The Transport Cache Manager for TAO. More...
#include <Transport_Cache_Manager_T.h>
Public Types | |
| enum | Find_Result { CACHE_FOUND_NONE, CACHE_FOUND_CONNECTING, CACHE_FOUND_BUSY, CACHE_FOUND_AVAILABLE } |
results of a find More... | |
| typedef TT | transport_type |
| typedef TRDT | transport_descriptor_type |
| typedef PSTRAT | purging_strategy |
| typedef Cache_ExtId_T < transport_descriptor_type > | Cache_ExtId |
| typedef Cache_IntId_T < transport_type > | Cache_IntId |
| typedef ACE_Hash_Map_Manager_Ex < Cache_ExtId, Cache_IntId, ACE_Hash< Cache_ExtId > , ACE_Equal_To< Cache_ExtId > , ACE_Null_Mutex > | HASH_MAP |
| typedef HASH_MAP::iterator | HASH_MAP_ITER |
| typedef ACE_Hash_Map_Entry < Cache_ExtId, Cache_IntId > | HASH_MAP_ENTRY |
| typedef TAO_Condition < TAO_SYNCH_MUTEX > | CONDITION |
Public Member Functions | |
| Transport_Cache_Manager_T (int percent, purging_strategy *purging_strategy, size_t cache_maximum, bool locked, const char *orbid) | |
| Constructor. | |
| ~Transport_Cache_Manager_T (void) | |
| Destructor. | |
| int | cache_transport (transport_descriptor_type *prop, transport_type *transport, Cache_Entries_State state=ENTRY_IDLE_AND_PURGABLE) |
| Add the transport to the cache. | |
| Find_Result | find_transport (transport_descriptor_type *prop, transport_type *&transport, size_t &busy_count) |
| int | purge (void) |
| Remove entries from the cache depending upon the strategy. | |
| int | purge_entry (HASH_MAP_ENTRY *&entry) |
| Purge the entry from the Cache Map. | |
| void | mark_invalid (HASH_MAP_ENTRY *entry) |
| Mark the entry as invalid for use but keep it in cache. | |
| void | mark_connected (HASH_MAP_ENTRY *entry, bool state) |
| Mark the entry as connected. | |
| int | make_idle (HASH_MAP_ENTRY *entry) |
| Make the entry idle and ready for use. | |
| void | set_entry_state (HASH_MAP_ENTRY *entry, TAO::Cache_Entries_State state) |
| Modify the state setting on the provided entry. | |
| int | update_entry (HASH_MAP_ENTRY *&entry) |
| int | close (Connection_Handler_Set &handlers) |
| bool | blockable_client_transports (Connection_Handler_Set &handlers) |
| size_t | current_size (void) const |
| Return the current size of the cache. | |
| size_t | total_size (void) const |
| Return the total size of the cache. | |
| HASH_MAP & | map (void) |
| Return the underlying cache map. | |
Private Types | |
| typedef HASH_MAP_ENTRY ** | DESCRIPTOR_SET |
Private Member Functions | |
| Find_Result | find (transport_descriptor_type *prop, transport_type *&transport, size_t &busy_count) |
| int | bind_i (Cache_ExtId &ext_id, Cache_IntId &int_id) |
| Find_Result | find_i (transport_descriptor_type *prop, transport_type *&transport, size_t &busy_count) |
| int | make_idle_i (HASH_MAP_ENTRY *entry) |
| Non-locking version and actual implementation of make_idle (). | |
| int | close_i (Connection_Handler_Set &handlers) |
| Non-locking version and actual implementation of close (). | |
| int | purge_entry_i (HASH_MAP_ENTRY *&entry) |
| Purge the entry from the Cache Map. | |
| void | mark_invalid_i (HASH_MAP_ENTRY *entry) |
| Mark the entry as invalid for use but keep it in cache. | |
| bool | is_entry_available_i (const HASH_MAP_ENTRY &entry) |
| bool | is_entry_connecting_i (const HASH_MAP_ENTRY &entry) |
| bool | is_entry_purgable_i (HASH_MAP_ENTRY &entry) |
| void | sort_set (DESCRIPTOR_SET &entries, int size) |
| Sort the list of entries. | |
| int | fill_set_i (DESCRIPTOR_SET &sorted_set) |
| bool | blockable_client_transports_i (Connection_Handler_Set &handlers) |
| Non-locking version of blockable_client_transports (). | |
Static Private Member Functions | |
| static int | cpscmp (const void *a, const void *b) |
| Used by qsort. | |
Private Attributes | |
| int | percent_ |
| The percentage of the cache to purge at one time. | |
| purging_strategy * | purging_strategy_ |
| The underlying connection purging strategy. | |
| HASH_MAP | cache_map_ |
| The hash map that has the connections. | |
| TAO_SYNCH_MUTEX | cache_map_mutex_ |
| ACE_Lock * | cache_lock_ |
| The lock that is used by the cache map. | |
| size_t | cache_maximum_ |
| Maximum size of the cache. | |
The Transport Cache Manager for TAO.
This class provides interfaces associating a TAO_Cache_ExtId & TAO_Cache_IntId. This class is wrapper around the ACE_Hash_Map_Manager class which is used as a container to Cache the connections. This class protects the entries with a lock. The map is updated only by holding the lock. The more compelling reason to have the lock in this class and not in the Hash_Map is that, we do quite a bit of work in this class for which we need a lock.
Definition at line 62 of file Transport_Cache_Manager_T.h.
| typedef Cache_ExtId_T<transport_descriptor_type> TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::Cache_ExtId |
Definition at line 78 of file Transport_Cache_Manager_T.h.
| typedef Cache_IntId_T<transport_type> TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::Cache_IntId |
Definition at line 79 of file Transport_Cache_Manager_T.h.
| typedef TAO_Condition<TAO_SYNCH_MUTEX> TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::CONDITION |
Definition at line 95 of file Transport_Cache_Manager_T.h.
typedef HASH_MAP_ENTRY** TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::DESCRIPTOR_SET [private] |
Definition at line 235 of file Transport_Cache_Manager_T.h.
| typedef ACE_Hash_Map_Manager_Ex<Cache_ExtId, Cache_IntId, ACE_Hash<Cache_ExtId>, ACE_Equal_To<Cache_ExtId>, ACE_Null_Mutex> TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::HASH_MAP |
Definition at line 87 of file Transport_Cache_Manager_T.h.
| typedef ACE_Hash_Map_Entry<Cache_ExtId, Cache_IntId> TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::HASH_MAP_ENTRY |
Definition at line 93 of file Transport_Cache_Manager_T.h.
| typedef HASH_MAP::iterator TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::HASH_MAP_ITER |
Definition at line 89 of file Transport_Cache_Manager_T.h.
| typedef PSTRAT TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::purging_strategy |
Definition at line 67 of file Transport_Cache_Manager_T.h.
| typedef TRDT TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::transport_descriptor_type |
Definition at line 66 of file Transport_Cache_Manager_T.h.
| typedef TT TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::transport_type |
Definition at line 65 of file Transport_Cache_Manager_T.h.
| enum TAO::Transport_Cache_Manager_T::Find_Result |
results of a find
Definition at line 70 of file Transport_Cache_Manager_T.h.
{
CACHE_FOUND_NONE,
CACHE_FOUND_CONNECTING,
CACHE_FOUND_BUSY,
CACHE_FOUND_AVAILABLE
};
| TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::Transport_Cache_Manager_T | ( | int | percent, | |
| purging_strategy * | purging_strategy, | |||
| size_t | cache_maximum, | |||
| bool | locked, | |||
| const char * | orbid | |||
| ) |
Constructor.
Definition at line 32 of file Transport_Cache_Manager_T.cpp.
: percent_ (percent) , purging_strategy_ (purging_strategy) , cache_map_ (cache_maximum) , cache_lock_ (0) , cache_maximum_ (cache_maximum) #if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1) , purge_monitor_ (0) , size_monitor_ (0) #endif /* TAO_HAS_MONITOR_POINTS==1 */ { if (locked) { ACE_NEW (this->cache_lock_, ACE_Lock_Adapter <TAO_SYNCH_MUTEX> (this->cache_map_mutex_)); } else { ACE_NEW (this->cache_lock_, ACE_Lock_Adapter<ACE_SYNCH_NULL_MUTEX>); } #if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1) ACE_NEW (this->purge_monitor_, ACE::Monitor_Control::Size_Monitor); ACE_NEW (this->size_monitor_, ACE::Monitor_Control::Size_Monitor); ACE_CString purge_name ("Connection_Cache_Purge_"); ACE_CString size_name ("Connection_Cache_Size_"); purge_name += orbid; size_name += orbid; this->purge_monitor_->name (purge_name.c_str ()); this->size_monitor_->name (size_name.c_str ()); this->purge_monitor_->add_to_registry (); this->size_monitor_->add_to_registry (); #else ACE_UNUSED_ARG (orbid); #endif /* TAO_HAS_MONITOR_POINTS==1 */ }
| TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::~Transport_Cache_Manager_T | ( | void | ) |
Destructor.
Definition at line 82 of file Transport_Cache_Manager_T.cpp.
{
delete this->cache_lock_;
this->cache_lock_ = 0;
delete this->purging_strategy_;
this->purging_strategy_ = 0;
#if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1)
this->purge_monitor_->remove_from_registry ();
this->size_monitor_->remove_from_registry ();
this->purge_monitor_->remove_ref ();
this->size_monitor_->remove_ref ();
#endif /* TAO_HAS_MONITOR_POINTS==1 */
}
| int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::bind_i | ( | Cache_ExtId & | ext_id, | |
| Cache_IntId & | int_id | |||
| ) | [private] |
Non-Locking version and actual implementation of bind () call. Calls bind on the Hash_Map_Manager that it holds. If the bind succeeds, it adds the Hash_Map_Entry in to the Transport for its reference.
Definition at line 116 of file Transport_Cache_Manager_T.cpp.
{
if (TAO_debug_level > 4)
{
ACE_DEBUG ((LM_INFO,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::bind_i, ")
ACE_TEXT ("Transport[%d] @ hash:index{%d:%d}\n"),
int_id.transport ()->id (),
ext_id.hash (),
ext_id.index ()
));
}
// Get the entry too
HASH_MAP_ENTRY *entry = 0;
// Update the purging strategy information while we
// are holding our lock
this->purging_strategy_->update_item (int_id.transport ());
int retval = 0;
bool more_to_do = true;
while (more_to_do)
{
if (this->cache_map_.current_size () >= cache_maximum_)
{
retval = -1;
if (TAO_debug_level > 0)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT("TAO (%P|%t) - Transport_Cache_Manager_T::bind_i, ")
ACE_TEXT("ERROR: unable to bind transport, cache is full\n")));
}
more_to_do = false;
}
else
{
retval = this->cache_map_.bind (ext_id, int_id, entry);
if (retval == 0)
{
// The entry has been added to cache succesfully
// Add the cache_map_entry to the transport
int_id.transport ()->cache_map_entry (entry);
more_to_do = false;
}
else if (retval == 1)
{
if (entry->item ().transport () == int_id.transport ())
{
// update the cache status
// we are already holding the lock, do not call set_entry_state
entry->item ().recycle_state (int_id.recycle_state ());
if (TAO_debug_level > 9 &&
entry->item ().is_connected () != int_id.is_connected ())
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_")
ACE_TEXT ("Manager::bind_i, Updating existing ")
ACE_TEXT ("entry sets is_connected to %C\n"),
(int_id.is_connected () ? "true" : "false")));
entry->item ().is_connected (int_id.is_connected ());
retval = 0;
more_to_do = false;
}
else
{
ext_id.index (ext_id.index () + 1);
if (TAO_debug_level > 8)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::bind_i, ")
ACE_TEXT ("Unable to bind Transport[%d] @ hash:index{%d:%d}. ")
ACE_TEXT ("Trying with a new index\n"),
int_id.transport ()->id (),
ext_id.hash (),
ext_id.index ()));
}
}
}
else
{
if (TAO_debug_level > 0)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT("TAO (%P|%t) - Transport_Cache_Manager_T::bind_i, ")
ACE_TEXT("ERROR: unable to bind transport\n")));
}
more_to_do = false;
}
}
}
if (retval == 0)
{
if (TAO_debug_level > 4)
{
ACE_DEBUG ((LM_INFO,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::bind_i: ")
ACE_TEXT ("Success Transport[%d] @ hash:index{%d:%d}. ")
ACE_TEXT ("Cache size is [%d]\n"),
int_id.transport ()->id (),
ext_id.hash (),
ext_id.index (),
this->current_size ()
));
}
}
#if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1)
this->size_monitor_->receive (this->current_size ());
#endif /* TAO_HAS_MONITOR_POINTS==1 */
return retval;
}
| bool TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::blockable_client_transports | ( | Connection_Handler_Set & | handlers | ) |
Return a set of connection handlers that belong to transports that have a RW wait strategy. This call is used for a specific use case by the ORB_Core during shutdown. The only way the ORB can wake up threads waiting on these sockets for replies is to iterate over these blockable transports and close the socket handles. Without these the threads will continue to wait there for ever.
Definition at line 115 of file Transport_Cache_Manager_T.inl.
{
ACE_MT (ACE_GUARD_RETURN (ACE_Lock,
guard,
*this->cache_lock_,
false));
return this->blockable_client_transports_i (handlers);
}
| bool TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::blockable_client_transports_i | ( | Connection_Handler_Set & | handlers | ) | [private] |
Non-locking version of blockable_client_transports ().
Definition at line 439 of file Transport_Cache_Manager_T.cpp.
{
HASH_MAP_ITER end_iter = this->cache_map_.end ();
for (HASH_MAP_ITER iter = this->cache_map_.begin ();
iter != end_iter;
++iter)
{
// Get the transport to fill its associated connection's
// handler.
bool const retval =
(*iter).int_id_.transport ()->provide_blockable_handler (h);
// Do not mark the entry as closed if we don't have a
// blockable handler added
if (retval)
(*iter).int_id_.recycle_state (ENTRY_CLOSED);
}
return true;
}
| int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::cache_transport | ( | transport_descriptor_type * | prop, | |
| transport_type * | transport, | |||
| Cache_Entries_State | state = ENTRY_IDLE_AND_PURGABLE | |||
| ) |
Add the transport to the cache.
The transport has the property definition based on which caching can be done. This method sets the cache entry status. By default the status is set to ENTRY_IDLE_AND_PURGABLE
Definition at line 11 of file Transport_Cache_Manager_T.inl.
{
// Compose the ExternId & Intid
Cache_ExtId ext_id (prop);
int retval = 0;
{
ACE_MT (ACE_GUARD_RETURN (ACE_Lock,
guard,
*this->cache_lock_,
-1));
Cache_IntId int_id (transport);
// If it has already connected, go directly to the IDLE_BNP state
if (int_id.is_connected () && state == ENTRY_CONNECTING)
int_id.recycle_state (ENTRY_IDLE_AND_PURGABLE);
else
int_id.recycle_state (state);
retval = this->bind_i (ext_id, int_id);
}
return retval;
}
| int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::close | ( | Connection_Handler_Set & | handlers | ) |
Close the underlying hash map manager and return any handlers still registered
Definition at line 96 of file Transport_Cache_Manager_T.inl.
{
// The cache lock pointer should only be zero if
// Transport_Cache_Manager_T::open() was never called. Note that
// only one thread opens the Transport_Cache_Manager_T at any given
// time, so it is safe to check for a non-zero lock pointer.
if (this->cache_lock_ == 0)
return -1;
ACE_MT (ACE_GUARD_RETURN (ACE_Lock,
guard,
*this->cache_lock_,
-1));
return this->close_i (handlers);
}
| int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::close_i | ( | Connection_Handler_Set & | handlers | ) | [private] |
Non-locking version and actual implementation of close ().
Definition at line 413 of file Transport_Cache_Manager_T.cpp.
{
HASH_MAP_ITER end_iter = this->cache_map_.end ();
for (HASH_MAP_ITER iter = this->cache_map_.begin ();
iter != end_iter;
++iter)
{
// Get the transport to fill its associated connection's handler.
(*iter).int_id_.transport ()->provide_handler (handlers);
// Inform the transport that has a reference to the entry in the
// map that we are *gone* now. So, the transport should not use
// the reference to the entry that he has, to access us *at any
// time*.
(*iter).int_id_.transport ()->cache_map_entry (0);
}
// Unbind all the entries in the map
this->cache_map_.unbind_all ();
return 0;
}
| int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::cpscmp | ( | const void * | a, | |
| const void * | b | |||
| ) | [static, private] |
Used by qsort.
Definition at line 576 of file Transport_Cache_Manager_T.cpp.
{
const HASH_MAP_ENTRY** left = (const HASH_MAP_ENTRY**)a;
const HASH_MAP_ENTRY** right = (const HASH_MAP_ENTRY**)b;
if ((*left)->int_id_.transport ()->purging_order () <
(*right)->int_id_.transport ()->purging_order ())
return -1;
if ((*left)->int_id_.transport ()->purging_order () >
(*right)->int_id_.transport ()->purging_order ())
return 1;
return 0;
}
| size_t TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::current_size | ( | void | ) | const |
Return the current size of the cache.
Definition at line 128 of file Transport_Cache_Manager_T.inl.
{
return this->cache_map_.current_size ();
}
| int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::fill_set_i | ( | DESCRIPTOR_SET & | sorted_set | ) | [private] |
Fill sorted_set in with the transport_descriptor_type's in a sorted order.
Definition at line 742 of file Transport_Cache_Manager_T.cpp.
{
int current_size = 0;
int const cache_maximum = this->purging_strategy_->cache_maximum ();
// set sorted_set to 0. This signifies nothing to purge.
sorted_set = 0;
// Do we need to worry about cache purging?
if (cache_maximum >= 0)
{
current_size = static_cast<int> (this->current_size ());
if (TAO_debug_level > 6)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::fill_set_i, ")
ACE_TEXT ("current_size = %d, cache_maximum = %d\n"),
current_size, cache_maximum));
}
if (current_size >= cache_maximum)
{
ACE_NEW_RETURN (sorted_set, HASH_MAP_ENTRY*[current_size], 0);
HASH_MAP_ITER iter = this->cache_map_.begin ();
for (int i = 0; i < current_size; ++i)
{
sorted_set[i] = &(*iter);
++iter;
}
this->sort_set (sorted_set, current_size);
}
}
return current_size;
}
| Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::Find_Result TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::find | ( | transport_descriptor_type * | prop, | |
| transport_type *& | transport, | |||
| size_t & | busy_count | |||
| ) | [private] |
Lookup entry<key,value> in the cache. Grabs the lock and calls the implementation function find_i.
Definition at line 81 of file Transport_Cache_Manager_T.inl.
| Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::Find_Result TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::find_i | ( | transport_descriptor_type * | prop, | |
| transport_type *& | transport, | |||
| size_t & | busy_count | |||
| ) | [private] |
Non-locking version and actual implementation of find () call. This calls the find () on the underlying Hash_Map_Manager. If the find succeeds, it calls the get_idle_transport ().
Definition at line 282 of file Transport_Cache_Manager_T.cpp.
{
// Get the entry from the Hash Map
Find_Result found = CACHE_FOUND_NONE;
// Make a temporary object. It does not do a copy.
Cache_ExtId key (prop);
HASH_MAP_ENTRY *entry = 0;
busy_count = 0;
int cache_status = 0;
HASH_MAP_ENTRY *found_entry = 0;
// loop until we find a usable transport, or until we've checked
// all cached entries for this endpoint
while (found != CACHE_FOUND_AVAILABLE && cache_status == 0)
{
entry = 0;
cache_status = this->cache_map_.find (key, entry);
if (cache_status == 0 && entry)
{
if (this->is_entry_available_i (*entry))
{
// Successfully found a transport_type.
found = CACHE_FOUND_AVAILABLE;
found_entry = entry;
entry->item ().recycle_state (ENTRY_BUSY);
if (TAO_debug_level > 6)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::find_i, ")
ACE_TEXT ("Found available Transport[%d] @hash:index {%d:%d}\n"),
entry->item ().transport ()->id (),
entry->ext_id_.hash (),
entry->ext_id_.index ()
));
}
}
else if (this->is_entry_connecting_i (*entry))
{
if (TAO_debug_level > 6)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::find_i, ")
ACE_TEXT ("Found connecting Transport[%d] @hash:index {%d:%d}\n"),
entry->item ().transport ()->id (),
entry->ext_id_.hash (),
entry->ext_id_.index ()
));
}
// if this is the first interesting entry
if (found != CACHE_FOUND_CONNECTING)
{
found_entry = entry;
found = CACHE_FOUND_CONNECTING;
}
}
else
{
// if this is the first busy entry
if (found == CACHE_FOUND_NONE && busy_count == 0)
{
found_entry = entry;
found = CACHE_FOUND_BUSY;
}
++busy_count;
if (TAO_debug_level > 6)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::find_i, ")
ACE_TEXT ("Found busy Transport[%d] @hash:index {%d:%d}\n"),
entry->item ().transport ()->id (),
entry->ext_id_.hash (),
entry->ext_id_.index ()
));
}
}
}
// Bump the index up
key.incr_index ();
}
if (found_entry != 0)
{
transport = found_entry->item ().transport ();
transport->add_reference ();
if (found == CACHE_FOUND_AVAILABLE)
{
// Update the purging strategy information while we
// are holding our lock
this->purging_strategy_->update_item (transport);
}
}
return found;
}
| Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::Find_Result TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::find_transport | ( | transport_descriptor_type * | prop, | |
| transport_type *& | transport, | |||
| size_t & | busy_count | |||
| ) |
Check the Transport Cache to check whether the connection exists in the Cache and return the connection
Definition at line 233 of file Transport_Cache_Manager_T.cpp.
{
if (prop == 0)
{
transport = 0;
return CACHE_FOUND_NONE;
}
Find_Result find_result = this->find (
prop, transport, busy_count);
if (find_result != CACHE_FOUND_NONE)
{
if (find_result == CACHE_FOUND_AVAILABLE)
{
if (transport->wait_strategy ()->non_blocking () == 0 &&
transport->orb_core ()->client_factory ()->use_cleanup_options ())
{
ACE_Event_Handler * const eh =
transport->event_handler_i ();
ACE_Reactor * const r =
transport->orb_core ()->reactor ();
if (eh &&
r->remove_handler (eh,
ACE_Event_Handler::READ_MASK |
ACE_Event_Handler::DONT_CALL) == -1)
{
if (TAO_debug_level > 0)
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T[%d]")
ACE_TEXT ("::find_transport, remove_handler failed\n"),
transport->id ()));
}
else
{
transport->wait_strategy ()->is_registered (false);
}
}
}
}
return find_result;
}
| bool TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::is_entry_available_i | ( | const HASH_MAP_ENTRY & | entry | ) | [private] |
Tries to find if the int_id_ in entry is available for use.
Definition at line 497 of file Transport_Cache_Manager_T.cpp.
{
Cache_Entries_State entry_state = entry.int_id_.recycle_state ();
bool result = (entry_state == ENTRY_IDLE_AND_PURGABLE);
if (result && entry.int_id_.transport () != 0)
{
// if it's not connected, it's not available
result = entry.int_id_.is_connected ();
}
if (TAO_debug_level > 8)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::")
ACE_TEXT ("is_entry_available_i[%d], %C state is %C\n"),
entry.int_id_.transport () ? entry.int_id_.transport ()->id () : 0,
(result ? "true" : "false"),
Cache_IntId::state_name (entry_state)));
}
return result;
}
| bool TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::is_entry_connecting_i | ( | const HASH_MAP_ENTRY & | entry | ) | [private] |
Tries to find if the int_id_ in entry is connect pending
Definition at line 547 of file Transport_Cache_Manager_T.cpp.
{
Cache_Entries_State entry_state = entry.int_id_.recycle_state ();
bool result = (entry_state == ENTRY_CONNECTING);
if (!result && entry.int_id_.transport () != 0)
{
// if we're not connected, that counts, too.
// Can this happen? Not sure <wilsond@ociweb.com>
result = !entry.int_id_.is_connected ();
}
if (TAO_debug_level > 8)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::")
ACE_TEXT ("is_entry_connecting_i[%d], %C, state is %C\n"),
entry.int_id_.transport () ? entry.int_id_.transport ()->id () : 0,
(result ? "true" : "false"),
Cache_IntId::state_name (entry_state)));
}
return result;
}
| bool TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::is_entry_purgable_i | ( | HASH_MAP_ENTRY & | entry | ) | [private] |
Tries to find if the int_id_ in entry is purgable
Definition at line 523 of file Transport_Cache_Manager_T.cpp.
{
Cache_Entries_State entry_state = entry.int_id_.recycle_state ();
transport_type* transport = entry.int_id_.transport ();
bool result = (entry_state == ENTRY_IDLE_AND_PURGABLE ||
entry_state == ENTRY_PURGABLE_BUT_NOT_IDLE)
&& transport->can_be_purged ();
if (TAO_debug_level > 8)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::")
ACE_TEXT ("is_entry_purgable_i[%d], %C state is %C\n"),
entry.int_id_.transport ()->id (),
(result ? "true" : "false"),
Cache_IntId::state_name (entry_state)));
}
return result;
}
| int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::make_idle | ( | HASH_MAP_ENTRY * | entry | ) |
Make the entry idle and ready for use.
Definition at line 73 of file Transport_Cache_Manager_T.inl.
{
ACE_MT (ACE_GUARD_RETURN (ACE_Lock, guard, *this->cache_lock_, -1));
return this->make_idle_i (entry);
}
| int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::make_idle_i | ( | HASH_MAP_ENTRY * | entry | ) | [private] |
Non-locking version and actual implementation of make_idle ().
Definition at line 384 of file Transport_Cache_Manager_T.cpp.
{
if (entry == 0)
return -1;
entry->item ().recycle_state (ENTRY_IDLE_AND_PURGABLE);
return 0;
}
| Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::HASH_MAP & TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::map | ( | void | ) |
Return the underlying cache map.
Definition at line 142 of file Transport_Cache_Manager_T.inl.
{
return this->cache_map_;
}
| void TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::mark_connected | ( | HASH_MAP_ENTRY * | entry, | |
| bool | state | |||
| ) |
Mark the entry as connected.
Definition at line 56 of file Transport_Cache_Manager_T.inl.
{
ACE_MT (ACE_GUARD (ACE_Lock, guard, *this->cache_lock_));
if (entry == 0)
return;
if (TAO_debug_level > 9 && state != entry->item ().is_connected ())
ACE_DEBUG ((LM_DEBUG, ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T")
ACE_TEXT ("::mark_connected, %s Transport[%d]\n"),
(state ? ACE_TEXT("true") : ACE_TEXT("false")),
entry->item ().transport ()->id ()
));
entry->item().is_connected (state);
}
| void TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::mark_invalid | ( | HASH_MAP_ENTRY * | entry | ) |
Mark the entry as invalid for use but keep it in cache.
Definition at line 48 of file Transport_Cache_Manager_T.inl.
{
ACE_MT (ACE_GUARD (ACE_Lock, guard, *this->cache_lock_));
this->mark_invalid_i (entry);
}
| void TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::mark_invalid_i | ( | HASH_MAP_ENTRY * | entry | ) | [private] |
Mark the entry as invalid for use but keep it in cache.
Definition at line 486 of file Transport_Cache_Manager_T.cpp.
{
if (entry != 0)
{
// Mark the entry as not usable
entry->item ().recycle_state (ENTRY_PURGABLE_BUT_NOT_IDLE);
}
}
| int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::purge | ( | void | ) |
Remove entries from the cache depending upon the strategy.
Definition at line 595 of file Transport_Cache_Manager_T.cpp.
{
typedef ACE_Unbounded_Set<transport_type*> transport_set_type;
transport_set_type transports_to_be_closed;
{
ACE_MT (ACE_GUARD_RETURN (ACE_Lock, ace_mon, *this->cache_lock_, 0));
DESCRIPTOR_SET sorted_set = 0;
int const sorted_size = this->fill_set_i (sorted_set);
// Only call close_entries () if sorted_set != 0. It takes
// control of sorted_set and cleans up any allocated memory. If
// sorted_set == 0, then there is nothing to de-allocate.
if (sorted_set != 0)
{
// BEGIN FORMER close_entries
// Calculate the number of entries to purge, when we have
// to purge try to at least to purge minimal of 1 entry
// which is needed if we have a very small cache maximum
int const amount = (sorted_size * this->percent_) / 100;
if (TAO_debug_level > 4)
{
ACE_DEBUG ((LM_INFO,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::purge, ")
ACE_TEXT ("Trying to purge %d of %d cache entries\n"),
amount,
sorted_size));
}
int count = 0;
for (int i = 0; count < amount && i < sorted_size; ++i)
{
if (this->is_entry_purgable_i (*sorted_set[i]))
{
transport_type* transport =
sorted_set[i]->int_id_.transport ();
sorted_set[i]->int_id_.recycle_state (ENTRY_BUSY);
transport->add_reference ();
if (TAO_debug_level > 4)
{
ACE_DEBUG ((LM_INFO,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::purge, ")
ACE_TEXT ("Purgable Transport[%d] found in ")
ACE_TEXT ("cache\n"),
transport->id ()));
}
if (transports_to_be_closed.insert_tail (transport) != 0)
{
if (TAO_debug_level > 0)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T")
ACE_TEXT ("::purge, Unable to add transport[%d] ")
ACE_TEXT ("on the to-be-closed set, so ")
ACE_TEXT ("it will not be purged\n"),
transport->id ()));
}
transport->remove_reference ();
}
// Count this as a successful purged entry
++count;
}
}
delete [] sorted_set;
sorted_set = 0;
// END FORMER close_entries
}
}
// Now, without the lock held, lets go through and close all the transports.
if (! transports_to_be_closed.is_empty ())
{
typename transport_set_type::iterator it (transports_to_be_closed);
while (! it.done ())
{
transport_type *transport = *it;
it.advance ();
if (transport)
{
transport->close_connection ();
transport->remove_reference ();
}
}
}
if (TAO_debug_level > 4)
{
ACE_DEBUG ((LM_INFO,
ACE_TEXT ("TAO (%P|%t) - Transport_Cache_Manager_T::purge, ")
ACE_TEXT ("Cache size after purging is [%d]\n"),
this->current_size ()
));
}
#if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1)
/// The value doesn't matter, all we need is the timestamp,
/// which is added automatically.
this->purge_monitor_->receive (static_cast<size_t> (0UL));
/// And update the size monitor as well.
this->size_monitor_->receive (this->current_size ());
#endif /* TAO_HAS_MONITOR_POINTS==1 */
return 0;
}
| int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::purge_entry | ( | HASH_MAP_ENTRY *& | entry | ) |
Purge the entry from the Cache Map.
Definition at line 40 of file Transport_Cache_Manager_T.inl.
{
ACE_MT (ACE_GUARD_RETURN (ACE_Lock, guard, *this->cache_lock_, -1));
return this->purge_entry_i (entry);
}
| int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::purge_entry_i | ( | HASH_MAP_ENTRY *& | entry | ) | [private] |
Purge the entry from the Cache Map.
Definition at line 464 of file Transport_Cache_Manager_T.cpp.
{
int retval = 0;
if (entry != 0)
{
// Remove the entry from the Map
retval = this->cache_map_.unbind (entry);
// Set the entry pointer to zero
entry = 0;
#if defined (TAO_HAS_MONITOR_POINTS) && (TAO_HAS_MONITOR_POINTS == 1)
this->size_monitor_->receive (this->current_size ());
#endif /* TAO_HAS_MONITOR_POINTS==1 */
}
return retval;
}
| void TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::set_entry_state | ( | HASH_MAP_ENTRY * | entry, | |
| TAO::Cache_Entries_State | state | |||
| ) |
Modify the state setting on the provided entry.
Definition at line 100 of file Transport_Cache_Manager_T.cpp.
{
ACE_MT (ACE_GUARD (ACE_Lock, guard, *this->cache_lock_));
if (entry != 0)
{
entry->item ().recycle_state (state);
if (state != ENTRY_UNKNOWN && state != ENTRY_CONNECTING
&& entry->item ().transport ())
entry->item ().is_connected (
entry->item ().transport ()->is_connected ());
}
}
| void TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::sort_set | ( | DESCRIPTOR_SET & | entries, | |
| int | size | |||
| ) | [private] |
Sort the list of entries.
Definition at line 712 of file Transport_Cache_Manager_T.cpp.
{
#if defined (ACE_LACKS_QSORT)
// Use insertion sort if we don't have qsort
for(int i = 1; i < current_size; ++i)
{
if (entries[i]->int_id_.transport ()->purging_order () <
entries[i - 1]->int_id_.transport ()->purging_order ())
{
HASH_MAP_ENTRY* entry = entries[i];
for(int j = i; j > 0 &&
entries[j - 1]->int_id_.transport ()->purging_order () >
entry->item ().transport ()->purging_order (); --j)
{
HASH_MAP_ENTRY* holder = entries[j];
entries[j] = entries[j - 1];
entries[j - 1] = holder;
}
}
}
#else
ACE_OS::qsort (entries, current_size,
sizeof (HASH_MAP_ENTRY*), (ACE_COMPARE_FUNC)cpscmp);
#endif /* ACE_LACKS_QSORT */
}
| size_t TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::total_size | ( | void | ) | const |
Return the total size of the cache.
Definition at line 135 of file Transport_Cache_Manager_T.inl.
{
return this->cache_map_.total_size ();
}
| int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::update_entry | ( | HASH_MAP_ENTRY *& | entry | ) |
Mark the entry as touched. This call updates the purging strategy policy information.
Definition at line 396 of file Transport_Cache_Manager_T.cpp.
{
ACE_MT (ACE_GUARD_RETURN (ACE_Lock,
guard,
*this->cache_lock_, -1));
if (entry == 0)
return -1;
purging_strategy *st = this->purging_strategy_;
(void) st->update_item (entry->item ().transport ());
return 0;
}
ACE_Lock* TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::cache_lock_ [private] |
The lock that is used by the cache map.
Definition at line 260 of file Transport_Cache_Manager_T.h.
HASH_MAP TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::cache_map_ [private] |
The hash map that has the connections.
Definition at line 255 of file Transport_Cache_Manager_T.h.
TAO_SYNCH_MUTEX TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::cache_map_mutex_ [private] |
Definition at line 257 of file Transport_Cache_Manager_T.h.
size_t TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::cache_maximum_ [private] |
Maximum size of the cache.
Definition at line 263 of file Transport_Cache_Manager_T.h.
int TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::percent_ [private] |
The percentage of the cache to purge at one time.
Definition at line 249 of file Transport_Cache_Manager_T.h.
purging_strategy* TAO::Transport_Cache_Manager_T< TT, TRDT, PSTRAT >::purging_strategy_ [private] |
The underlying connection purging strategy.
Definition at line 252 of file Transport_Cache_Manager_T.h.
1.7.0
