Direct base class for the ACE_Task template. More...
#include <Task.h>
Public Member Functions | |
| ACE_Task_Base (ACE_Thread_Manager *=0) | |
| Constructor. | |
| virtual | ~ACE_Task_Base (void) |
| Destructor. | |
| virtual int | open (void *args=0) |
| virtual int | close (u_long flags=0) |
| virtual int | module_closed (void) |
| virtual int | put (ACE_Message_Block *, ACE_Time_Value *=0) |
| virtual int | svc (void) |
| Run by a daemon thread to handle deferred processing. | |
| virtual int | activate (long flags=THR_NEW_LWP|THR_JOINABLE|THR_INHERIT_SCHED, int n_threads=1, int force_active=0, long priority=ACE_DEFAULT_THREAD_PRIORITY, int grp_id=-1, ACE_Task_Base *task=0, ACE_hthread_t thread_handles[]=0, void *stack[]=0, size_t stack_size[]=0, ACE_thread_t thread_ids[]=0, const char *thr_name[]=0) |
| virtual int | wait (void) |
| virtual int | suspend (void) |
| Suspend a task. | |
| virtual int | resume (void) |
| Resume a suspended task. | |
| int | grp_id (void) const |
| Get the current group id. | |
| void | grp_id (int) |
| Set the current group id. | |
| ACE_Thread_Manager * | thr_mgr (void) const |
| Get the thread manager associated with this Task. | |
| void | thr_mgr (ACE_Thread_Manager *) |
| Set the thread manager associated with this Task. | |
| int | is_reader (void) const |
| True if queue is a reader, else false. | |
| int | is_writer (void) const |
| True if queue is a writer, else false. | |
| size_t | thr_count (void) const |
| ACE_thread_t | last_thread (void) const |
Static Public Member Functions | |
| static ACE_THR_FUNC_RETURN | svc_run (void *) |
| Routine that runs the service routine as a daemon thread. | |
| static void | cleanup (void *object, void *params) |
Protected Attributes | |
| size_t | thr_count_ |
| ACE_Thread_Manager * | thr_mgr_ |
| Multi-threading manager. | |
| u_long | flags_ |
| ACE_Task flags. | |
| int | grp_id_ |
| This maintains the group id of the Task. | |
| ACE_thread_t | last_thread_id_ |
| Holds the thread ID of the last thread to exit svc() in this object. | |
Private Member Functions | |
| ACE_Task_Base & | operator= (const ACE_Task_Base &) |
| ACE_Task_Base (const ACE_Task_Base &) | |
Direct base class for the ACE_Task template.
This class factors out the non-template code in order to reduce template bloat, as well as to make it possible for the ACE_Thread_Manager to store ACE_Task_Base *'s polymorphically.
Definition at line 66 of file Task.h.
| ACE_Task_Base::ACE_Task_Base | ( | ACE_Thread_Manager * | = 0 |
) |
Constructor.
| ACE_Task_Base::~ACE_Task_Base | ( | void | ) | [virtual] |
| ACE_Task_Base::ACE_Task_Base | ( | const ACE_Task_Base & | ) | [private] |
| int ACE_Task_Base::activate | ( | long | flags = THR_NEW_LWP | THR_JOINABLE | THR_INHERIT_SCHED, |
|
| int | n_threads = 1, |
|||
| int | force_active = 0, |
|||
| long | priority = ACE_DEFAULT_THREAD_PRIORITY, |
|||
| int | grp_id = -1, |
|||
| ACE_Task_Base * | task = 0, |
|||
| ACE_hthread_t | thread_handles[] = 0, |
|||
| void * | stack[] = 0, |
|||
| size_t | stack_size[] = 0, |
|||
| ACE_thread_t | thread_ids[] = 0, |
|||
| const char * | thr_name[] = 0 | |||
| ) | [virtual] |
Turn the task into an active object, i.e., having n_threads of control, all running at the priority level (see below) with the same grp_id, all of which invoke <Task::svc>. Returns -1 if failure occurs, returns 1 if Task is already an active object and force_active is false (i.e., do *not* create a new thread in this case), and returns 0 if Task was not already an active object and a thread is created successfully or thread is an active object and force_active is true. Note that if force_active is true and there are already threads spawned in this <Task>, the grp_id parameter is ignored and the grp_id of any newly activated thread(s) will inherit the existing grp_id of the existing thread(s) in the <Task>.
The <{flags}> are a bitwise-OR of the following: = BEGIN<INDENT> THR_CANCEL_DISABLE, THR_CANCEL_ENABLE, THR_CANCEL_DEFERRED, THR_CANCEL_ASYNCHRONOUS, THR_BOUND, THR_NEW_LWP, THR_DETACHED, THR_SUSPENDED, THR_DAEMON, THR_JOINABLE, THR_SCHED_FIFO, THR_SCHED_RR, THR_SCHED_DEFAULT, THR_EXPLICIT_SCHED, THR_SCOPE_SYSTEM, THR_SCOPE_PROCESS = END<INDENT> If THR_SCHED_INHERIT is not desirable, applications should specifically pass in THR_EXPLICIT_SCHED.
By default, or if <{priority}> is set to ACE_DEFAULT_THREAD_PRIORITY, an "appropriate" priority value for the given scheduling policy (specified in <{flags}>, e.g., <THR_SCHED_DEFAULT>) is used. This value is calculated dynamically, and is the median value between the minimum and maximum priority values for the given policy. If an explicit value is given, it is used. Note that actual priority values are EXTREMEMLY implementation-dependent, and are probably best avoided.
If thread_handles != 0 it is assumed to be an array of n thread_handles that will be assigned the values of the thread handles being spawned. Returns -1 on failure (errno will explain...), otherwise returns the group id of the threads.
Assigning task allows you to associate the newly spawned threads with an instance of ACE_Task_Base. If task == 0, then the new threads are associated automatically with this ACE_Task_Base. Setting the task argument to value other than this makes the thread manipulating methods, such as wait(), suspend(), resume(), useless. Threads spawned with user specified task value must therefore be manipulated thru ACE_Thread_Manager directly.
If stack != 0 it is assumed to be an array of n pointers to the base of the stacks to use for the threads being spawned. Likewise, if stack_size != 0 it is assumed to be an array of n values indicating how big each of the corresponding stacks are.
Reimplemented in ACE_Thread_Timer_Queue_Adapter< TQ, TYPE >.
Definition at line 120 of file Task.cpp.
{
ACE_TRACE ("ACE_Task_Base::activate");
#if defined (ACE_MT_SAFE) && (ACE_MT_SAFE != 0)
ACE_GUARD_RETURN (ACE_Thread_Mutex, ace_mon, this->lock_, -1);
// If the task passed in is zero, we will use <this>
if (task == 0)
task = this;
if (this->thr_count_ > 0 && force_active == 0)
return 1; // Already active.
else
{
if (this->thr_count_ > 0 && this->grp_id_ != -1)
// If we're joining an existing group of threads then make
// sure to use its group id.
grp_id = this->grp_id_;
this->thr_count_ += n_threads;
}
// Use the ACE_Thread_Manager singleton if we're running as an
// active object and the caller didn't supply us with a
// Thread_Manager.
if (this->thr_mgr_ == 0)
# if defined (ACE_THREAD_MANAGER_LACKS_STATICS)
this->thr_mgr_ = ACE_THREAD_MANAGER_SINGLETON::instance ();
# else /* ! ACE_THREAD_MANAGER_LACKS_STATICS */
this->thr_mgr_ = ACE_Thread_Manager::instance ();
# endif /* ACE_THREAD_MANAGER_LACKS_STATICS */
int grp_spawned = -1;
if (thread_ids == 0)
// Thread Ids were not specified
grp_spawned =
this->thr_mgr_->spawn_n (n_threads,
&ACE_Task_Base::svc_run,
(void *) this,
flags,
priority,
grp_id,
task,
thread_handles,
stack,
stack_size,
thr_name);
else
// thread names were specified
grp_spawned =
this->thr_mgr_->spawn_n (thread_ids,
n_threads,
&ACE_Task_Base::svc_run,
(void *) this,
flags,
priority,
grp_id,
stack,
stack_size,
thread_handles,
task,
thr_name);
if (grp_spawned == -1)
{
// If spawn_n fails, restore original thread count.
this->thr_count_ -= n_threads;
return -1;
}
if (this->grp_id_ == -1)
this->grp_id_ = grp_spawned;
#if defined (ACE_MVS) || defined(__TANDEM)
ACE_OS::memcpy( &this->last_thread_id_, '\0', sizeof(this->last_thread_id_));
#else
this->last_thread_id_ = 0; // Reset to prevent inadvertant match on ID
#endif /* defined (ACE_MVS) */
return 0;
#else
{
// Keep the compiler from complaining.
ACE_UNUSED_ARG (flags);
ACE_UNUSED_ARG (n_threads);
ACE_UNUSED_ARG (force_active);
ACE_UNUSED_ARG (priority);
ACE_UNUSED_ARG (grp_id);
ACE_UNUSED_ARG (task);
ACE_UNUSED_ARG (thread_handles);
ACE_UNUSED_ARG (stack);
ACE_UNUSED_ARG (stack_size);
ACE_UNUSED_ARG (thread_ids);
ACE_UNUSED_ARG (thr_name);
ACE_NOTSUP_RETURN (-1);
}
#endif /* ACE_MT_SAFE */
}
| void ACE_Task_Base::cleanup | ( | void * | object, | |
| void * | params | |||
| ) | [static] |
Cleanup hook that is called when a thread exits to gracefully shutdown an ACE_Task.
Definition at line 230 of file Task.cpp.
{
ACE_Task_Base *t = (ACE_Task_Base *) object;
// The thread count must be decremented first in case the <close>
// hook does something crazy like "delete this".
{
ACE_MT (ACE_GUARD (ACE_Thread_Mutex, ace_mon, t->lock_));
t->thr_count_--;
if (0 == t->thr_count_)
t->last_thread_id_ = ACE_Thread::self ();
}
// @@ Is it possible to pass in the exit status somehow?
t->close ();
// t is undefined here. close() could have deleted it.
}
| int ACE_Task_Base::close | ( | u_long | flags = 0 |
) | [virtual] |
Hook called from ACE_Thread_Exit when during thread exit and from the default implementation of module_closed(). In general, this method shouldn't be called directly by an application, particularly if the Task is running as an Active Object. Instead, a special message should be passed into the Task via the put() method defined below, and the svc() method should interpret this as a flag to shut down the Task.
Reimplemented in ACE_Stream_Head< ACE_SYNCH_DECL >, ACE_Stream_Tail< ACE_SYNCH_DECL >, ACE_Thru_Task< ACE_SYNCH_DECL >, ACE_Svc_Handler< ACE_PEER_STREAM_1, ACE_SYNCH_DECL >, and ACE_Svc_Handler< ACE_PEER_STREAM_2, ACE_SYNCH_USE >.
Definition at line 56 of file Task.cpp.
{
ACE_TRACE ("ACE_Task_Base::close");
return 0;
}
| int ACE_Task_Base::grp_id | ( | void | ) | const |
Get the current group id.
Definition at line 9 of file Task.inl.
{
ACE_TRACE ("ACE_Task_Base::grp_id");
ACE_MT (ACE_GUARD_RETURN (ACE_Thread_Mutex, ace_mon, const_cast <ACE_Thread_Mutex&>(this->lock_), -1));
return this->grp_id_;
}
| void ACE_Task_Base::grp_id | ( | int | identifier | ) |
Set the current group id.
| int ACE_Task_Base::is_reader | ( | void | ) | const |
True if queue is a reader, else false.
Definition at line 46 of file Task.inl.
{
ACE_TRACE ("ACE_Task_Base::is_reader");
return (ACE_BIT_ENABLED (this->flags_, ACE_Task_Flags::ACE_READER));
}
| int ACE_Task_Base::is_writer | ( | void | ) | const |
True if queue is a writer, else false.
Definition at line 53 of file Task.inl.
{
ACE_TRACE ("ACE_Task_Base::is_writer");
return (ACE_BIT_DISABLED (this->flags_, ACE_Task_Flags::ACE_READER));
}
| ACE_thread_t ACE_Task_Base::last_thread | ( | void | ) | const |
Returns the thread ID of the thread whose exit caused this object's thread count to be decremented to 0.
When a thread spawned in the context of this object (using activate()) returns from its svc() method ACE calls the close() hook. Before it does so, it decrements the number of active threads. If the number of threads is decremented to 0, the thread ID of the current thread is stored for access by this method. If the returned thread ID matches the calling thread's ID, the calling thread knows that there are no other threads still active in the ACE_Task.
| ACE_thread_t | of the last thread to close. 0 if the last thread is not yet known; for example, if no threads are active, or if multiple threads are active. |
Definition at line 71 of file Task.inl.
{
ACE_TRACE ("ACE_Task_Base::last_thread");
return this->last_thread_id_;
}
| int ACE_Task_Base::module_closed | ( | void | ) | [virtual] |
Hook called during ACE_Module::close(). The default implementation calls forwards the call to close(1). Please notice the changed value of the default argument of close(). This allows tasks to differ between the call has been originated from ACE_Thread_Exit or from module_closed(). Be aware that close(0) will be also called when a thread associated with the ACE_Task instance exits.
Definition at line 66 of file Task.cpp.
{
return this->close (1);
}
| int ACE_Task_Base::open | ( | void * | args = 0 |
) | [virtual] |
Hook called to initialize a task and prepare it for execution. args can be used to pass arbitrary information into <open>.
Reimplemented in ACE_Stream_Head< ACE_SYNCH_DECL >, ACE_Stream_Tail< ACE_SYNCH_DECL >, ACE_Thru_Task< ACE_SYNCH_DECL >, ACE_Svc_Handler< ACE_PEER_STREAM_1, ACE_SYNCH_DECL >, and ACE_Svc_Handler< ACE_PEER_STREAM_2, ACE_SYNCH_USE >.
Definition at line 47 of file Task.cpp.
{
ACE_TRACE ("ACE_Task_Base::open");
return 0;
}
| ACE_Task_Base& ACE_Task_Base::operator= | ( | const ACE_Task_Base & | ) | [private] |
| int ACE_Task_Base::put | ( | ACE_Message_Block * | , | |
| ACE_Time_Value * | = 0 | |||
| ) | [virtual] |
A hook method that can be used to pass a message to a task, where it can be processed immediately or queued for subsequent processing in the svc() hook method.
Reimplemented in ACE_Stream_Head< ACE_SYNCH_DECL >, ACE_Stream_Tail< ACE_SYNCH_DECL >, ACE_Thru_Task< ACE_SYNCH_DECL >, and ACE_Buffered_Svc_Handler< ACE_PEER_STREAM_1, ACE_SYNCH_DECL >.
Definition at line 74 of file Task.cpp.
{
ACE_TRACE ("ACE_Task_Base::put");
return 0;
}
| int ACE_Task_Base::resume | ( | void | ) | [virtual] |
Resume a suspended task.
Reimplemented from ACE_Service_Object.
Definition at line 109 of file Task.cpp.
{
ACE_TRACE ("ACE_Task_Base::resume");
ACE_MT (ACE_GUARD_RETURN (ACE_Thread_Mutex, ace_mon, this->lock_, -1));
if (this->thr_count_ > 0)
return this->thr_mgr_->resume_task (this);
return 0;
}
| int ACE_Task_Base::suspend | ( | void | ) | [virtual] |
Suspend a task.
Reimplemented from ACE_Service_Object.
Definition at line 97 of file Task.cpp.
{
ACE_TRACE ("ACE_Task_Base::suspend");
ACE_MT (ACE_GUARD_RETURN (ACE_Thread_Mutex, ace_mon, this->lock_, -1));
if (this->thr_count_ > 0)
return this->thr_mgr_->suspend_task (this);
return 0;
}
| int ACE_Task_Base::svc | ( | void | ) | [virtual] |
Run by a daemon thread to handle deferred processing.
Reimplemented in ACE_Asynch_Pseudo_Task, ACE_Stream_Head< ACE_SYNCH_DECL >, ACE_Stream_Tail< ACE_SYNCH_DECL >, ACE_Thru_Task< ACE_SYNCH_DECL >, and ACE_Thread_Timer_Queue_Adapter< TQ, TYPE >.
Definition at line 38 of file Task.cpp.
{
ACE_TRACE ("ACE_Task_Base::svc");
return 0;
}
| ACE_THR_FUNC_RETURN ACE_Task_Base::svc_run | ( | void * | args | ) | [static] |
Routine that runs the service routine as a daemon thread.
Definition at line 258 of file Task.cpp.
{
ACE_TRACE ("ACE_Task_Base::svc_run");
ACE_Task_Base *t = (ACE_Task_Base *) args;
// Register ourself with our <Thread_Manager>'s thread exit hook
// mechanism so that our close() hook will be sure to get invoked
// when this thread exits.
#if defined ACE_HAS_SIG_C_FUNC
t->thr_mgr ()->at_exit (t, ACE_Task_Base_cleanup, 0);
#else
t->thr_mgr ()->at_exit (t, ACE_Task_Base::cleanup, 0);
#endif /* ACE_HAS_SIG_C_FUNC */
// Call the Task's svc() hook method.
int const svc_status = t->svc ();
ACE_THR_FUNC_RETURN status;
#if defined (ACE_HAS_INTEGRAL_TYPE_THR_FUNC_RETURN)
// Reinterpret case between integral types is not mentioned in the C++ spec
status = static_cast<ACE_THR_FUNC_RETURN> (svc_status);
#else
status = reinterpret_cast<ACE_THR_FUNC_RETURN> (svc_status);
#endif /* ACE_HAS_INTEGRAL_TYPE_THR_FUNC_RETURN */
// If we changed this zero change the other if in OS.cpp Thread_Adapter::invoke
#if 1
// Call the <Task->close> hook.
ACE_Thread_Manager *thr_mgr_ptr = t->thr_mgr ();
// This calls the Task->close () hook.
t->cleanup (t, 0);
// This prevents a second invocation of the cleanup code
// (called later by <ACE_Thread_Manager::exit>.
thr_mgr_ptr->at_exit (t, 0, 0);
#endif
return status;
}
| size_t ACE_Task_Base::thr_count | ( | void | ) | const |
Returns the number of threads currently running within a task. If we're a passive object this value is 0, else it's greater than 0.
Definition at line 61 of file Task.inl.
{
ACE_TRACE ("ACE_Task_Base::thr_count");
ACE_MT (ACE_GUARD_RETURN (ACE_Thread_Mutex, ace_mon, const_cast <ACE_Thread_Mutex&>(this->lock_), 0));
return this->thr_count_;
}
| ACE_Thread_Manager * ACE_Task_Base::thr_mgr | ( | void | ) | const |
| void ACE_Task_Base::thr_mgr | ( | ACE_Thread_Manager * | thr_mgr | ) |
| int ACE_Task_Base::wait | ( | void | ) | [virtual] |
Block until there are no more threads running in this task. This method will not wait for either detached or daemon threads; the threads must have been spawned with the THR_JOINABLE flag. Upon successful completion, the threads have been joined, so further attempts to join with any of the waited-for threads will fail.
| 0 | Success. | |
| -1 | Failure (consult errno for further information). |
u_long ACE_Task_Base::flags_ [protected] |
int ACE_Task_Base::grp_id_ [protected] |
ACE_thread_t ACE_Task_Base::last_thread_id_ [protected] |
size_t ACE_Task_Base::thr_count_ [protected] |
ACE_Thread_Manager* ACE_Task_Base::thr_mgr_ [protected] |
1.7.0
