#include <Muxed_TMS.h>
Using this strategy a single connection can have multiple outstanding requests. @ Can the performance of the demuxer be made more predictable, for example, using the request id as an active demux key?
Definition at line 49 of file Muxed_TMS.h.
Definition at line 98 of file Muxed_TMS.h.
| TAO_Muxed_TMS::TAO_Muxed_TMS | ( | TAO_Transport * | transport | ) |
Constructor.
Definition at line 16 of file Muxed_TMS.cpp.
: TAO_Transport_Mux_Strategy (transport) , lock_ (0) , request_id_generator_ (0) , orb_core_ (transport->orb_core ()) , dispatcher_table_ (this->orb_core_->client_factory ()->reply_dispatcher_table_size ()) { this->lock_ = this->orb_core_->client_factory ()->create_transport_mux_strategy_lock (); }
| TAO_Muxed_TMS::~TAO_Muxed_TMS | ( | void | ) | [virtual] |
| TAO_Muxed_TMS::TAO_Muxed_TMS | ( | const TAO_Muxed_TMS & | ) | [private] |
| int TAO_Muxed_TMS::bind_dispatcher | ( | CORBA::ULong | request_id, | |
| ACE_Intrusive_Auto_Ptr< TAO_Reply_Dispatcher > | rd | |||
| ) | [virtual] |
Bind the dispatcher with the request id.
Implements TAO_Transport_Mux_Strategy.
Definition at line 68 of file Muxed_TMS.cpp.
{
ACE_GUARD_RETURN (ACE_Lock,
ace_mon,
*this->lock_,
-1);
if (rd == 0)
{
if (TAO_debug_level > 0)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - TAO_Muxed_TMS::bind_dispatcher, ")
ACE_TEXT ("null reply dispatcher\n")));
}
return 0;
}
int const result = this->dispatcher_table_.bind (request_id, rd);
if (result != 0)
{
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - TAO_Muxed_TMS::bind_dispatcher, ")
ACE_TEXT ("bind dispatcher failed: result = %d, request id = %d\n"),
result, request_id));
return -1;
}
return 0;
}
| int TAO_Muxed_TMS::clear_cache_i | ( | void | ) | [private] |
Definition at line 260 of file Muxed_TMS.cpp.
{
if (this->dispatcher_table_.current_size () == 0)
return -1;
REQUEST_DISPATCHER_TABLE::ITERATOR const end =
this->dispatcher_table_.end ();
ACE_Unbounded_Stack <ACE_Intrusive_Auto_Ptr<TAO_Reply_Dispatcher> > ubs;
for (REQUEST_DISPATCHER_TABLE::ITERATOR i =
this->dispatcher_table_.begin ();
i != end;
++i)
{
ubs.push ((*i).int_id_);
}
this->dispatcher_table_.unbind_all ();
size_t const sz = ubs.size ();
for (size_t k = 0 ; k != sz ; ++k)
{
ACE_Intrusive_Auto_Ptr<TAO_Reply_Dispatcher> rd(0);
if (ubs.pop (rd) == 0)
{
rd->connection_closed ();
}
}
return 0;
}
| void TAO_Muxed_TMS::connection_closed | ( | void | ) | [virtual] |
The transport object has closed the connection, inform all Reply dispatchers and waiting strategies.
Implements TAO_Transport_Mux_Strategy.
Definition at line 245 of file Muxed_TMS.cpp.
{
ACE_GUARD (ACE_Lock,
ace_mon,
*this->lock_);
int retval = 0;
do
{
retval = this->clear_cache_i ();
}
while (retval != -1);
}
| int TAO_Muxed_TMS::dispatch_reply | ( | TAO_Pluggable_Reply_Params & | params | ) | [virtual] |
Dispatch the reply for request_id, cleanup any resources allocated for that request.
Implements TAO_Transport_Mux_Strategy.
Definition at line 126 of file Muxed_TMS.cpp.
{
int result = 0;
ACE_Intrusive_Auto_Ptr<TAO_Reply_Dispatcher> rd(0);
// Grab the reply dispatcher for this id.
{
ACE_GUARD_RETURN (ACE_Lock,
ace_mon,
*this->lock_,
-1);
result = this->dispatcher_table_.unbind (params.request_id_, rd);
}
if (result == 0 && rd)
{
if (TAO_debug_level > 8)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - TAO_Muxed_TMS::dispatch_reply, ")
ACE_TEXT ("id = %d\n"),
params.request_id_));
// Dispatch the reply.
// They return 1 on success, and -1 on failure.
result = rd->dispatch_reply (params);
}
else
{
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - TAO_Muxed_TMS::dispatch_reply, ")
ACE_TEXT ("unbind dispatcher failed, id %d: result = %d\n"),
params.request_id_,
result));
// Result = 0 means that the mux strategy was not able
// to find a registered reply handler, either because the reply
// was not our reply - just forget about it - or it was ours, but
// the reply timed out - just forget about the reply.
result = 0;
}
return result;
}
| bool TAO_Muxed_TMS::has_request | ( | void | ) | [virtual] |
Do we have a request pending.
Implements TAO_Transport_Mux_Strategy.
Definition at line 115 of file Muxed_TMS.cpp.
{
ACE_GUARD_RETURN (ACE_Lock,
ace_mon,
*this->lock_,
false);
return this->dispatcher_table_.current_size () > 0;
}
| bool TAO_Muxed_TMS::idle_after_reply | ( | void | ) | [virtual] |
Request is sent and the reply is received. Idle the transport now. The return value indicates whether idling was successful or not.
Implements TAO_Transport_Mux_Strategy.
Definition at line 239 of file Muxed_TMS.cpp.
{
return false;
}
| bool TAO_Muxed_TMS::idle_after_send | ( | void | ) | [virtual] |
Request has been just sent, but the reply is not received. Idle the transport now. The return value indicates whether idling was successful or not.
Implements TAO_Transport_Mux_Strategy.
Definition at line 227 of file Muxed_TMS.cpp.
{
// Irrespective of whether we are successful or not we need to
// return true. If *this* class is not successfull in idling the
// transport no one can.
if (this->transport_ != 0)
(void) this->transport_->make_idle ();
return true;
}
| void TAO_Muxed_TMS::operator= | ( | const TAO_Muxed_TMS & | ) | [private] |
| int TAO_Muxed_TMS::reply_timed_out | ( | CORBA::ULong | request_id | ) | [virtual] |
Dispatch a reply timeout for request request_id
Implements TAO_Transport_Mux_Strategy.
Definition at line 173 of file Muxed_TMS.cpp.
{
int result = 0;
ACE_Intrusive_Auto_Ptr<TAO_Reply_Dispatcher> rd(0);
// Grab the reply dispatcher for this id.
{
ACE_GUARD_RETURN (ACE_Lock,
ace_mon,
*this->lock_,
-1);
result = this->dispatcher_table_.unbind (request_id, rd);
}
if (result == 0 && rd)
{
if (TAO_debug_level > 8)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - TAO_Muxed_TMS::reply_timed_out, ")
ACE_TEXT ("id = %d\n"),
request_id));
}
// Do not move it outside the scope of the lock. A follower thread
// could have timedout unwinding the stack and the reply
// dispatcher, and that would mean the present thread could be left
// with a dangling pointer and may crash. To safeguard against such
// cases we dispatch with the lock held.
// Dispatch the reply.
rd->reply_timed_out ();
}
else
{
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - TAO_Muxed_TMS::reply_timed_out, ")
ACE_TEXT ("unbind dispatcher failed, id %d: result = %d\n"),
request_id,
result));
// Result = 0 means that the mux strategy was not able
// to find a registered reply handler, either because the reply
// was not our reply - just forget about it - or it was ours, but
// the reply timed out - just forget about the reply.
result = 0;
}
return result;
}
| CORBA::ULong TAO_Muxed_TMS::request_id | ( | void | ) | [virtual] |
Generate and return an unique request id for the current invocation.
Implements TAO_Transport_Mux_Strategy.
Definition at line 35 of file Muxed_TMS.cpp.
{
// @@ What is a good error return value?
ACE_GUARD_RETURN (ACE_Lock,
ace_mon,
*this->lock_,
0);
++this->request_id_generator_;
// if TAO_Transport::bidirectional_flag_
// == 1 --> originating side
// == 0 --> other side
// == -1 --> no bi-directional connection was negotiated
// The originating side must have an even request ID, and the other
// side must have an odd request ID. Make sure that is the case.
int const bidir_flag = this->transport_->bidirectional_flag ();
if ((bidir_flag == 1 && ACE_ODD (this->request_id_generator_))
|| (bidir_flag == 0 && ACE_EVEN (this->request_id_generator_)))
++this->request_id_generator_;
if (TAO_debug_level > 4)
ACE_DEBUG ((LM_DEBUG,
"TAO (%P|%t) - Muxed_TMS[%d]::request_id, <%d>\n",
this->transport_->id (),
this->request_id_generator_));
return this->request_id_generator_;
}
| int TAO_Muxed_TMS::unbind_dispatcher | ( | CORBA::ULong | request_id | ) | [virtual] |
Unbind the dispatcher, the client is no longer waiting for the request, for example, because the request timedout. The strategy can (must) cleanup any resources associated with the request. A later reply for that request should be ignored.
Implements TAO_Transport_Mux_Strategy.
Definition at line 104 of file Muxed_TMS.cpp.
{
ACE_GUARD_RETURN (ACE_Lock,
ace_mon,
*this->lock_,
-1);
return this->dispatcher_table_.unbind (request_id);
}
Table of <Request ID, Reply Dispatcher> pairs.
Definition at line 101 of file Muxed_TMS.h.
ACE_Lock* TAO_Muxed_TMS::lock_ [private] |
Lock to protect the state of the object.
Definition at line 83 of file Muxed_TMS.h.
TAO_ORB_Core* const TAO_Muxed_TMS::orb_core_ [private] |
Keep track of the orb core pointer. We need to this to create the Reply Dispatchers.
Definition at line 91 of file Muxed_TMS.h.
Used to generate a different request_id on each call to request_id().
Definition at line 87 of file Muxed_TMS.h.
