment.
Implements TAO_GIOP_Message_Generator_Parser.
Definition at line 508 of file GIOP_Message_Generator_Parser_12.cpp.
{
return TAO_GIOP_MESSAGE_FRAGMENT_HEADER;
}
| bool TAO_GIOP_Message_Generator_Parser_12::is_ready_for_bidirectional | ( | void | ) | const [virtual] |
Is the messaging object ready for processing BiDirectional request/response?
Reimplemented from TAO_GIOP_Message_Generator_Parser.
Definition at line 399 of file GIOP_Message_Generator_Parser_12.cpp.
{
// We do support bidirectional
return true;
}
| CORBA::Octet TAO_GIOP_Message_Generator_Parser_12::major_version | ( | void | ) | const [virtual] |
Our versions.
Implements TAO_GIOP_Message_Generator_Parser.
Definition at line 386 of file GIOP_Message_Generator_Parser_12.cpp.
{
return static_cast<CORBA::Octet> (1);
}
| bool TAO_GIOP_Message_Generator_Parser_12::marshall_target_spec | ( | TAO_Target_Specification & | spec, | |
| TAO_OutputCDR & | msg | |||
| ) | [private] |
Marshall the TargetSpecification.
This method may be required for other GIOP version coming out later than 1.2. We need to share this method
Definition at line 406 of file GIOP_Message_Generator_Parser_12.cpp.
{
switch (spec.specifier ())
{
case TAO_Target_Specification::Key_Addr:
{
// As this is a union send in the discriminant first
if (!(msg << GIOP::KeyAddr))
return false;
// Get the object key
const TAO::ObjectKey *key = spec.object_key ();
if (key)
{
// Marshall in the object key
if (!(msg << *key))
return false;
}
else
{
if (TAO_debug_level)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("(%N |%l) Unable to handle this request\n")));
}
return false;
}
break;
}
case TAO_Target_Specification::Profile_Addr:
{
// As this is a union send in the discriminant first
if (!(msg << GIOP::ProfileAddr))
return false;
// Get the profile
const IOP::TaggedProfile *pfile = spec.profile ();
if (pfile)
{
// Marshall in the object key
if (!(msg << *pfile))
return false;
}
else
{
if (TAO_debug_level)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("(%N |%l) Unable to handle this request\n")));
}
return false;
}
break;
}
case TAO_Target_Specification::Reference_Addr:
{
// As this is a union send in the discriminant first
if (!(msg << GIOP::ReferenceAddr))
return false;
// Get the IOR
IOP::IOR *ior = 0;
CORBA::ULong const index = spec.iop_ior (ior);
if (ior)
{
// This is a struct IORAddressingInfo. So, marshall each
// member of the struct one after another in the order
// defined.
if (!(msg << index))
return false;
if (!(msg << *ior))
return false;;
}
else
{
if (TAO_debug_level)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("(%N |%l) Unable to handle this request\n")));
}
return false;
}
break;
}
default:
if (TAO_debug_level)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("(%N |%l) Unable to handle this request\n")));
}
return false;
}
return true;
}
| CORBA::Octet TAO_GIOP_Message_Generator_Parser_12::minor_version | ( | void | ) | const [virtual] |
Implements TAO_GIOP_Message_Generator_Parser.
Definition at line 393 of file GIOP_Message_Generator_Parser_12.cpp.
{
return static_cast<CORBA::Octet> (2);
}
| int TAO_GIOP_Message_Generator_Parser_12::parse_locate_header | ( | TAO_GIOP_Locate_Request_Header & | request | ) | [virtual] |
Parse the LocateRequest Header from the incoming stream. This will do a version specific parsing of the incoming Request header
Implements TAO_GIOP_Message_Generator_Parser.
Definition at line 311 of file GIOP_Message_Generator_Parser_12.cpp.
{
// Get the stream .
TAO_InputCDR &msg = request.incoming_stream ();
// Get the request id.
CORBA::ULong req_id = 0;
CORBA::Boolean hdr_status = msg.read_ulong (req_id);
// Store it in the Locate request classes
request.request_id (req_id);
// Unmarshal the target address field.
hdr_status =
hdr_status && request.profile ().unmarshall_target_address(msg);
// Reset the pointer to an 8-byte bouns]dary
msg.align_read_ptr (TAO_GIOP_MESSAGE_ALIGN_PTR);
return hdr_status ? 0 : -1;
}
| int TAO_GIOP_Message_Generator_Parser_12::parse_locate_reply | ( | TAO_InputCDR & | input, | |
| TAO_Pluggable_Reply_Params & | params | |||
| ) | [virtual] |
Parse the locate reply message.
Reimplemented from TAO_GIOP_Message_Generator_Parser.
Definition at line 364 of file GIOP_Message_Generator_Parser_12.cpp.
{
if (TAO_GIOP_Message_Generator_Parser::parse_locate_reply (cdr, params) == -1)
return -1;
// Note: We dont align the pointer to an 8 byte boundary for a
// locate reply body. This is due to an urgent issue raised by Michi
// in the OMG. I discussed this with Michi today (09/07/2001) and I
// learn that this has been passed. Hence the change..
/*if (cdr.length () > 0)
{
// Align the read pointer on an 8-byte boundary
cdr.align_read_ptr (TAO_GIOP_MESSAGE_ALIGN_PTR);
}*/
return 0;
}
| int TAO_GIOP_Message_Generator_Parser_12::parse_reply | ( | TAO_InputCDR & | input, | |
| TAO_Pluggable_Reply_Params & | params | |||
| ) | [virtual] |
Parse the reply message.
Reimplemented from TAO_GIOP_Message_Generator_Parser.
Definition at line 335 of file GIOP_Message_Generator_Parser_12.cpp.
{
if (TAO_GIOP_Message_Generator_Parser::parse_reply (cdr, params) == -1)
return -1;
if (!(cdr >> params.svc_ctx_))
{
if (TAO_debug_level)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) parse_reply, ")
ACE_TEXT ("extracting context\n")));
}
return -1;
}
if (cdr.length () > 0)
{
// Align the read pointer on an 8-byte boundary
cdr.align_read_ptr (TAO_GIOP_MESSAGE_ALIGN_PTR);
}
return 0;
}
| int TAO_GIOP_Message_Generator_Parser_12::parse_request_header | ( | TAO_ServerRequest & | request | ) | [virtual] |
Parse the Request Header from the incoming stream. This will do a version specific parsing of the incoming Request header
Implements TAO_GIOP_Message_Generator_Parser.
Definition at line 225 of file GIOP_Message_Generator_Parser_12.cpp.
{
// Get the input CDR in the request class
TAO_InputCDR & input = *request.incoming ();
CORBA::Boolean hdr_status = (CORBA::Boolean) input.good_bit ();
CORBA::ULong req_id = 0;
// Get the rest of the request header ...
hdr_status = hdr_status && input.read_ulong (req_id);
request.request_id (req_id);
CORBA::Octet response_flags = CORBA::Octet();
hdr_status = hdr_status && input.read_octet (response_flags);
request.response_expected ((response_flags > 0));
// The high bit of the octet has been set if the SyncScope policy
// value is SYNC_WITH_SERVER.
request.sync_with_server ((response_flags == 1));
// Reserved field
input.skip_bytes (3);
// Unmarshal the target address field.
hdr_status =
hdr_status && request.profile ().unmarshall_target_address(input);
CORBA::ULong length = 0;
hdr_status = hdr_status && input.read_ulong (length);
if (hdr_status)
{
// Do not include NULL character at the end.
// @@ This is not getting demarshaled using the codeset
// translators!
// Notice that there are no memory allocations involved
// here!
request.operation (input.rd_ptr (),
length - 1,
0 /* TAO_ServerRequest does NOT own string */);
hdr_status = input.skip_bytes (length);
}
// Tear out the service context ... we currently ignore it, but it
// should probably be passed to each ORB service as appropriate
// (e.g. transactions, security).
//
// NOTE: As security support kicks in, this is a good place to
// verify a digital signature, if that is required in this security
// environment. It may be required even when using IPSEC security
// infrastructure.
IOP::ServiceContextList &req_service_info = request.request_service_info ();
if (!(input >> req_service_info))
{
if (TAO_debug_level)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) parse_request_header, ")
ACE_TEXT ("extracting context\n")));
}
return -1;
}
if (req_service_info.length() > 0)
{
request.orb_core ()->service_context_registry ().
process_service_contexts (req_service_info, *(request.transport ()));
}
if (input.length () > 0)
{
// Reset the read_ptr to an 8-byte boundary.
input.align_read_ptr (TAO_GIOP_MESSAGE_ALIGN_PTR);
}
return hdr_status ? 0 : -1;
}
| bool TAO_GIOP_Message_Generator_Parser_12::write_fragment_header | ( | TAO_OutputCDR & | cdr, | |
| CORBA::ULong | request_id | |||
| ) | [virtual] |
Write the GIOP fragment message header to the output CDR stream cdr.
Implements TAO_GIOP_Message_Generator_Parser.
Definition at line 213 of file GIOP_Message_Generator_Parser_12.cpp.
{
return (cdr << request_id);
// No need to align write pointer to an 8 byte boundary since it
// should already be aligned (12 for GIOP messager + 4 for fragment
// header = 16 -- a multiple of 8)
}
| bool TAO_GIOP_Message_Generator_Parser_12::write_locate_reply_mesg | ( | TAO_OutputCDR & | output, | |
| CORBA::ULong | request_id, | |||
| TAO_GIOP_Locate_Status_Msg & | status | |||
| ) | [virtual] |
Writes the locate _reply message in to the output.
Implements TAO_GIOP_Message_Generator_Parser.
Definition at line 149 of file GIOP_Message_Generator_Parser_12.cpp.
{
if (!(output.write_ulong (request_id)))
return false;
// Make the header for the locate request
if (!(output.write_ulong (status_info.status)))
return false;
// Note: We dont align the pointer to an 8 byte boundary for a
// locate reply body. This is due to an urgent issue raised by Michi
// in the OMG. I discussed this with Michi today (09/07/2001) and I
// learn that this has been passed. Hence the change..
/*
if (status_info.status == TAO_GIOP_OBJECT_FORWARD ||
status_info.status == TAO_GIOP_OBJECT_FORWARD_PERM)
{
// We have to send some data, so align the pointer
if (output.align_write_ptr (TAO_GIOP_MESSAGE_ALIGN_PTR) == -1)
{
return false;
}
}
*/
switch (status_info.status)
{
case GIOP::OBJECT_FORWARD:
// More likely than not we will not have this in TAO
case GIOP::OBJECT_FORWARD_PERM:
{
CORBA::Object_ptr object_ptr =
status_info.forward_location_var.in ();
if (!(output << object_ptr))
{
if (TAO_debug_level > 0)
{
ACE_ERROR ((
LM_ERROR,
ACE_TEXT ("TAO (%P|%t|%N|%l) write_locate_reply_mesg-")
ACE_TEXT (" cannot marshal object reference\n")
));
}
}
}
break;
case GIOP::LOC_SYSTEM_EXCEPTION:
case GIOP::LOC_NEEDS_ADDRESSING_MODE:
// Do we do these in TAO??
// What to do here???? I dont really know. I have to do a survey
// of the specifications that uses this.
break;
default:
break;
}
return true;
}
| bool TAO_GIOP_Message_Generator_Parser_12::write_locate_request_header | ( | CORBA::ULong | request_id, | |
| TAO_Target_Specification & | spec, | |||
| TAO_OutputCDR & | msg | |||
| ) | [virtual] |
Write the LocateRequest header.
Implements TAO_GIOP_Message_Generator_Parser.
Definition at line 97 of file GIOP_Message_Generator_Parser_12.cpp.
{
// Write the request id
if (!(msg << request_id))
return false;
// Write the target address
if (!(this->marshall_target_spec (spec, msg)))
return false;
// I dont think we need to align the pointer to an 8 byte boundary
// here.
// We need to align the pointer
// if (msg.align_write_ptr (TAO_GIOP_MESSAGE_ALIGN_PTR) == -1)
// return 0;
// Return success
return true;
}
| bool TAO_GIOP_Message_Generator_Parser_12::write_reply_header | ( | TAO_OutputCDR & | output, | |
| TAO_Pluggable_Reply_Params_Base & | reply | |||
| ) | [virtual] |
Write the reply header in to output.
Implements TAO_GIOP_Message_Generator_Parser.
Definition at line 121 of file GIOP_Message_Generator_Parser_12.cpp.
{
// Write the request ID
if (!(output.write_ulong (reply.request_id_)))
return false;
// Write the reply status
if (!(output.write_ulong (reply.reply_status ())))
return false;
if (!(output << reply.service_context_notowned ()))
return false;
if (reply.argument_flag_)
{
// If we have some data to be marshalled, then we align the
// pointer to a 8 byte boundary. Else, we just leave it throu
if (output.align_write_ptr (TAO_GIOP_MESSAGE_ALIGN_PTR) == -1)
{
return false;
}
}
return true;
}
| bool TAO_GIOP_Message_Generator_Parser_12::write_request_header | ( | const TAO_Operation_Details & | opdetails, | |
| TAO_Target_Specification & | spec, | |||
| TAO_OutputCDR & | msg | |||
| ) | [virtual] |
Write the request header in to msg.
Implements TAO_GIOP_Message_Generator_Parser.
Definition at line 27 of file GIOP_Message_Generator_Parser_12.cpp.
{
// First the request id
if (!(msg << opdetails.request_id ()))
return false;
CORBA::Octet const response_flags = opdetails.response_flags ();
// Here are the Octet values for different policies. See the meaning
// of response_flags of RequestHeader_1_2 in the CORBA specification as
// to why the values below are used.
// '00000000' for SYNC_NONE
// '00000000' for SYNC_WITH_TRANSPORT
// '00000001' for SYNC_WITH_SERVER
// '00000011' for SYNC_WITH_TARGET
// '00000011' for regular two ways, but if they are invoked via a
// DII with INV_NO_RESPONSE flag set then we need to send '00000001'
//
// We have not implemented the policy INV_NO_RESPONSE for DII.
if (response_flags == TAO_TWOWAY_RESPONSE_FLAG)
msg << ACE_OutputCDR::from_octet (3);
// Second the response flags
// Sync scope - ignored by server if request is not oneway.
else if (response_flags == CORBA::Octet (Messaging::SYNC_NONE)
|| response_flags == CORBA::Octet (Messaging::SYNC_WITH_TRANSPORT)
|| response_flags == CORBA::Octet (TAO::SYNC_DELAYED_BUFFERING))
// No response required.
msg << ACE_OutputCDR::from_octet (0);
else if (response_flags == CORBA::Octet (Messaging::SYNC_WITH_SERVER))
// Return before dispatching to the servant
msg << ACE_OutputCDR::from_octet (1);
else if (response_flags == CORBA::Octet (Messaging::SYNC_WITH_TARGET))
// Return after dispatching servant.
msg << ACE_OutputCDR::from_octet (3);
else
// Until more flags are defined by the OMG.
return false;
// The reserved field
CORBA::Octet reserved[3] = {0, 0, 0};
msg.write_octet_array (reserved, 3);
if (!this->marshall_target_spec (spec, msg))
return false;
// Write the operation name
msg.write_string (opdetails.opname_len (),
opdetails.opname ());
// Write the service context list
if (!(msg << opdetails.request_service_info ()))
return false;
// We align the pointer only if the operation has arguments.
if (opdetails.argument_flag ()
&& msg.align_write_ptr (TAO_GIOP_MESSAGE_ALIGN_PTR) == -1)
{
return false;
}
return true;
}
1.7.0
