#include <RT_Policy_Validator.h>
Definition at line 39 of file RT_Policy_Validator.h.
| TAO_POA_RT_Policy_Validator::TAO_POA_RT_Policy_Validator | ( | TAO_ORB_Core & | orb_core | ) |
Constructor.
Definition at line 24 of file RT_Policy_Validator.cpp.
: TAO_Policy_Validator (orb_core), thread_pool_ (0) { // No-Op. }
| TAO_POA_RT_Policy_Validator::~TAO_POA_RT_Policy_Validator | ( | void | ) |
| TAO_Thread_Pool * TAO_POA_RT_Policy_Validator::extract_thread_pool | ( | TAO_ORB_Core & | orb_core, | |
| TAO_Policy_Set & | policies | |||
| ) | [static] |
Definition at line 508 of file RT_Policy_Validator.cpp.
{
CORBA::Policy_var policy =
policies.get_cached_policy (TAO_CACHED_POLICY_THREADPOOL);
RTCORBA::ThreadpoolPolicy_var thread_pool_policy =
RTCORBA::ThreadpoolPolicy::_narrow (policy.in ());
if (CORBA::is_nil (thread_pool_policy.in ()))
return 0;
RTCORBA::ThreadpoolId thread_pool_id = thread_pool_policy->threadpool ();
// Get the RTORB.
CORBA::Object_var object = orb_core.resolve_rt_orb ();
RTCORBA::RTORB_var rt_orb = RTCORBA::RTORB::_narrow (object.in ());
TAO_RT_ORB * const tao_rt_orb =
dynamic_cast <TAO_RT_ORB *> (rt_orb.in ());
if (!tao_rt_orb)
throw CORBA::INTERNAL ();
TAO_Thread_Pool_Manager & tp_manager = tao_rt_orb->tp_manager ();
TAO_Thread_Pool * const thread_pool =
tp_manager.get_threadpool (thread_pool_id);
if (thread_pool == 0)
throw PortableServer::POA::InvalidPolicy ();
return thread_pool;
}
| CORBA::Boolean TAO_POA_RT_Policy_Validator::legal_policy_impl | ( | CORBA::PolicyType | type | ) | [protected, virtual] |
Return whether the specified policy type is legal for the current configuration. This is needed since the user can potentially specify policies that are unknown to an validate () routine, and these need to be caught.
Implements TAO_Policy_Validator.
Definition at line 47 of file RT_Policy_Validator.cpp.
{
return (type == RTCORBA::PRIORITY_MODEL_POLICY_TYPE ||
type == RTCORBA::THREADPOOL_POLICY_TYPE ||
type == RTCORBA::CLIENT_PROTOCOL_POLICY_TYPE ||
type == RTCORBA::SERVER_PROTOCOL_POLICY_TYPE ||
type == RTCORBA::PRIORITY_BANDED_CONNECTION_POLICY_TYPE);
}
| void TAO_POA_RT_Policy_Validator::merge_policies_impl | ( | TAO_Policy_Set & | policies | ) | [protected, virtual] |
Add/merge policies.
Implements TAO_Policy_Validator.
Definition at line 352 of file RT_Policy_Validator.cpp.
{
// Check if the user has specified the priority model policy.
CORBA::Policy_var priority_model =
policies.get_cached_policy (TAO_CACHED_POLICY_PRIORITY_MODEL);
if (CORBA::is_nil (priority_model.in ()))
{
// If not, check if the priority model policy has been specified
// at the ORB level.
priority_model =
this->orb_core_.get_cached_policy (TAO_CACHED_POLICY_PRIORITY_MODEL);
if (!CORBA::is_nil (priority_model.in ()))
{
// If so, we'll use that policy.
policies.set_policy (priority_model.in ());
}
}
// Check if the user has specified the server protocol policy.
CORBA::Policy_var server_protocol =
policies.get_cached_policy (TAO_CACHED_POLICY_RT_SERVER_PROTOCOL);
if (CORBA::is_nil (server_protocol.in ()))
{
// If not, check if the server protocol policy has been
// specified at the ORB level.
server_protocol =
this->orb_core_.get_cached_policy (TAO_CACHED_POLICY_RT_SERVER_PROTOCOL);
if (!CORBA::is_nil (server_protocol.in ()))
{
// If so, we'll use that policy.
policies.set_policy (server_protocol.in ());
}
}
// Check if the user has specified the thread pool policy.
CORBA::Policy_var thread_pool =
policies.get_cached_policy (TAO_CACHED_POLICY_THREADPOOL);
if (CORBA::is_nil (thread_pool.in ()))
{
// If not, check if the thread pool policy has been specified at
// the ORB level.
thread_pool =
this->orb_core_.get_cached_policy (TAO_CACHED_POLICY_THREADPOOL);
if (!CORBA::is_nil (thread_pool.in ()))
{
// If so, we'll use that policy.
policies.set_policy (thread_pool.in ());
}
}
}
| void TAO_POA_RT_Policy_Validator::server_protocol_policy_from_acceptor_registry | ( | RTCORBA::ProtocolList & | protocols, | |
| TAO_Acceptor_Registry & | acceptor_registry, | |||
| TAO_ORB_Core & | orb_core | |||
| ) | [static] |
Definition at line 463 of file RT_Policy_Validator.cpp.
{
TAO_AcceptorSetIterator end = acceptor_registry.end ();
for (TAO_AcceptorSetIterator acceptor = acceptor_registry.begin ();
acceptor != end;
++acceptor)
{
if (*acceptor == 0)
continue;
CORBA::ULong current_length = protocols.length ();
// Make sure that this protocol is not already in the protocol
// list.
bool protocol_already_present = false;
for (CORBA::ULong i = 0;
i < current_length && !protocol_already_present;
++i)
{
if (protocols[i].protocol_type == (*acceptor)->tag ())
protocol_already_present = true;
}
if (protocol_already_present)
continue;
protocols.length (current_length + 1);
protocols[current_length].protocol_type =
(*acceptor)->tag ();
protocols[current_length].orb_protocol_properties =
RTCORBA::ProtocolProperties::_nil ();
protocols[current_length].transport_protocol_properties =
TAO_Protocol_Properties_Factory::create_transport_protocol_property ((*acceptor)->tag (),
&orb_core);
}
}
| RTCORBA::ServerProtocolPolicy_ptr TAO_POA_RT_Policy_Validator::server_protocol_policy_from_thread_pool | ( | TAO_Thread_Pool * | thread_pool, | |
| TAO_ORB_Core & | orb_core | |||
| ) | [static] |
Definition at line 411 of file RT_Policy_Validator.cpp.
{
RTCORBA::ProtocolList protocols;
if (thread_pool)
{
TAO_Thread_Lane **lanes =
thread_pool->lanes ();
for (CORBA::ULong i = 0;
i != thread_pool->number_of_lanes ();
++i)
{
TAO_Thread_Lane_Resources &resources =
lanes[i]->resources ();
TAO_Acceptor_Registry &acceptor_registry =
resources.acceptor_registry ();
TAO_POA_RT_Policy_Validator::server_protocol_policy_from_acceptor_registry (protocols,
acceptor_registry,
orb_core);
}
}
else
{
TAO_Thread_Lane_Resources_Manager &thread_lane_resources_manager =
orb_core.thread_lane_resources_manager ();
TAO_Thread_Lane_Resources &resources =
thread_lane_resources_manager.default_lane_resources ();
TAO_Acceptor_Registry &acceptor_registry =
resources.acceptor_registry ();
TAO_POA_RT_Policy_Validator::server_protocol_policy_from_acceptor_registry (protocols,
acceptor_registry,
orb_core);
}
// Set ServerProtocolPolicy.
TAO_ServerProtocolPolicy *server_protocol_policy = 0;
ACE_NEW_RETURN (server_protocol_policy,
TAO_ServerProtocolPolicy (protocols),
0);
return server_protocol_policy;
}
| void TAO_POA_RT_Policy_Validator::validate_impl | ( | TAO_Policy_Set & | policies | ) | [protected, virtual] |
Validate that the policies in the specified set are consistent and legal. Throw an appropriate exception if that is not the case.
Implements TAO_Policy_Validator.
Definition at line 37 of file RT_Policy_Validator.cpp.
{
this->validate_thread_pool (policies);
this->validate_server_protocol (policies);
this->validate_priorities (policies);
}
| void TAO_POA_RT_Policy_Validator::validate_priorities | ( | TAO_Policy_Set & | policies | ) | [private] |
Definition at line 152 of file RT_Policy_Validator.cpp.
{
// Initialize to the default priority/priority model.
CORBA::Short priority =
TAO_INVALID_PRIORITY;
TAO::Portable_Server::Cached_Policies::PriorityModel rt_priority_model =
TAO::Portable_Server::Cached_Policies::NOT_SPECIFIED;
CORBA::Policy_var policy =
policies.get_cached_policy (TAO_CACHED_POLICY_PRIORITY_MODEL);
RTCORBA::PriorityModelPolicy_var priority_model =
RTCORBA::PriorityModelPolicy::_narrow (policy.in ());
if (!CORBA::is_nil (priority_model.in ()))
{
priority = priority_model->server_priority ();
rt_priority_model =
TAO::Portable_Server::Cached_Policies::PriorityModel (
priority_model->priority_model ());
// Check that the priority is in bounds.
if (priority < RTCORBA::minPriority
// The line below will always be false unless the value of
// RTCORBA::maxPriority, which is now assigned the value of
// 32767, is changed in RTCORBA.pidl.
// || priority > RTCORBA::maxPriority
)
{
throw PortableServer::POA::InvalidPolicy ();
}
}
else
// If priority model was not specified, then we better not have a
// thread pool with lanes.
{
if (this->thread_pool_ != 0 &&
this->thread_pool_->with_lanes ())
throw PortableServer::POA::InvalidPolicy ();
}
policy =
policies.get_cached_policy (TAO_CACHED_POLICY_RT_PRIORITY_BANDED_CONNECTION);
RTCORBA::PriorityBandedConnectionPolicy_var priority_bands
= RTCORBA::PriorityBandedConnectionPolicy::_narrow (policy.in ());
TAO_PriorityBandedConnectionPolicy *bands_policy =
dynamic_cast<TAO_PriorityBandedConnectionPolicy *> (priority_bands.in ());
// If priority banded connections are set, make sure that:
// 0. A priority model was specified.
// 1. There is at least one band.
// 2a. low is not < RTCORBA::minPriority
// 2b. low <= high
// 2c. high is not > RTCORBA::maxPriority
// 3. If priority model is SERVER_DECLARED, server_priority must
// match one of the bands.
// 4. If this POA has a thread pool with lanes, then for each band,
// there must be at least one thread lane that can service it,
// i.e., whose priority falls into the band's range.
if (bands_policy != 0)
{
// Checks 0.
if (rt_priority_model == TAO::Portable_Server::Cached_Policies::NOT_SPECIFIED)
throw PortableServer::POA::InvalidPolicy ();
RTCORBA::PriorityBands &bands =
bands_policy->priority_bands_rep ();
// Checks 1.
if (bands.length () == 0)
throw PortableServer::POA::InvalidPolicy ();
// Checks 2.
for (CORBA::ULong i = 0; i < bands.length (); ++i)
{
// 2a. low is not < RTCORBA::minPriority
// 2b. low is not > high
// 2c. high is not > RTCORBA::maxPriority
if (bands[i].low < RTCORBA::minPriority
|| bands[i].low > bands[i].high
// The line below will always be false unless the value of
// RTCORBA::maxPriority, which is now assigned the value of
// 32767, is changed in RTCORBA.pidl.
// || bands[i].high > RTCORBA::maxPriority
)
{
throw PortableServer::POA::InvalidPolicy ();
}
}
// Check 3.
if (rt_priority_model == TAO::Portable_Server::Cached_Policies::SERVER_DECLARED)
{
int match = 0;
for (CORBA::ULong i = 0; i < bands.length (); ++i)
{
if (priority <= bands[i].high &&
priority >= bands[i].low)
{
match = 1;
break;
}
}
if (!match)
throw PortableServer::POA::InvalidPolicy ();
}
//
// Check 4.
//
// If this POA is using the default thread pool (which doesn't
// have lanes) or a thread pool without lanes, we are done with
// the checks.
if (this->thread_pool_ == 0 ||
!this->thread_pool_->with_lanes ())
return;
// If this POA is using a thread pool with lanes, make sure we
// have at least one thread lane that corresponds to these
// each band.
TAO_Thread_Lane **lanes =
this->thread_pool_->lanes ();
for (CORBA::ULong band = 0;
band < bands.length ();
++band)
{
int match = 0;
for (CORBA::ULong lane = 0;
lane != this->thread_pool_->number_of_lanes () && !match;
++lane)
{
CORBA::Short lane_priority =
lanes[lane]->lane_priority ();
if (lane_priority <= bands[band].high &&
lane_priority >= bands[band].low)
match = 1;
}
if (!match)
throw PortableServer::POA::InvalidPolicy ();
}
// Done with checks.
return;
}
// If priority banded connections are not set, and the priority
// model is SERVER_DECLARED, make sure we have at least one thread
// lane that can provide service for the specified SERVER_DECLARED
// priority.
if (rt_priority_model == TAO::Portable_Server::Cached_Policies::SERVER_DECLARED)
{
// If this POA is using the default thread pool (which doesn't
// have lanes) or a thread pool without lanes, we are done with
// the checks.
if (this->thread_pool_ == 0 ||
!this->thread_pool_->with_lanes ())
return;
// If this POA is using a thread pool with lanes, make sure we
// have at least one thread lane that can provide service for
// the specified SERVER_DECLARED priority.
TAO_Thread_Lane **lanes =
this->thread_pool_->lanes ();
int match = 0;
for (CORBA::ULong lane = 0;
lane != this->thread_pool_->number_of_lanes () && !match;
++lane)
{
CORBA::Short lane_priority =
lanes[lane]->lane_priority ();
if (lane_priority <= priority &&
lane_priority >= priority)
match = 1;
}
if (!match)
throw PortableServer::POA::InvalidPolicy ();
// Done with checks.
return;
}
}
| void TAO_POA_RT_Policy_Validator::validate_server_protocol | ( | TAO_Policy_Set & | policies | ) | [private] |
Definition at line 57 of file RT_Policy_Validator.cpp.
{
// Make sure we have an endpoint for at least one of the protocols
// specified in the RTCORBA::ServerProtocolPolicy. This ensure we
// will be able to create non-nil object references.
CORBA::Policy_var protocol =
policies.get_cached_policy (TAO_CACHED_POLICY_RT_SERVER_PROTOCOL);
if (CORBA::is_nil (protocol.in ()))
{
// If the server protocol policy has not been specified, then
// add a server policy that reflects the protocols supported by
// the acceptor registries of the POA's thread pool.
protocol =
TAO_POA_RT_Policy_Validator::server_protocol_policy_from_thread_pool (this->thread_pool_,
this->orb_core_);
if (!CORBA::is_nil (protocol.in ()))
{
// If so, we'll use that policy.
policies.set_policy (protocol.in ());
}
}
RTCORBA::ServerProtocolPolicy_var server_protocol_policy =
RTCORBA::ServerProtocolPolicy::_narrow (protocol.in ());
TAO_ServerProtocolPolicy *server_protocol =
dynamic_cast <TAO_ServerProtocolPolicy *>
(server_protocol_policy.in ());
RTCORBA::ProtocolList &protocols =
server_protocol->protocols_rep ();
for (CORBA::ULong j = 0; j < protocols.length (); ++j)
{
bool found = false;
CORBA::ULong const protocol_type = protocols[j].protocol_type;
if (this->thread_pool_)
{
TAO_Thread_Lane **lanes =
this->thread_pool_->lanes ();
for (CORBA::ULong i = 0;
i != this->thread_pool_->number_of_lanes ();
++i)
{
TAO_Thread_Lane_Resources &resources =
lanes[i]->resources ();
TAO_Acceptor_Registry &acceptor_registry =
resources.acceptor_registry ();
for (TAO_AcceptorSetIterator a = acceptor_registry.begin ();
a != acceptor_registry.end ();
++a)
{
if ((*a)->tag () == protocol_type)
{
found = true;
break;
}
}
}
}
else
{
TAO_Thread_Lane_Resources_Manager &thread_lane_resources_manager =
this->orb_core_.thread_lane_resources_manager ();
TAO_Thread_Lane_Resources &resources =
thread_lane_resources_manager.default_lane_resources ();
TAO_Acceptor_Registry &acceptor_registry =
resources.acceptor_registry ();
for (TAO_AcceptorSetIterator a = acceptor_registry.begin ();
a != acceptor_registry.end ();
++a)
{
if ((*a)->tag () == protocol_type)
{
found = true;
break;
}
}
}
if (!found)
throw PortableServer::POA::InvalidPolicy ();
}
}
| void TAO_POA_RT_Policy_Validator::validate_thread_pool | ( | TAO_Policy_Set & | policies | ) | [private] |
Definition at line 345 of file RT_Policy_Validator.cpp.
{
this->thread_pool_ =
TAO_POA_RT_Policy_Validator::extract_thread_pool (this->orb_core_, policies);
}
Definition at line 86 of file RT_Policy_Validator.h.
1.7.0
