TAO: TAO::Transport_Cache_Manager Class Reference

typedef TAO_Condition<TAO_SYNCH_MUTEX> TAO::Transport_Cache_Manager::CONDITION

Definition at line 81 of file Transport_Cache_Manager.h.

typedef HASH_MAP_ENTRY** TAO::Transport_Cache_Manager::DESCRIPTOR_SET [private]

Definition at line 219 of file Transport_Cache_Manager.h.

typedef ACE_Hash_Map_Manager_Ex<Cache_ExtId, Cache_IntId, ACE_Hash<Cache_ExtId>, ACE_Equal_To<Cache_ExtId>, ACE_Null_Mutex> TAO::Transport_Cache_Manager::HASH_MAP

Definition at line 73 of file Transport_Cache_Manager.h.

typedef ACE_Hash_Map_Entry<Cache_ExtId, Cache_IntId> TAO::Transport_Cache_Manager::HASH_MAP_ENTRY

Definition at line 79 of file Transport_Cache_Manager.h.

typedef HASH_MAP::iterator TAO::Transport_Cache_Manager::HASH_MAP_ITER

Definition at line 75 of file Transport_Cache_Manager.h.

TAO::Transport_Cache_Manager::Transport_Cache_Manager ( TAO_ORB_Core & orb_core )

Constructor.

If the cache is not going to be locked then dont create a condition variable. Make the <muxed_number_> to 0, else a single thread could get into waiting mode

Definition at line 25 of file Transport_Cache_Manager.cpp.

References ACE_NEW, TAO_Resource_Factory::locked_transport_cache(), muxed_number_, and TAO_ORB_Core::resource_factory().

00026     : percent_ (orb_core.resource_factory ()->purge_percentage ())
00027     , purging_strategy_ (orb_core.resource_factory ()->create_purging_strategy ())
00028     , cache_map_ (orb_core.resource_factory ()->cache_maximum ())
00029     , condition_ (0)
00030     , cache_lock_ (0)
00031     , muxed_number_ (orb_core.resource_factory ()->max_muxed_connections ())
00032     , no_waiting_threads_ (0)
00033     , last_entry_returned_ (0)
00034   {
00035     if (orb_core.resource_factory ()->locked_transport_cache ())
00036       {
00037         ACE_NEW (this->condition_,
00038                  TAO_Condition <TAO_SYNCH_MUTEX>);
00039
00040         ACE_NEW (this->cache_lock_,
00041                  ACE_Lock_Adapter <TAO_SYNCH_MUTEX> (*this->condition_->mutex ()));
00042       }
00043     else
00044       {
00045         /// If the cache is not going to be locked then dont create a
00046         /// condition variable. Make the <muxed_number_> to 0, else a
00047         /// single thread could get into waiting mode
00048         this->muxed_number_ = 0;
00049         ACE_NEW (this->cache_lock_,
00050                  ACE_Lock_Adapter<ACE_SYNCH_NULL_MUTEX>);
00051       }
00052
00053 #if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1)
00054     ACE_NEW (this->purge_monitor_,
00055              ACE::Monitor_Control::Size_Monitor ("Connection_Cache_Purge"));
00056     ACE_NEW (this->size_monitor_,
00057              ACE::Monitor_Control::Size_Monitor ("Connection_Cache_Size"));
00058     this->purge_monitor_->add_to_registry ();
00059     this->size_monitor_->add_to_registry ();
00060 #endif /* TAO_HAS_MONITOR_POINTS==1 */
00061   }

TAO::Transport_Cache_Manager::~Transport_Cache_Manager ( void )

Destructor.

Definition at line 63 of file Transport_Cache_Manager.cpp.

References TAO_Condition< MUTEX >::broadcast(), cache_lock_, condition_, and purging_strategy_.

00064   {
00065     // Wakeup all the waiting threads threads before we shutdown stuff
00066     if (this->no_waiting_threads_)
00067       {
00068         this->condition_->broadcast ();
00069       }
00070
00071     // Delete the lock that we have
00072     if (this->cache_lock_)
00073       {
00074         delete this->cache_lock_;
00075         this->cache_lock_ = 0;
00076       }
00077
00078     // Delete the purging strategy
00079     if (this->purging_strategy_)
00080       {
00081         delete this->purging_strategy_;
00082         this->purging_strategy_ = 0;
00083       }
00084
00085     // Delete the condition variable
00086     if (this->condition_)
00087       {
00088         delete this->condition_;
00089         this->condition_ = 0;
00090       }
00091
00092 #if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1)
00093     this->purge_monitor_->remove_from_registry ();
00094     this->size_monitor_->remove_from_registry ();
00095     this->purge_monitor_->remove_ref ();
00096     this->size_monitor_->remove_ref ();
00097 #endif /* TAO_HAS_MONITOR_POINTS==1 */
00098   }

ACE_INLINE int TAO::Transport_Cache_Manager::bind	(	Cache_ExtId &	ext_id,
		Cache_IntId &	int_id
	)			`[private]`

Associate ext_id with int_id. Grabs the lock and calls the implementation function bind_i.

Definition at line 11 of file Transport_Cache_Manager.inl.

References ACE_GUARD_RETURN, and bind_i().

00013   {
00014     ACE_MT (ACE_GUARD_RETURN (ACE_Lock,
00015                               guard,
00016                               *this->cache_lock_,
00017                               -1));
00018
00019     return this->bind_i (ext_id, int_id);
00020   }

int TAO::Transport_Cache_Manager::bind_i	(	Cache_ExtId &	ext_id,
		Cache_IntId &	int_id
	)			`[private]`

Non-Locking version and actual implementation of bind () call. Calls bind on the Hash_Map_Manager that it holds. If the bind succeeds, it adds the Hash_Map_Entry in to the Transport for its reference. If the bind fails because of an exiting entry, this method calls the get_last_index_bind ().

Definition at line 102 of file Transport_Cache_Manager.cpp.

References ACE_DEBUG, ACE_ERROR, ACE_TEXT, ACE_Hash_Map_Manager_Ex< EXT_ID, INT_ID, HASH_KEY, COMPARE_KEYS, ACE_LOCK >::bind(), cache_map_, TAO_Transport::cache_map_entry(), get_last_index_bind(), TAO::Cache_ExtId::hash(), TAO_Transport::id(), LM_DEBUG, LM_ERROR, LM_INFO, purging_strategy_, TAO_debug_level, TAO::Cache_IntId::transport(), and TAO_Connection_Purging_Strategy::update_item().

Referenced by bind(), cache_idle_transport(), and cache_transport().

00104   {
00105     if (TAO_debug_level > 0)
00106        {
00107          ACE_DEBUG ((LM_INFO,
00108             ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager::bind_i, ")
00109             ACE_TEXT ("Transport[%d]; hash %d\n"),
00110             int_id.transport ()->id (),
00111             ext_id.hash ()
00112             ));
00113        }
00114
00115     // Get the entry too
00116     HASH_MAP_ENTRY *entry = 0;
00117
00118     // Update the purging strategy information while we
00119     // are holding our lock
00120     this->purging_strategy_->update_item (int_id.transport ());
00121
00122     int retval = this->cache_map_.bind (ext_id, int_id, entry);
00123     if (retval == 0)
00124       {
00125         // The entry has been added to cache succesfully
00126         // Add the cache_map_entry to the transport
00127         int_id.transport ()->cache_map_entry (entry);
00128       }
00129     else if (retval == 1)
00130       {
00131         if (TAO_debug_level > 4)
00132           {
00133             ACE_DEBUG ((LM_DEBUG,
00134                         "TAO (%P|%t) - Transport_Cache_Manager::bind_i, "
00135                         "unable to bind in the first attempt. "
00136                         "Trying with a new index\n"));
00137           }
00138
00139         // There was an entry like this before, so let us do some
00140         // minor adjustments and rebind
00141         retval = this->get_last_index_bind (ext_id, int_id, entry);
00142         if (retval == 0)
00143           {
00144             int_id.transport ()->cache_map_entry (entry);
00145           }
00146       }
00147
00148     if (TAO_debug_level > 5 && retval != 0)
00149       {
00150         ACE_ERROR ((LM_ERROR,
00151                     "TAO (%P|%t) - Transport_Cache_Manager::bind_i, "
00152                     "unable to bind\n"));
00153       }
00154     else if (TAO_debug_level > 3)
00155       {
00156         ACE_DEBUG ((LM_DEBUG,
00157                     "TAO (%P|%t) - Transport_Cache_Manager::bind_i, "
00158                     "cache size is [%d]\n",
00159                     this->current_size ()));
00160       }
00161
00162 #if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1)
00163     this->size_monitor_->receive (this->current_size ());
00164 #endif /* TAO_HAS_MONITOR_POINTS==1 */
00165
00166     return retval;
00167   }

ACE_INLINE bool TAO::Transport_Cache_Manager::blockable_client_transports ( Connection_Handler_Set & handlers )

This call is used for a specific use case by the ORB_Core during shutdown. The only way the ORB can wake up threads waiting on these sockstes for replies is to iterate over these blockable transports and close the socket handles. Without these the threads will continue to wait there for ever.

Definition at line 124 of file Transport_Cache_Manager.inl.

References ACE_GUARD_RETURN, and blockable_client_transports_i().

00126   {
00127     ACE_MT (ACE_GUARD_RETURN (ACE_Lock,
00128                               guard,
00129                               *this->cache_lock_,
00130                               false));
00131
00132     return this->blockable_client_transports_i (handlers);
00133   }

bool TAO::Transport_Cache_Manager::blockable_client_transports_i ( Connection_Handler_Set & handlers ) [private]

Non-locking version of blockable_client_transports ().

Definition at line 375 of file Transport_Cache_Manager.cpp.

References cache_map_, ACE_Hash_Map_Manager_Ex< EXT_ID, INT_ID, HASH_KEY, COMPARE_KEYS, ACE_LOCK >::end(), and TAO::ENTRY_CLOSED.

Referenced by blockable_client_transports().

00377   {
00378     HASH_MAP_ITER end_iter = this->cache_map_.end ();
00379
00380     for (HASH_MAP_ITER iter = this->cache_map_.begin ();
00381          iter != end_iter;
00382          ++iter)
00383       {
00384         // Get the transport to fill its associated connection's
00385         // handler.
00386         bool const retval =
00387           (*iter).int_id_.transport ()->provide_blockable_handler (h);
00388
00389         // Do not mark the entry as closed if we don't have a
00390         // blockable handler added
00391         if (retval)
00392           (*iter).int_id_.recycle_state (ENTRY_CLOSED);
00393       }
00394
00395     return true;
00396   }

ACE_INLINE int TAO::Transport_Cache_Manager::cache_idle_transport	(	TAO_Transport_Descriptor_Interface *	prop,
		TAO_Transport *	transport
	)

Similar to the one above, but the transport is left in ENTRY_IDLE_AND_PURGABLE state.

Definition at line 48 of file Transport_Cache_Manager.inl.

References ACE_GUARD_RETURN, bind_i(), TAO::ENTRY_IDLE_AND_PURGABLE, and TAO::Cache_IntId::recycle_state().

00051   {
00052     // Compose the ExternId & Intid
00053     Cache_ExtId ext_id (prop);
00054     Cache_IntId int_id (transport);
00055
00056     int retval = 0;
00057     {
00058       ACE_MT (ACE_GUARD_RETURN (ACE_Lock,
00059                                 guard,
00060                                 *this->cache_lock_,
00061                                 -1));
00062
00063       // Do as the semantics of this method dictates
00064       int_id.recycle_state (ENTRY_IDLE_AND_PURGABLE);
00065       retval = this->bind_i (ext_id, int_id);
00066     }
00067
00068     return retval;
00069   }

ACE_INLINE int TAO::Transport_Cache_Manager::cache_transport	(	TAO_Transport_Descriptor_Interface *	prop,
		TAO_Transport *	transport
	)

Add the transport to the cache.

The transport has the property definition based on which caching can be done. This method marks the transport ACE_RECYCLABLE_BUSY which helps the threads opening up connections to use the transport immediately.

Definition at line 23 of file Transport_Cache_Manager.inl.

References ACE_GUARD_RETURN, bind_i(), TAO::ENTRY_BUSY, and TAO::Cache_IntId::recycle_state().

00026   {
00027     // Compose the ExternId & Intid
00028     Cache_ExtId ext_id (prop);
00029     Cache_IntId int_id (transport);
00030
00031     int retval = 0;
00032     {
00033       ACE_MT (ACE_GUARD_RETURN (ACE_Lock,
00034                                 guard,
00035                                 *this->cache_lock_,
00036                                 -1));
00037
00038       // Do as the semantics of this method dictates
00039       int_id.recycle_state (ENTRY_BUSY);
00040
00041       retval = this->bind_i (ext_id, int_id);
00042     }
00043
00044     return retval;
00045   }

ACE_INLINE int TAO::Transport_Cache_Manager::close ( Connection_Handler_Set & handlers )

Close the underlying hash map manager and return any handlers still registered

Definition at line 106 of file Transport_Cache_Manager.inl.

References ACE_GUARD_RETURN, and close_i().

00107   {
00108     // The cache lock pointer should only be zero if
00109     // Transport_Cache_Manager::open() was never called.  Note that
00110     // only one thread opens the Transport_Cache_Manager at any given
00111     // time, so it is safe to check for a non-zero lock pointer.
00112     if (this->cache_lock_ == 0)
00113       return -1;
00114
00115     ACE_MT (ACE_GUARD_RETURN (ACE_Lock,
00116                               guard,
00117                               *this->cache_lock_,
00118                               -1));
00119
00120     return this->close_i (handlers);
00121   }

int TAO::Transport_Cache_Manager::close_i ( Connection_Handler_Set & handlers ) [private]

Non-locking version and actual implementation of close ().

Definition at line 350 of file Transport_Cache_Manager.cpp.

References cache_map_, ACE_Hash_Map_Manager_Ex< EXT_ID, INT_ID, HASH_KEY, COMPARE_KEYS, ACE_LOCK >::end(), and ACE_Hash_Map_Manager_Ex< EXT_ID, INT_ID, HASH_KEY, COMPARE_KEYS, ACE_LOCK >::unbind_all().

Referenced by close().

00351   {
00352     HASH_MAP_ITER end_iter = this->cache_map_.end ();
00353
00354     for (HASH_MAP_ITER iter = this->cache_map_.begin ();
00355          iter != end_iter;
00356          ++iter)
00357       {
00358         // Get the transport to fill its associated connection's handler.
00359         (*iter).int_id_.transport ()->provide_handler (handlers);
00360
00361         // Inform the transport that has a reference to the entry in the
00362         // map that we are *gone* now. So, the transport should not use
00363         // the reference to the entry that he has, to access us *at any
00364         // time*.
00365         (*iter).int_id_.transport ()->cache_map_entry (0);
00366       }
00367
00368     // Unbind all the entries in the map
00369     this->cache_map_.unbind_all ();
00370
00371     return 0;
00372   }

int TAO::Transport_Cache_Manager::cpscmp	(	const void *	a,
		const void *	b
	)			`[static, private]`

Used by qsort.

Definition at line 481 of file Transport_Cache_Manager.cpp.

Referenced by sort_set().

00482   {
00483     const HASH_MAP_ENTRY** left  = (const HASH_MAP_ENTRY**)a;
00484     const HASH_MAP_ENTRY** right = (const HASH_MAP_ENTRY**)b;
00485
00486     if ((*left)->int_id_.transport ()->purging_order () <
00487         (*right)->int_id_.transport ()->purging_order ())
00488       return -1;
00489
00490     if ((*left)->int_id_.transport ()->purging_order () >
00491         (*right)->int_id_.transport ()->purging_order ())
00492       return 1;
00493
00494     return 0;
00495   }

ACE_INLINE size_t TAO::Transport_Cache_Manager::current_size ( void ) const

Return the current size of the cache.

Definition at line 136 of file Transport_Cache_Manager.inl.

References cache_map_, and ACE_Hash_Map_Manager_Ex< EXT_ID, INT_ID, HASH_KEY, COMPARE_KEYS, ACE_LOCK >::current_size().

Referenced by fill_set_i().

00137   {
00138     return this->cache_map_.current_size ();
00139   }

int TAO::Transport_Cache_Manager::fill_set_i ( DESCRIPTOR_SET & sorted_set ) [private]

Fill sorted_set in with the TAO_Transport_Descriptor_Interface's in a sorted order.

Definition at line 626 of file Transport_Cache_Manager.cpp.

References ACE_DEBUG, ACE_NEW_RETURN, ACE_TEXT, ACE_Hash_Map_Manager_Ex< EXT_ID, INT_ID, HASH_KEY, COMPARE_KEYS, ACE_LOCK >::begin(), cache_map_, TAO_Connection_Purging_Strategy::cache_maximum(), ACE_Hash_Map_Manager_Ex< EXT_ID, INT_ID, HASH_KEY, COMPARE_KEYS, ACE_LOCK >::current_size(), current_size(), LM_DEBUG, purging_strategy_, sort_set(), and TAO_debug_level.

Referenced by purge().

00627   {
00628     int current_size = 0;
00629     int const cache_maximum = this->purging_strategy_->cache_maximum ();
00630
00631     // set sorted_set to 0.  This signifies nothing to purge.
00632     sorted_set = 0;
00633
00634     // Do we need to worry about cache purging?
00635     if (cache_maximum >= 0)
00636       {
00637         current_size = static_cast<int> (this->cache_map_.current_size ());
00638
00639         if (TAO_debug_level > 0)
00640           {
00641             ACE_DEBUG ((LM_DEBUG,
00642                         ACE_TEXT("TAO (%P|%t) - Transport_Cache_Manager::fill_set_i, ")
00643                         ACE_TEXT("current_size = %d, cache_maximum = %d\n"),
00644                         current_size, cache_maximum));
00645           }
00646
00647         if (current_size >= cache_maximum)
00648           {
00649             ACE_NEW_RETURN (sorted_set, HASH_MAP_ENTRY*[current_size], 0);
00650
00651             HASH_MAP_ITER iter = this->cache_map_.begin ();
00652
00653             for (int i = 0; i < current_size; ++i)
00654               {
00655                 sorted_set[i] = &(*iter);
00656                 iter++;
00657               }
00658
00659             this->sort_set (sorted_set, current_size);
00660           }
00661     }
00662
00663     return current_size;
00664   }

int TAO::Transport_Cache_Manager::find	(	const Cache_ExtId &	key,
		Cache_IntId &	value
	)			`[private]`

Lookup entry<key,value> in the cache. Grabs the lock and calls the implementation function find_i.

Definition at line 217 of file Transport_Cache_Manager.cpp.

References ACE_GUARD_RETURN, find_i(), purging_strategy_, TAO::Cache_IntId::transport(), and TAO_Connection_Purging_Strategy::update_item().

Referenced by find_transport().

00219   {
00220     ACE_MT (ACE_GUARD_RETURN  (ACE_Lock,
00221                                guard,
00222                                *this->cache_lock_,
00223                                -1));
00224
00225     int const status =  this->find_i (key, value);
00226
00227     if (status == 0)
00228       {
00229         // Update the purging strategy information while we
00230         // are holding our lock
00231         this->purging_strategy_->update_item (value.transport ());
00232       }
00233
00234     return status;
00235   }

int TAO::Transport_Cache_Manager::find_i	(	const Cache_ExtId &	key,
		Cache_IntId &	value
	)			`[private]`

Non-locking version and actual implementation of find () call. This calls the find () on the underlying Hash_Map_Manager. If the find succeeds, it calls the get_idle_transport ().

Definition at line 238 of file Transport_Cache_Manager.cpp.

References ACE_DEBUG, ACE_ERROR, ACE_TEXT, cache_map_, TAO::ENTRY_BUSY, ACE_Hash_Map_Entry< EXT_ID, INT_ID >::ext_id_, ACE_Hash_Map_Manager_Ex< EXT_ID, INT_ID, HASH_KEY, COMPARE_KEYS, ACE_LOCK >::find(), ACE_Hash_Map_Entry< EXT_ID, INT_ID >::int_id_, is_entry_idle(), LM_DEBUG, LM_ERROR, TAO::Cache_ExtId::property(), TAO_debug_level, and wait_for_connection().

Referenced by find().

00240   {
00241     HASH_MAP_ENTRY *entry = 0;
00242
00243     // Get the entry from the Hash Map
00244     int retval = 0;
00245
00246     // Make a temporary object. It does not do a copy.
00247     Cache_ExtId tmp_key (key.property ());
00248
00249     while (retval == 0)
00250       {
00251         // Wait for a connection..
00252         this->wait_for_connection (tmp_key);
00253
00254         // Look for an entry in the map
00255         retval = this->cache_map_.find (tmp_key, entry);
00256
00257         // We have an entry in the map, check whether it is idle.
00258         if (entry)
00259           {
00260             CORBA::Boolean const idle = this->is_entry_idle (entry);
00261
00262             if (idle)
00263               {
00264                 // Successfully found a TAO_Transport.
00265
00266                 entry->int_id_.recycle_state (ENTRY_BUSY);
00267
00268                 // NOTE: This assignment operator indirectly incurs two
00269                 //       lock operations since it duplicates and releases
00270                 //       TAO_Transport objects.
00271                 value = entry->int_id_;
00272
00273                 if (TAO_debug_level > 4)
00274                   {
00275                     ACE_DEBUG ((LM_DEBUG,
00276                                 ACE_TEXT("TAO (%P|%t) - Transport_Cache_Manager::find_i, ")
00277                                 ACE_TEXT("at index %d (Transport[%d]) - idle\n"),
00278                                 entry->ext_id_.index (),
00279                                 entry->int_id_.transport ()->id ()));
00280                   }
00281
00282                 return 0;
00283               }
00284             else if (TAO_debug_level > 6)
00285                   {
00286                     ACE_DEBUG ((LM_DEBUG,
00287                                 ACE_TEXT("TAO (%P|%t) - Transport_Cache_Manager::find_i, ")
00288                                 ACE_TEXT("at index %d (Transport[%d]) - not idle\n"),
00289                                 entry->ext_id_.index (),
00290                                 entry->int_id_.transport ()->id ()));
00291                   }
00292           }
00293
00294         // Bump the index up
00295         tmp_key.incr_index ();
00296       }
00297
00298     // If we are here then it is an error
00299     if (TAO_debug_level > 4 && retval != 0)
00300       {
00301         ACE_ERROR ((LM_ERROR,
00302                     "TAO (%P|%t) - Transport_Cache_Manager::find_i, "
00303                     "no idle transport is available\n"));
00304       }
00305
00306     return retval;
00307   }

int TAO::Transport_Cache_Manager::find_transport	(	TAO_Transport_Descriptor_Interface *	prop,
		TAO_Transport *&	transport
	)

Check the Transport Cache to check whether the connection exists in the Cache and return the connection

Definition at line 170 of file Transport_Cache_Manager.cpp.

References ACE_ERROR, ACE_TEXT, TAO_ORB_Core::client_factory(), ACE_Event_Handler::DONT_CALL, TAO_Transport::event_handler_i(), find(), TAO_Transport::id(), TAO_Wait_Strategy::is_registered(), LM_ERROR, TAO_Wait_Strategy::non_blocking(), TAO_Transport::orb_core(), TAO_ORB_Core::reactor(), ACE_Event_Handler::READ_MASK, TAO::Cache_IntId::relinquish_transport(), ACE_Reactor::remove_handler(), TAO_debug_level, TAO_Client_Strategy_Factory::use_cleanup_options(), and TAO_Transport::wait_strategy().

00173   {
00174     if (prop == 0)
00175       {
00176         transport = 0;
00177         return -1;
00178       }
00179
00180     // Compose the ExternId
00181     Cache_ExtId ext_id (prop);
00182     Cache_IntId int_id;
00183
00184     int const retval = this->find (ext_id, int_id);
00185     if (retval == 0)
00186       {
00187         transport = int_id.relinquish_transport ();
00188
00189         if (transport->wait_strategy ()->non_blocking () == 0 &&
00190             transport->orb_core ()->client_factory ()->use_cleanup_options ())
00191           {
00192             ACE_Event_Handler * const eh = transport->event_handler_i ();
00193             ACE_Reactor * const r = transport->orb_core ()->reactor ();
00194
00195             if (eh &&
00196                 r->remove_handler (eh,
00197                                    ACE_Event_Handler::READ_MASK |
00198                                    ACE_Event_Handler::DONT_CALL) == -1)
00199               {
00200                 if (TAO_debug_level > 0)
00201                   ACE_ERROR ((LM_ERROR,
00202                               ACE_TEXT ("TAO (%P|%t) - TAO_Transport_Cache_Manager[%d]")
00203                               ACE_TEXT ("::find_transport, remove_handler failed \n"),
00204                               transport->id ()));
00205               }
00206             else
00207               {
00208                 transport->wait_strategy ()->is_registered (false);
00209               }
00210           }
00211       }
00212
00213     return retval;
00214   }

int TAO::Transport_Cache_Manager::get_last_index_bind	(	Cache_ExtId &	key,
		Cache_IntId &	val,
		HASH_MAP_ENTRY *&	entry
	)			`[private]`

This is called by the bind () call when a bind fails with a available entry. When a new connection is created in TAO with an already existing endpoint, in addition to an exisitng one, we mark the connections with an index. This method, finds out the last highest index and binds the entry with an index = (last highest index + 1).

Definition at line 432 of file Transport_Cache_Manager.cpp.

References ACE_Hash_Map_Manager_Ex< EXT_ID, INT_ID, HASH_KEY, COMPARE_KEYS, ACE_LOCK >::bind(), cache_map_, ACE_Hash_Map_Entry< EXT_ID, INT_ID >::ext_id_, ACE_Hash_Map_Manager_Ex< EXT_ID, INT_ID, HASH_KEY, COMPARE_KEYS, ACE_LOCK >::find(), and TAO::Cache_ExtId::index().

Referenced by bind_i().

00435   {
00436     CORBA::ULong ctr = entry->ext_id_.index ();
00437     int retval = 0;
00438
00439     while (retval == 0)
00440       {
00441         // Set the index
00442         key.index (++ctr);
00443
00444         // Check to see if an element exists in the Map. If it exists we
00445         // loop, else we drop out of the loop
00446         retval = this->cache_map_.find (key);
00447       }
00448
00449     // Now do a bind again with the new index
00450     return  this->cache_map_.bind (key, val, entry);
00451
00452 #if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1)
00453     this->size_monitor_->receive (this->current_size ());
00454 #endif /* TAO_HAS_MONITOR_POINTS==1 */
00455   }

bool TAO::Transport_Cache_Manager::is_entry_idle ( HASH_MAP_ENTRY *& entry ) [private]

Tries to find if the <int_id_> in entry is idle for use. If it is idle it is immediately markes as busy and returns a value of 1, else it returns a value of 0

Definition at line 459 of file Transport_Cache_Manager.cpp.

References ACE_DEBUG, ACE_TEXT, TAO::ENTRY_IDLE_AND_PURGABLE, TAO::ENTRY_IDLE_BUT_NOT_PURGABLE, ACE_Hash_Map_Entry< EXT_ID, INT_ID >::int_id_, LM_DEBUG, and TAO_debug_level.

Referenced by find_i().

00460   {
00461     Cache_Entries_State entry_state =
00462       entry->int_id_.recycle_state ();
00463
00464     if (TAO_debug_level)
00465       {
00466         ACE_DEBUG ((LM_DEBUG,
00467                     ACE_TEXT("TAO (%P|%t) - Transport_Cache_Manager::is_entry_idle, ")
00468                     ACE_TEXT("state is [%d]\n"),
00469                     entry_state));
00470       }
00471
00472     if (entry_state == ENTRY_IDLE_AND_PURGABLE ||
00473         entry_state == ENTRY_IDLE_BUT_NOT_PURGABLE)
00474       return true;
00475
00476     return false;
00477   }

int TAO::Transport_Cache_Manager::is_wakeup_useful ( Cache_ExtId & extid ) [private]

Is the wakeup useful todo some work?

Definition at line 709 of file Transport_Cache_Manager.cpp.

References condition_, TAO::Cache_ExtId::index(), TAO_Transport_Descriptor_Interface::is_equivalent(), last_entry_returned_, TAO::Cache_ExtId::property(), and TAO_Condition< MUTEX >::signal().

Referenced by wait_for_connection().

00710   {
00711     // Get the underlying property that we are looking for
00712     TAO_Transport_Descriptor_Interface *prop = extid.property ();
00713
00714     // Just check the underlying property for equivalence. If the last
00715     // connection that was returned  had the same property just return
00716     // 1.
00717     if (this->last_entry_returned_ &&
00718         prop->is_equivalent (this->last_entry_returned_->property ()))
00719       {
00720         // Set the index to be right so that we can pick teh connection
00721         // right away..
00722         extid.index (this->last_entry_returned_->index ());
00723
00724         // There is no more use for it ...
00725         this->last_entry_returned_ = 0;
00726
00727         return 1;
00728       }
00729
00730     // If there  is an entry that was returned and if there are more
00731     // threads just wake up the peer to check for the returned
00732     // connection.
00733     if (this->last_entry_returned_ &&
00734         this->no_waiting_threads_ > 1)
00735       {
00736         this->condition_->signal ();
00737       }
00738
00739     return 0;
00740   }

ACE_INLINE int TAO::Transport_Cache_Manager::make_idle ( HASH_MAP_ENTRY *& entry )

Make the entry idle and ready for use.

Definition at line 96 of file Transport_Cache_Manager.inl.

References ACE_GUARD_RETURN, and make_idle_i().

00097   {
00098     if(entry == 0)
00099       return -1;
00100
00101     ACE_MT (ACE_GUARD_RETURN (ACE_Lock, guard, *this->cache_lock_, -1));
00102     return this->make_idle_i (entry);
00103   }

int TAO::Transport_Cache_Manager::make_idle_i ( HASH_MAP_ENTRY *& entry ) [private]

Non-locking version and actual implementation of make_idle ().

Definition at line 310 of file Transport_Cache_Manager.cpp.

References condition_, TAO::ENTRY_IDLE_AND_PURGABLE, ACE_Hash_Map_Entry< EXT_ID, INT_ID >::ext_id_, ACE_Hash_Map_Entry< EXT_ID, INT_ID >::int_id_, last_entry_returned_, and TAO_Condition< MUTEX >::signal().

Referenced by make_idle().

00311   {
00312     if (entry == 0)
00313       return -1;
00314
00315     entry->int_id_.recycle_state (ENTRY_IDLE_AND_PURGABLE);
00316
00317     // Does any one need waking?
00318     if (this->no_waiting_threads_)
00319       {
00320         // We returned this entry to the map
00321         this->last_entry_returned_ = &entry->ext_id_;
00322
00323         // Wake up a thread
00324         this->condition_->signal ();
00325       }
00326
00327     return 0;
00328   }

ACE_INLINE Transport_Cache_Manager::HASH_MAP & TAO::Transport_Cache_Manager::map ( void )

Return the underlying cache map.

Definition at line 148 of file Transport_Cache_Manager.inl.

References cache_map_.

00149   {
00150     return this->cache_map_;
00151   }

ACE_INLINE void TAO::Transport_Cache_Manager::mark_invalid ( HASH_MAP_ENTRY *& )

Mark the entry as invalid for use but keep it in cache.

Definition at line 84 of file Transport_Cache_Manager.inl.

References ACE_GUARD, and mark_invalid_i().

00085   {
00086     if(entry == 0)
00087       return;
00088
00089     // Double checked locking
00090     ACE_MT (ACE_GUARD (ACE_Lock, guard, *this->cache_lock_));
00091
00092     this->mark_invalid_i (entry);
00093   }

void TAO::Transport_Cache_Manager::mark_invalid_i ( HASH_MAP_ENTRY *& ) [private]

Mark the entry as invalid for use but keep it in cache.

Definition at line 420 of file Transport_Cache_Manager.cpp.

References TAO::ENTRY_PURGABLE_BUT_NOT_IDLE, and ACE_Hash_Map_Entry< EXT_ID, INT_ID >::int_id_.

Referenced by mark_invalid().

00421   {
00422     if (entry == 0)
00423       {
00424         return;
00425       }
00426
00427     // Mark the entry as not usable
00428     entry->int_id_.recycle_state (ENTRY_PURGABLE_BUT_NOT_IDLE);
00429   }

int TAO::Transport_Cache_Manager::purge ( void )

Remove entries from the cache depending upon the strategy.

Definition at line 499 of file Transport_Cache_Manager.cpp.

References ACE_DEBUG, ACE_GUARD_RETURN, ACE_TEXT, TAO_Transport::add_reference(), TAO::ENTRY_BUSY, fill_set_i(), TAO_Transport::id(), ACE_Hash_Map_Entry< EXT_ID, INT_ID >::int_id_, ACE_Unbounded_Stack< T >::is_empty(), LM_DEBUG, LM_INFO, percent_, ACE_Unbounded_Stack< T >::pop(), ACE_Unbounded_Stack< T >::push(), and TAO_debug_level.

00500   {
00501     ACE_Unbounded_Stack<TAO_Transport*> transports_to_be_closed;
00502
00503     {
00504       ACE_MT (ACE_GUARD_RETURN (ACE_Lock, ace_mon, *this->cache_lock_, 0));
00505
00506       DESCRIPTOR_SET sorted_set = 0;
00507       int sorted_size = this->fill_set_i (sorted_set);
00508
00509       // Only call close_entries () if sorted_set != 0.  It takes
00510       // control of sorted_set and cleans up any allocated memory.  If
00511       // sorted_set == 0, then there is nothing to de-allocate.
00512       if (sorted_set != 0)
00513         {
00514           // BEGIN FORMER close_entries
00515           // Calculate the number of entries to purge
00516           int const amount = (sorted_size * this->percent_) / 100;
00517
00518           if (TAO_debug_level > 0)
00519             {
00520               ACE_DEBUG ((LM_DEBUG,
00521                           ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager::")
00522                           ACE_TEXT ("purge,  purging %d of %d cache entries\n"),
00523                           amount,
00524                           sorted_size));
00525             }
00526
00527           int count = 0;
00528
00529           for (int i = 0; count < amount && i < sorted_size; ++i)
00530             {
00531               if (this->is_entry_idle (sorted_set[i]))
00532                 {
00533                   sorted_set[i]->int_id_.recycle_state (ENTRY_BUSY);
00534
00535                   TAO_Transport* transport =
00536                     sorted_set[i]->int_id_.transport ();
00537                   transport->add_reference ();
00538
00539                   if (transports_to_be_closed.push (transport) != 0)
00540                     {
00541                       ACE_DEBUG ((LM_INFO,
00542                                   ACE_TEXT ("TAO (%P|%t) - ")
00543                                   ACE_TEXT ("Unable to push transport %u ")
00544                                   ACE_TEXT ("on the to-be-closed stack, so ")
00545                                   ACE_TEXT ("it will leak\n"),
00546                                 transport->id ()));
00547                     }
00548
00549                   if (TAO_debug_level > 0)
00550                     {
00551                       ACE_DEBUG ((LM_DEBUG, ACE_TEXT ("TAO (%P|%t) - ")
00552                                   ACE_TEXT ("Idle transport found in ")
00553                                   ACE_TEXT ("cache: [%d] \n"),
00554                                   transport->id ()));
00555                     }
00556
00557                   // Count this as a successful purged entry
00558                   ++count;
00559                 }
00560             }
00561
00562           delete [] sorted_set;
00563           sorted_set = 0;
00564           // END FORMER close_entries
00565         }
00566     }
00567
00568     // Now, without the lock held, lets go through and close all the transports.
00569     TAO_Transport *transport = 0;
00570
00571     while (! transports_to_be_closed.is_empty ())
00572       {
00573         if (transports_to_be_closed.pop (transport) == 0)
00574           {
00575             if (transport)
00576               {
00577                 transport->close_connection ();
00578                 transport->remove_reference ();
00579               }
00580           }
00581       }
00582
00583 #if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1)
00584     /// The value doesn't matter, all we need is the timestamp,
00585     /// which is added automatically.
00586     this->purge_monitor_->receive (static_cast<size_t> (0UL));
00587     /// And update the size monitor as well.
00588     this->size_monitor_->receive (this->current_size ());
00589 #endif /* TAO_HAS_MONITOR_POINTS==1 */
00590
00591     return 0;
00592   }

ACE_INLINE int TAO::Transport_Cache_Manager::purge_entry ( HASH_MAP_ENTRY *& )

Purge the entry from the Cache Map.

Definition at line 72 of file Transport_Cache_Manager.inl.

References ACE_GUARD_RETURN, and purge_entry_i().

00073   {
00074     // Double checked locking
00075     if(entry == 0)
00076       return 0;
00077
00078     ACE_MT (ACE_GUARD_RETURN (ACE_Lock, guard, *this->cache_lock_, -1));
00079
00080     return this->purge_entry_i (entry);
00081   }

int TAO::Transport_Cache_Manager::purge_entry_i ( HASH_MAP_ENTRY *& entry ) [private]

Purge the entry from the Cache Map.

Definition at line 399 of file Transport_Cache_Manager.cpp.

References cache_map_, and ACE_Hash_Map_Manager_Ex< EXT_ID, INT_ID, HASH_KEY, COMPARE_KEYS, ACE_LOCK >::unbind().

Referenced by purge_entry().

00400   {
00401     if (entry == 0)
00402       {
00403         return 0;
00404       }
00405
00406     // Remove the entry from the Map
00407     int const retval = this->cache_map_.unbind (entry);
00408
00409     // Set the entry pointer to zero
00410     entry = 0;
00411
00412 #if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1)
00413     this->size_monitor_->receive (this->current_size ());
00414 #endif /* TAO_HAS_MONITOR_POINTS==1 */
00415
00416     return retval;
00417   }

void TAO::Transport_Cache_Manager::sort_set	(	DESCRIPTOR_SET &	entries,
		int	size
	)			`[private]`

Sort the list of entries.

Definition at line 596 of file Transport_Cache_Manager.cpp.

References cpscmp(), ACE_Hash_Map_Entry< EXT_ID, INT_ID >::int_id_, and ACE_OS::qsort().

Referenced by fill_set_i().

00598   {
00599 #if defined (ACE_LACKS_QSORT)
00600     // Use insertion sort if we don't have qsort
00601     for(int i = 1; i < current_size; ++i)
00602       {
00603         if (entries[i]->int_id_.transport ()->purging_order () <
00604             entries[i - 1]->int_id_.transport ()->purging_order ())
00605           {
00606             HASH_MAP_ENTRY* entry = entries[i];
00607
00608             for(int j = i; j > 0 &&
00609                   entries[j - 1]->int_id_.transport ()->purging_order () >
00610                   entry->int_id_.transport ()->purging_order (); --j)
00611               {
00612                 HASH_MAP_ENTRY* holder = entries[j];
00613                 entries[j] = entries[j - 1];
00614                 entries[j - 1] = holder;
00615               }
00616           }
00617       }
00618 #else
00619     ACE_OS::qsort (entries, current_size,
00620                    sizeof (HASH_MAP_ENTRY*), (ACE_COMPARE_FUNC)cpscmp);
00621 #endif /* ACE_LACKS_QSORT */
00622   }

ACE_INLINE size_t TAO::Transport_Cache_Manager::total_size ( void ) const

Return the total size of the cache.

Definition at line 142 of file Transport_Cache_Manager.inl.

References cache_map_, and ACE_Hash_Map_Manager_Ex< EXT_ID, INT_ID, HASH_KEY, COMPARE_KEYS, ACE_LOCK >::total_size().

00143   {
00144     return this->cache_map_.total_size ();
00145   }

int TAO::Transport_Cache_Manager::update_entry ( HASH_MAP_ENTRY *& entry )

Mark the entry as touched. This call updates the purging strategy policy information.

Definition at line 331 of file Transport_Cache_Manager.cpp.

References ACE_GUARD_RETURN, ACE_Hash_Map_Entry< EXT_ID, INT_ID >::int_id_, purging_strategy_, and TAO_Connection_Purging_Strategy::update_item().

00332   {
00333     if(entry == 0)
00334       return -1;
00335
00336     ACE_MT (ACE_GUARD_RETURN (ACE_Lock,
00337                               guard,
00338                               *this->cache_lock_, -1));
00339
00340     if (entry == 0)
00341       return -1;
00342
00343     TAO_Connection_Purging_Strategy *st = this->purging_strategy_;
00344     (void) st->update_item (entry->int_id_.transport ());
00345
00346     return 0;
00347   }

int TAO::Transport_Cache_Manager::wait_for_connection ( Cache_ExtId & extid ) [private]

Wait for connections if we have reached the limit on the number of muxed connections. If not (ie. if we dont use a muxed connection or if we have not reached the limit) this just behaves as a no-op. <extid> has all the information about the connection that is being searched.

Definition at line 668 of file Transport_Cache_Manager.cpp.

References ACE_DEBUG, ACE_TEXT, condition_, TAO::Cache_ExtId::index(), is_wakeup_useful(), LM_DEBUG, no_waiting_threads_, TAO_debug_level, and TAO_Condition< MUTEX >::wait().

Referenced by find_i().

00669   {
00670     if (this->muxed_number_ && this->muxed_number_ == extid.index ())
00671       {
00672         // If we have a limit on the number of muxed connections for
00673         // a particular endpoint just wait to get the connection
00674         ++this->no_waiting_threads_;
00675
00676         if (TAO_debug_level > 2)
00677           {
00678             ACE_DEBUG ((LM_DEBUG,
00679                         ACE_TEXT("TAO (%P|%t) - Transport_Cache_Manager")
00680                         ACE_TEXT("::wait_for_connection, ")
00681                         ACE_TEXT("entering wait loop\n")));
00682           }
00683
00684         int ready_togo = 0;
00685
00686         while (ready_togo == 0)
00687           {
00688             this->condition_->wait ();
00689
00690             // Check whether we are waiting for this connection
00691             ready_togo = this->is_wakeup_useful (extid);
00692           }
00693
00694         if (TAO_debug_level > 2)
00695           {
00696             ACE_DEBUG ((LM_DEBUG,
00697                         ACE_TEXT("TAO (%P|%t) - Transport_Cache_Manager::wait_for_connection, ")
00698                         ACE_TEXT("left wait loop\n")));
00699           }
00700
00701         // We are not waiting anymore
00702         --this->no_waiting_threads_;
00703       }
00704
00705     return 0;
00706   }

ACE_Lock* TAO::Transport_Cache_Manager::cache_lock_ [private]

The lock that is used by the cache map.

Definition at line 255 of file Transport_Cache_Manager.h.

Referenced by ~Transport_Cache_Manager().

HASH_MAP TAO::Transport_Cache_Manager::cache_map_ [private]

The hash map that has the connections.

Definition at line 249 of file Transport_Cache_Manager.h.

Referenced by bind_i(), blockable_client_transports_i(), close_i(), current_size(), fill_set_i(), find_i(), get_last_index_bind(), map(), purge_entry_i(), and total_size().

CONDITION* TAO::Transport_Cache_Manager::condition_ [private]

The condition variable.

Definition at line 252 of file Transport_Cache_Manager.h.

Referenced by is_wakeup_useful(), make_idle_i(), wait_for_connection(), and ~Transport_Cache_Manager().

Cache_ExtId* TAO::Transport_Cache_Manager::last_entry_returned_ [private]

This is for optimization purposes. In a situation where number of threads are waiting for connections, the last connection that is put back is cached here. This should prevent all th threads trying to search for their required entry.

Definition at line 267 of file Transport_Cache_Manager.h.

Referenced by is_wakeup_useful(), and make_idle_i().

CORBA::ULong TAO::Transport_Cache_Manager::muxed_number_ [private]

Number of allowed muxed connections.

Definition at line 258 of file Transport_Cache_Manager.h.

Referenced by Transport_Cache_Manager().

int TAO::Transport_Cache_Manager::no_waiting_threads_ [private]

Number of threads waiting for connections.

Definition at line 261 of file Transport_Cache_Manager.h.

Referenced by wait_for_connection().

int TAO::Transport_Cache_Manager::percent_ [private]

The percentage of the cache to purge at one time.

Definition at line 243 of file Transport_Cache_Manager.h.

Referenced by purge().

TAO_Connection_Purging_Strategy* TAO::Transport_Cache_Manager::purging_strategy_ [private]

The underlying connection purging strategy.

Definition at line 246 of file Transport_Cache_Manager.h.

Referenced by bind_i(), fill_set_i(), find(), update_entry(), and ~Transport_Cache_Manager().

TAO::Transport_Cache_Manager Class Reference

Public Types

Public Member Functions

Private Types

Private Member Functions

Static Private Member Functions

Private Attributes

Detailed Description

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation


Public Types
typedef ACE_Hash_Map_Manager_Ex< Cache_ExtId, Cache_IntId, ACE_Hash< Cache_ExtId >, ACE_Equal_To< Cache_ExtId >, ACE_Null_Mutex >	HASH_MAP
typedef HASH_MAP::iterator	HASH_MAP_ITER
typedef ACE_Hash_Map_Entry< Cache_ExtId, Cache_IntId >	HASH_MAP_ENTRY
typedef TAO_Condition< TAO_SYNCH_MUTEX >	CONDITION
Public Member Functions
	Transport_Cache_Manager (TAO_ORB_Core &orb_core)
	Constructor.
	~Transport_Cache_Manager (void)
	Destructor.
int	cache_transport (TAO_Transport_Descriptor_Interface prop, TAO_Transport transport)
	Add the transport to the cache.
int	cache_idle_transport (TAO_Transport_Descriptor_Interface prop, TAO_Transport transport)
int	find_transport (TAO_Transport_Descriptor_Interface prop, TAO_Transport &transport)
int	purge (void)
	Remove entries from the cache depending upon the strategy.
int	purge_entry (HASH_MAP_ENTRY *&)
	Purge the entry from the Cache Map.
void	mark_invalid (HASH_MAP_ENTRY *&)
	Mark the entry as invalid for use but keep it in cache.
int	make_idle (HASH_MAP_ENTRY *&entry)
	Make the entry idle and ready for use.
int	update_entry (HASH_MAP_ENTRY *&entry)
int	close (Connection_Handler_Set &handlers)
bool	blockable_client_transports (Connection_Handler_Set &handlers)
size_t	current_size (void) const
	Return the current size of the cache.
size_t	total_size (void) const
	Return the total size of the cache.
HASH_MAP &	map (void)
	Return the underlying cache map.
Private Types
typedef HASH_MAP_ENTRY **	DESCRIPTOR_SET
Private Member Functions
int	bind (Cache_ExtId &ext_id, Cache_IntId &int_id)
int	find (const Cache_ExtId &key, Cache_IntId &value)
int	bind_i (Cache_ExtId &ext_id, Cache_IntId &int_id)
int	find_i (const Cache_ExtId &key, Cache_IntId &value)
int	make_idle_i (HASH_MAP_ENTRY *&entry)
	Non-locking version and actual implementation of make_idle ().
int	close_i (Connection_Handler_Set &handlers)
	Non-locking version and actual implementation of close ().
int	purge_entry_i (HASH_MAP_ENTRY *&entry)
	Purge the entry from the Cache Map.
void	mark_invalid_i (HASH_MAP_ENTRY *&)
	Mark the entry as invalid for use but keep it in cache.
int	get_last_index_bind (Cache_ExtId &key, Cache_IntId &val, HASH_MAP_ENTRY *&entry)
bool	is_entry_idle (HASH_MAP_ENTRY *&entry)
void	sort_set (DESCRIPTOR_SET &entries, int size)
	Sort the list of entries.
int	fill_set_i (DESCRIPTOR_SET &sorted_set)
int	wait_for_connection (Cache_ExtId &extid)
int	is_wakeup_useful (Cache_ExtId &extid)
	Is the wakeup useful todo some work?
bool	blockable_client_transports_i (Connection_Handler_Set &handlers)
	Non-locking version of blockable_client_transports ().
Static Private Member Functions
static int	cpscmp (const void a, const void b)
	Used by qsort.
Private Attributes
int	percent_
	The percentage of the cache to purge at one time.
TAO_Connection_Purging_Strategy *	purging_strategy_
	The underlying connection purging strategy.
HASH_MAP	cache_map_
	The hash map that has the connections.
CONDITION *	condition_
	The condition variable.
ACE_Lock *	cache_lock_
	The lock that is used by the cache map.
CORBA::ULong	muxed_number_
	Number of allowed muxed connections.
int	no_waiting_threads_
	Number of threads waiting for connections.
Cache_ExtId *	last_entry_returned_
