This class defines the protocol specific attributes required for locating ORBs over a TCP/IP network. More...
#include <IIOP_Profile.h>
Public Member Functions | |
| TAO_IIOP_Profile (const ACE_INET_Addr &addr, const TAO::ObjectKey &object_key, const TAO_GIOP_Message_Version &version, TAO_ORB_Core *orb_core) | |
| TAO_IIOP_Profile (const char *host, CORBA::UShort port, const TAO::ObjectKey &object_key, const ACE_INET_Addr &addr, const TAO_GIOP_Message_Version &version, TAO_ORB_Core *orb_core) | |
| TAO_IIOP_Profile (TAO_ORB_Core *orb_core) | |
| Profile constructor, default. | |
| void | add_endpoint (TAO_IIOP_Endpoint *endp) |
| void | remove_endpoint (TAO_IIOP_Endpoint *endp) |
| virtual void | remove_generic_endpoint (TAO_Endpoint *ep) |
| virtual void | add_generic_endpoint (TAO_Endpoint *ep) |
| Add an endpoint when the specific endpoint type is unknown. | |
| virtual char | object_key_delimiter (void) const |
| The object key delimiter that IIOP uses or expects. | |
| virtual char * | to_string (void) |
| Template methods. Please see Profile.h for documentation. | |
| virtual int | encode_endpoints (void) |
| virtual int | encode_alternate_endpoints (void) |
| virtual TAO_Endpoint * | endpoint (void) |
| virtual TAO_Endpoint * | base_endpoint (void) |
| virtual CORBA::ULong | endpoint_count (void) const |
| Return how many endpoints this profile contains. | |
| virtual CORBA::ULong | hash (CORBA::ULong max) |
| Return a hash value for this object. | |
Static Public Member Functions | |
| static const char * | prefix (void) |
| Return the char string prefix. | |
Static Public Attributes | |
| static const char | object_key_delimiter_ = '/' |
Protected Member Functions | |
| ~TAO_IIOP_Profile (void) | |
| Destructor is to be called only through <_decr_refcnt>. | |
| int | encode_endpoints_for_rt (void) |
| virtual int | decode_profile (TAO_InputCDR &cdr) |
| Template methods. Please see Profile.h for the documentation. | |
| virtual int | decode_endpoints (void) |
| virtual void | parse_string_i (const char *string) |
| Protocol specific implementation of parse_string (). | |
| virtual void | create_profile_body (TAO_OutputCDR &cdr) const |
| Creates an encapsulation of the ProfileBody struct in the cdr. | |
| virtual CORBA::Boolean | do_is_equivalent (const TAO_Profile *other_profile) |
| Profile equivalence template method invoked on subclasses. | |
Protected Attributes | |
| TAO_IIOP_Endpoint | endpoint_ |
| TAO_IIOP_Endpoint * | last_endpoint_ |
| For efficient insertion at the end of the list. | |
| CORBA::ULong | count_ |
| Number of endpoints in the list headed by <endpoint_>. | |
This class defines the protocol specific attributes required for locating ORBs over a TCP/IP network.
This class defines the IIOP profile as specified in the CORBA specification.
Definition at line 44 of file IIOP_Profile.h.
| TAO_IIOP_Profile::TAO_IIOP_Profile | ( | const ACE_INET_Addr & | addr, | |
| const TAO::ObjectKey & | object_key, | |||
| const TAO_GIOP_Message_Version & | version, | |||
| TAO_ORB_Core * | orb_core | |||
| ) |
Profile constructor, same as above except the object_key has already been marshaled.
Definition at line 51 of file IIOP_Profile.cpp.
: TAO_Profile (IOP::TAG_INTERNET_IOP, orb_core, object_key, version), endpoint_ (addr, orb_core->orb_params ()->use_dotted_decimal_addresses ()), last_endpoint_ (&this->endpoint_), count_ (1) { }
| TAO_IIOP_Profile::TAO_IIOP_Profile | ( | const char * | host, | |
| CORBA::UShort | port, | |||
| const TAO::ObjectKey & | object_key, | |||
| const ACE_INET_Addr & | addr, | |||
| const TAO_GIOP_Message_Version & | version, | |||
| TAO_ORB_Core * | orb_core | |||
| ) |
Profile constructor, this is the most efficient since it doesn't require any address resolution processing.
Definition at line 66 of file IIOP_Profile.cpp.
: TAO_Profile (IOP::TAG_INTERNET_IOP, orb_core, object_key, version), endpoint_ (host, port, addr), last_endpoint_ (&this->endpoint_), count_ (1) { }
| TAO_IIOP_Profile::TAO_IIOP_Profile | ( | TAO_ORB_Core * | orb_core | ) |
Profile constructor, default.
Definition at line 82 of file IIOP_Profile.cpp.
: TAO_Profile (IOP::TAG_INTERNET_IOP, orb_core, TAO_GIOP_Message_Version (TAO_DEF_GIOP_MAJOR, TAO_DEF_GIOP_MINOR)), endpoint_ (), last_endpoint_ (&this->endpoint_), count_ (1) { }
| TAO_IIOP_Profile::~TAO_IIOP_Profile | ( | void | ) | [protected] |
Destructor is to be called only through <_decr_refcnt>.
Definition at line 24 of file IIOP_Profile.cpp.
{
// Clean up the list of endpoints since we own it.
// Skip the head, since it is not dynamically allocated.
TAO_Endpoint *tmp = 0;
for (TAO_Endpoint *next = this->endpoint ()->next ();
next != 0;
next = tmp)
{
tmp = next->next ();
delete next;
}
}
| void TAO_IIOP_Profile::add_endpoint | ( | TAO_IIOP_Endpoint * | endp | ) |
Add endp to this profile's list of endpoints (it is inserted at the end of the list). This profiles takes ownership of endp.
Definition at line 400 of file IIOP_Profile.cpp.
{
this->last_endpoint_->next_ = endp;
this->last_endpoint_ = endp;
++this->count_;
}
| void TAO_IIOP_Profile::add_generic_endpoint | ( | TAO_Endpoint * | ep | ) | [virtual] |
Add an endpoint when the specific endpoint type is unknown.
Reimplemented from TAO_Profile.
Definition at line 464 of file IIOP_Profile.cpp.
{
TAO_IIOP_Endpoint *iep = dynamic_cast<TAO_IIOP_Endpoint *>(endp);
if (iep != 0)
{
TAO_IIOP_Endpoint *clone;
ACE_NEW (clone, TAO_IIOP_Endpoint(*iep));
this->add_endpoint(clone);
}
}
| TAO_Endpoint * TAO_IIOP_Profile::base_endpoint | ( | void | ) | [virtual] |
Since SSLIOP_Profile derives from IIOP_Profile, but SSLIOP_Endpoint does not derive from IIOP_Endpoint, it is necessary to have a way of always getting the IIOP_Endpoint using a generic interface regardless of the final type of the profile.
Reimplemented from TAO_Profile.
Definition at line 386 of file IIOP_Profile.cpp.
{
// do not call endpoint(), return the value directly. This is to
// avoid calling a derived implementation of endpoint().
return &this->endpoint_;
}
| void TAO_IIOP_Profile::create_profile_body | ( | TAO_OutputCDR & | cdr | ) | const [protected, virtual] |
Creates an encapsulation of the ProfileBody struct in the cdr.
Implements TAO_Profile.
Definition at line 568 of file IIOP_Profile.cpp.
{
encap.write_octet (TAO_ENCAP_BYTE_ORDER);
// The GIOP version
encap.write_octet (this->version_.major);
encap.write_octet (this->version_.minor);
// STRING hostname from profile
#if defined (ACE_HAS_IPV6)
// For IPv6 decimal addresses make sure the possibly included scopeid
// is not published as this has only local meaning.
const char* host = 0;
const char* pos = 0;
if (this->endpoint_.is_ipv6_decimal_ &&
(pos = ACE_OS::strchr (host = this->endpoint_.host (), '%')) != 0)
{
ACE_CString tmp;
size_t len = pos - host;
tmp.set (this->endpoint_.host (), len, 1);
encap.write_string (tmp.c_str ());
}
else
#endif /* ACE_HAS_IPV6 */
encap.write_string (this->endpoint_.host ());
// UNSIGNED SHORT port number
encap.write_ushort (this->endpoint_.port ());
// OCTET SEQUENCE for object key
if (this->ref_object_key_)
encap << this->ref_object_key_->object_key ();
else
{
ACE_ERROR ((LM_ERROR,
"(%P|%t) TAO - IIOP_Profile::create_profile_body "
"no object key marshalled\n"));
}
if (this->version_.major > 1 || this->version_.minor > 0)
this->tagged_components ().encode (encap);
}
| int TAO_IIOP_Profile::decode_endpoints | ( | void | ) | [protected, virtual] |
Helper for decode(). Decodes endpoints from a tagged component. Decode only if RTCORBA is enabled. Furthermore, we may not find TAO_TAG_ENDPOINTS component, e.g., if we are talking to nonRT version of TAO or some other ORB. This is not an error, and we must proceed. Return 0 on success and -1 on failure.
Implements TAO_Profile.
Definition at line 757 of file IIOP_Profile.cpp.
{
IOP::TaggedComponent tagged_component;
tagged_component.tag = TAO_TAG_ENDPOINTS;
if (this->tagged_components_.get_component (tagged_component))
{
const CORBA::Octet *buf =
tagged_component.component_data.get_buffer ();
TAO_InputCDR in_cdr (reinterpret_cast<const char *> (buf),
tagged_component.component_data.length ());
// Extract the Byte Order.
CORBA::Boolean byte_order;
if (!(in_cdr >> ACE_InputCDR::to_boolean (byte_order)))
return -1;
in_cdr.reset_byte_order (static_cast<int> (byte_order));
// Extract endpoints sequence.
TAO::IIOPEndpointSequence endpoints;
if (!(in_cdr >> endpoints))
return -1;
// Get the priority of the first endpoint (head of the list.
// It's other data is extracted as part of the standard profile
// decoding.
this->endpoint_.priority (endpoints[0].priority);
// Use information extracted from the tagged component to
// populate the profile. Skip the first endpoint, since it is
// always extracted through standard profile body. Also, begin
// from the end of the sequence to preserve endpoint order,
// since <add_endpoint> method reverses the order of endpoints
// in the list.
for (CORBA::ULong i = endpoints.length () - 1;
i > 0;
--i)
{
TAO_IIOP_Endpoint *endpoint = 0;
ACE_NEW_RETURN (endpoint,
TAO_IIOP_Endpoint (endpoints[i].host,
endpoints[i].port,
endpoints[i].priority),
-1);
this->add_endpoint (endpoint);
}
}
// Now decode if there are any TAG_ALTERNATE_IIOP_ADDRESS
// components.
IOP::MultipleComponentProfile& tc = this->tagged_components_.components();
for (CORBA::ULong index = 0; index < tc.length(); index++)
{
if (tc[index].tag != IOP::TAG_ALTERNATE_IIOP_ADDRESS)
continue;
const CORBA::Octet *buf =
tc[index].component_data.get_buffer ();
TAO_InputCDR in_cdr (reinterpret_cast<const char*>(buf),
tc[index].component_data.length ());
// Extract the Byte Order.
CORBA::Boolean byte_order;
if (!(in_cdr >> ACE_InputCDR::to_boolean (byte_order)))
return -1;
in_cdr.reset_byte_order (static_cast<int>(byte_order));
CORBA::String_var host;
CORBA::Short port;
if (!(in_cdr >> host.out()) || !(in_cdr >> port))
return -1;
TAO_IIOP_Endpoint *endpoint = 0;
ACE_NEW_RETURN (endpoint,
TAO_IIOP_Endpoint (host.in(),
port,
TAO_INVALID_PRIORITY),
-1);
this->add_endpoint (endpoint);
}
return 0;
}
| int TAO_IIOP_Profile::decode_profile | ( | TAO_InputCDR & | cdr | ) | [protected, virtual] |
Template methods. Please see Profile.h for the documentation.
Implements TAO_Profile.
Definition at line 95 of file IIOP_Profile.cpp.
{
// Decode host and port into the <endpoint_>.
// it is necessary to do it indirectly so that IPv6 host addresses
// can be evaluated correctly.
CORBA::String_var host;
CORBA::UShort port;
if (cdr.read_string(host.out()) == 0 ||
cdr.read_ushort (port) == 0)
{
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) IIOP_Profile::decode - ")
ACE_TEXT ("error while decoding host/port\n")));
return -1;
}
this->endpoint_.host(host.in());
this->endpoint_.port(port);
if (cdr.good_bit ())
{
// Invalidate the object_addr_ until first access.
this->endpoint_.object_addr_.set_type (-1);
const char* csv = this->orb_core()->orb_params()->preferred_interfaces();
bool const enforce =
this->orb_core()->orb_params()->enforce_pref_interfaces();
this->count_ += this->endpoint_.preferred_interfaces(csv, enforce, *this);
return 1;
}
return -1;
}
| CORBA::Boolean TAO_IIOP_Profile::do_is_equivalent | ( | const TAO_Profile * | other | ) | [protected, virtual] |
Profile equivalence template method invoked on subclasses.
TAO_Profile subclasses must implement this template method so that they can apply their own definition of profile equivalence.
Implements TAO_Profile.
Definition at line 319 of file IIOP_Profile.cpp.
{
if (other_profile == this)
return true;
const TAO_IIOP_Profile *op =
dynamic_cast<const TAO_IIOP_Profile *> (other_profile);
// Make sure we have a TAO_IIOP_Profile.
if (op == 0)
return false;
if (this->count_ == 0 && op->count_ == 0)
return true;
if (this->count_ != op->count_)
return false;
// Check endpoints equivalence.
const TAO_IIOP_Endpoint *other_endp = &op->endpoint_;
for (TAO_IIOP_Endpoint *endp = &this->endpoint_;
endp != 0;
endp = endp->next_)
{
if (endp->is_equivalent (other_endp))
other_endp = other_endp->next_;
else
return false;
}
return true;
}
| int TAO_IIOP_Profile::encode_alternate_endpoints | ( | void | ) | [virtual] |
Encode alternate endpoints for non-RT profiles, using multiple TAG_ALTERNATE_IIOP_ADDRESS components, one endpoint per component
Reimplemented from TAO_Profile.
Definition at line 612 of file IIOP_Profile.cpp.
{
// encode IOP::TAG_ALTERNATE_IIOP_ADDRESS tags if there are more
// than one endpoints to listen to.
const TAO_IIOP_Endpoint *endpoint = &this->endpoint_;
for (CORBA::ULong i = 1;
i < this->count_;
++i)
{
// The first endpoint is the actual endpoint. The rest of the
// endpoints are the alternate endpoints. So, neglect the first
// endpoint for TAG_ALTERNATE_IIOP_ADDRESS
endpoint = endpoint->next_;
if (!endpoint->is_encodable_)
continue;
// Encode the data structure. - The CORBA specification does not
// mandate a particular container for the endpoints, only that
// it is encoded as host first, then port.
TAO_OutputCDR out_cdr;
#if defined (ACE_HAS_IPV6)
// For IPv6 decimal addresses make sure the possibly included scopeid
// is not published as this has only local meaning.
const char* host = 0;
const char* pos = 0;
if (endpoint->is_ipv6_decimal_ &&
(pos = ACE_OS::strchr (host = endpoint->host (), '%')) != 0)
{
ACE_CString tmp;
size_t len = pos - host;
tmp.set (endpoint->host (), len, 1);
if (!(out_cdr << ACE_OutputCDR::from_boolean (TAO_ENCAP_BYTE_ORDER))
|| !(out_cdr << tmp.c_str ())
|| !(out_cdr << endpoint->port ()))
return -1;
out_cdr.write_string (len, endpoint->host ());
}
else
#endif /* ACE_HAS_IPV6 */
if (!(out_cdr << ACE_OutputCDR::from_boolean (TAO_ENCAP_BYTE_ORDER))
|| !(out_cdr << endpoint->host ())
|| !(out_cdr << endpoint->port ()))
return -1;
IOP::TaggedComponent tagged_component;
tagged_component.tag = IOP::TAG_ALTERNATE_IIOP_ADDRESS;
size_t length = out_cdr.total_length ();
tagged_component.component_data.length
(static_cast<CORBA::ULong>(length));
CORBA::Octet *buf =
tagged_component.component_data.get_buffer ();
for (const ACE_Message_Block *iterator = out_cdr.begin ();
iterator != 0;
iterator = iterator->cont ())
{
size_t i_length = iterator->length ();
ACE_OS::memcpy (buf, iterator->rd_ptr (), i_length);
buf += i_length;
}
// Add component with encoded endpoint data to this profile's
// TaggedComponents.
tagged_components_.set_component (tagged_component);
}
return 0;
}
| int TAO_IIOP_Profile::encode_endpoints | ( | void | ) | [virtual] |
Encode endpoints for RT profiles, using a single TAO_TAG_ENDPOINT component.
Implements TAO_Profile.
Definition at line 685 of file IIOP_Profile.cpp.
{
CORBA::ULong actual_count = 0;
const TAO_IIOP_Endpoint *endpoint = &this->endpoint_;
// Count the number of endpoints that needs to be encoded
for (CORBA::ULong c = 0;
c != this->count_;
++c)
{
if (endpoint->is_encodable_)
++actual_count;
endpoint = endpoint->next_;
}
// Create a data structure and fill it with endpoint info for wire
// transfer.
// We include information for the head of the list
// together with other endpoints because even though its addressing
// info is transmitted using standard ProfileBody components, its
// priority is not!
TAO::IIOPEndpointSequence endpoints;
endpoints.length (actual_count);
endpoint = &this->endpoint_;
for (CORBA::ULong i = 0;
i < actual_count;
++i)
{
if (endpoint->is_encodable_)
{
#if defined (ACE_HAS_IPV6)
if (endpoint->is_ipv6_decimal_)
{
// Don't publish scopeid if included.
ACE_CString tmp(endpoint->host ());
ACE_CString::size_type pos = tmp.find('%');
if (pos != ACE_CString::npos)
{
tmp = tmp.substr (0, pos + 1);
tmp[pos] = '\0';
endpoints[i].host = tmp.c_str();
}
else
endpoints[i].host = tmp.c_str();
}
else
#endif /* ACE_HAS_IPV6 */
endpoints[i].host = endpoint->host ();
endpoints[i].port = endpoint->port ();
endpoints[i].priority = endpoint->priority ();
}
endpoint = endpoint->next_;
}
// Encode the data structure.
TAO_OutputCDR out_cdr;
if (!(out_cdr << ACE_OutputCDR::from_boolean (TAO_ENCAP_BYTE_ORDER))
|| !(out_cdr << endpoints))
return -1;
this->set_tagged_components (out_cdr);
return 0;
}
| int TAO_IIOP_Profile::encode_endpoints_for_rt | ( | void | ) | [protected] |
Helper method for encode_endpoints to deal with RT requests.
Encodes this profile's endpoints into a tagged component. This is done only if RTCORBA is enabled, since currently this is the only case when we have more than one endpoint per profile. Returns 0 on success and -1 on failure.
Endpoints are transmitted using TAO-proprietory tagged component. Component tag is TAO_TAG_ENDPOINTS and component data is an encapsulation of a sequence of structs, each representing a single endpoint. Data format is specified in iiop_endpoins.pidl.
| TAO_Endpoint * TAO_IIOP_Profile::endpoint | ( | void | ) | [virtual] |
Return a pointer to this profile's endpoint. If the profile contains more than one endpoint, i.e., a list, the method returns the head of the list.
Implements TAO_Profile.
Definition at line 380 of file IIOP_Profile.cpp.
{
return &this->endpoint_;
}
| CORBA::ULong TAO_IIOP_Profile::endpoint_count | ( | void | ) | const [virtual] |
Return how many endpoints this profile contains.
Implements TAO_Profile.
Definition at line 394 of file IIOP_Profile.cpp.
{
return this->count_;
}
| CORBA::ULong TAO_IIOP_Profile::hash | ( | CORBA::ULong | max | ) | [virtual] |
Return a hash value for this object.
Implements TAO_Profile.
Definition at line 351 of file IIOP_Profile.cpp.
{
// Get the hash value for all endpoints.
CORBA::ULong hashval = 0;
for (TAO_IIOP_Endpoint *endp = &this->endpoint_;
endp != 0;
endp = endp->next_)
{
hashval += endp->hash ();
}
hashval += this->version_.minor;
hashval += this->tag ();
const TAO::ObjectKey &ok =
this->ref_object_key_->object_key ();
if (ok.length () >= 4)
{
hashval += ok[1];
hashval += ok[3];
}
hashval += TAO_Profile::hash_service_i (max);
return hashval % max;
}
| char TAO_IIOP_Profile::object_key_delimiter | ( | void | ) | const [virtual] |
The object key delimiter that IIOP uses or expects.
Implements TAO_Profile.
Definition at line 44 of file IIOP_Profile.cpp.
{
return TAO_IIOP_Profile::object_key_delimiter_;
}
| void TAO_IIOP_Profile::parse_string_i | ( | const char * | string | ) | [protected, virtual] |
Protocol specific implementation of parse_string ().
Implements TAO_Profile.
Definition at line 133 of file IIOP_Profile.cpp.
{
// Pull off the "hostname:port/" part of the objref
// Copy the string because we are going to modify it...
const char *okd = ACE_OS::strchr (ior, this->object_key_delimiter_);
if (okd == 0 || okd == ior)
{
// No object key delimiter or no hostname specified.
throw ::CORBA::INV_OBJREF (
CORBA::SystemException::_tao_minor_code (
0,
EINVAL),
CORBA::COMPLETED_NO);
}
// Length of host string.
CORBA::ULong length_host = 0;
const char *cp_pos_overrun = ACE_OS::strchr (ior, ':'); // Look for a port
const char *cp_pos = (cp_pos_overrun < okd) ? cp_pos_overrun : 0; // but before object key
#if defined (ACE_HAS_IPV6)
// IPv6 numeric address in host string?
bool ipv6_in_host = false;
// Check if this is a (possibly) IPv6 supporting profile containing a
// decimal IPv6 address representation.
if ((this->version().major > TAO_MIN_IPV6_IIOP_MAJOR ||
this->version().minor >= TAO_MIN_IPV6_IIOP_MINOR) &&
ior[0] == '[')
{
// In this case we have to find the end of the numeric address and
// start looking for the port separator from there.
const char *cp_pos_a_overrun = ACE_OS::strchr(ior, ']');
const char *cp_pos_a = (cp_pos_a_overrun < okd) ? cp_pos_a_overrun : 0; // before object key
if (cp_pos_a == 0)
{
// No valid IPv6 address specified.
if (TAO_debug_level > 0)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("\nTAO (%P|%t) IIOP_Profile: ")
ACE_TEXT ("Invalid IPv6 decimal address specified.\n")));
}
throw ::CORBA::INV_OBJREF (
CORBA::SystemException::_tao_minor_code (
0,
EINVAL),
CORBA::COMPLETED_NO);
}
else
{
if (cp_pos_a[1] == ':') // Look for a port
cp_pos = cp_pos_a + 1;
else
cp_pos = 0;
ipv6_in_host = true; // host string contains full IPv6 numeric address
}
}
#endif /* ACE_HAS_IPV6 */
if (cp_pos == ior)
{
// No hostname, however one is required by the spec when specifying a port.
// See formal-04-03-01, section 13.6.10.3
if (TAO_debug_level > 0)
{
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("\nTAO (%P|%t) IIOP_Profile: ")
ACE_TEXT ("Host address may be omited only when no port has been specified.\n")));
}
throw ::CORBA::INV_OBJREF (
CORBA::SystemException::_tao_minor_code (
0,
EINVAL),
CORBA::COMPLETED_NO);
}
else if (cp_pos != 0)
{
// A port number or port name was specified.
CORBA::ULong length_port = okd - cp_pos - 1;
CORBA::String_var tmp = CORBA::string_alloc (length_port);
if (tmp.in() != 0)
{
ACE_OS::strncpy (tmp.inout (), cp_pos + 1, length_port);
tmp[length_port] = '\0';
}
if (length_port == 0)
{
this->endpoint_.port_ = 2809; // default IIOP port for
// parsing corbaloc strings
}
else if (tmp.in () != 0 && ACE_OS::strspn (tmp.in (), "1234567890") == length_port)
{
this->endpoint_.port_ =
static_cast<CORBA::UShort> (ACE_OS::atoi (tmp.in ()));
}
else
{
ACE_INET_Addr ia;
if (tmp.in () == 0 || ia.string_to_addr (tmp.in ()) == -1)
{
throw ::CORBA::INV_OBJREF (
CORBA::SystemException::_tao_minor_code (
0,
EINVAL),
CORBA::COMPLETED_NO);
}
else
{
this->endpoint_.port_ = ia.get_port_number ();
}
}
length_host = cp_pos - ior;
}
else
length_host = okd - ior;
#if defined (ACE_HAS_IPV6)
if (ipv6_in_host)
length_host -= 2; // don't store '[' and ']'
#endif /* ACE_HAS_IPV6 */
CORBA::String_var tmp = CORBA::string_alloc (length_host);
#if defined (ACE_HAS_IPV6)
if (ipv6_in_host)
ACE_OS::strncpy (tmp.inout (), ior + 1, length_host);
else
#endif /* ACE_HAS_IPV6 */
// Skip the trailing '/'
ACE_OS::strncpy (tmp.inout (), ior, length_host);
tmp[length_host] = '\0';
this->endpoint_.host_ = tmp._retn ();
#if defined (ACE_HAS_IPV6)
this->endpoint_.is_ipv6_decimal_ = ipv6_in_host;
#endif /* ACE_HAS_IPV6 */
if (ACE_OS::strcmp (this->endpoint_.host_.in (), "") == 0)
{
ACE_INET_Addr host_addr;
char tmp_host [MAXHOSTNAMELEN + 1];
// If no host is specified: assign the default host, i.e. the
// local host.
if (host_addr.get_host_name (tmp_host,
sizeof (tmp_host)) != 0)
{
// Can't get the IP address since the INET_Addr wasn't
// initialized. Just throw an exception.
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("\n\nTAO (%P|%t) ")
ACE_TEXT ("IIOP_Profile::parse_string ")
ACE_TEXT ("- %p\n\n"),
ACE_TEXT ("cannot determine hostname")));
// @@ What's the right exception to throw here?
throw ::CORBA::INV_OBJREF (
CORBA::SystemException::_tao_minor_code (
0,
EINVAL),
CORBA::COMPLETED_NO);
}
else
this->endpoint_.host_ = CORBA::string_dup (tmp_host);
}
TAO::ObjectKey ok;
TAO::ObjectKey::decode_string_to_sequence (ok,
okd + 1);
(void) this->orb_core ()->object_key_table ().bind (ok,
this->ref_object_key_);
}
| const char * TAO_IIOP_Profile::prefix | ( | void | ) | [static] |
Return the char string prefix.
Definition at line 562 of file IIOP_Profile.cpp.
{
return ::the_prefix;
}
| void TAO_IIOP_Profile::remove_endpoint | ( | TAO_IIOP_Endpoint * | endp | ) |
Remove endp from this profile's list of endpoints and free the endp memory. This method assumes endp is in this profile's endpoint list.
Definition at line 409 of file IIOP_Profile.cpp.
{
if (endp == 0)
return;
// special handling for the target matching the base endpoint
if (endp == &this->endpoint_)
{
if (--this->count_ > 0)
{
TAO_IIOP_Endpoint* n = this->endpoint_.next_;
this->endpoint_ = *n;
// since the assignment operator does not copy the next_
// pointer, we must do it by hand
this->endpoint_.next_ = n->next_;
if (this->last_endpoint_ == n)
{
this->last_endpoint_ = &this->endpoint_;
}
delete n;
}
return;
}
TAO_IIOP_Endpoint* prev = &this->endpoint_;
TAO_IIOP_Endpoint* cur = this->endpoint_.next_;
while (cur != 0)
{
if (cur == endp)
break;
prev = cur;
cur = cur->next_;
}
if (cur != 0)
{
prev->next_ = cur->next_;
cur->next_ = 0;
--this->count_;
if (this->last_endpoint_ == cur)
{
this->last_endpoint_ = prev;
}
delete cur;
}
}
| void TAO_IIOP_Profile::remove_generic_endpoint | ( | TAO_Endpoint * | ep | ) | [virtual] |
Remove the provided endpoint from the profile. Some subclasses of TAO_Profile already have a protocol-specific version of remove_endpoint, but this generic interface is required. The default implementation is a no-op. Protocol maintainers wishing to add support for the EndpointPolicy must implement remove_generic_endpoint to call their protocol-specific version of remove_endpoint
Reimplemented from TAO_Profile.
Definition at line 458 of file IIOP_Profile.cpp.
{
this->remove_endpoint(dynamic_cast<TAO_IIOP_Endpoint *>(ep));
}
| char * TAO_IIOP_Profile::to_string | ( | void | ) | [virtual] |
Template methods. Please see Profile.h for documentation.
Implements TAO_Profile.
Definition at line 476 of file IIOP_Profile.cpp.
{
// corbaloc:iiop:1.2@host:port,iiop:1.2@host:port,.../key
CORBA::String_var key;
TAO::ObjectKey::encode_sequence_to_string (key.inout(),
this->ref_object_key_->object_key ());
size_t buflen = (
8 /* "corbaloc" */ +
1 /* colon separator */ +
1 /* object key separator */ +
ACE_OS::strlen (key.in ()));
size_t const pfx_len = (
ACE_OS::strlen (::the_prefix) /* "iiop" */ +
1 /* colon separator */);
const TAO_IIOP_Endpoint *endp = 0;
for (endp = &this->endpoint_; endp != 0; endp = endp->next_)
{
buflen += (
pfx_len +
1 /* major version */ +
1 /* decimal point */ +
1 /* minor version */ +
1 /* `@' character */ +
ACE_OS::strlen (endp->host ()) +
1 /* colon separator */ +
5 /* port number */ +
1 /* comma */);
#if defined (ACE_HAS_IPV6)
if (endp->is_ipv6_decimal_)
buflen += 2; // room for '[' and ']'
#endif /* ACE_HAS_IPV6 */
}
static const char digits [] = "0123456789";
char * buf = CORBA::string_alloc (static_cast<CORBA::ULong> (buflen));
ACE_OS::strcpy(buf, "corbaloc:");
for (endp = &this->endpoint_; endp != 0; endp = endp->next_)
{
if(&this->endpoint_ != endp)
ACE_OS::strcat(buf, ",");
#if defined (ACE_HAS_IPV6)
if (endp->is_ipv6_decimal_)
{
// Don't publish scopeid if included.
ACE_CString tmp(endp->host ());
ACE_CString::size_type pos = tmp.find('%');
if (pos != ACE_CString::npos)
{
tmp = tmp.substr(0, pos + 1);
tmp[pos] = '\0';
}
ACE_OS::sprintf (buf + ACE_OS::strlen(buf),
"%s:%c.%c@[%s]:%d",
::the_prefix,
digits [this->version_.major],
digits [this->version_.minor],
tmp.c_str (),
endp->port () );
}
else
#endif
ACE_OS::sprintf (buf + ACE_OS::strlen(buf),
"%s:%c.%c@%s:%d",
::the_prefix,
digits [this->version_.major],
digits [this->version_.minor],
endp->host (),
endp->port () );
}
ACE_OS::sprintf (buf + ACE_OS::strlen(buf),
"%c%s",
this->object_key_delimiter_,
key.in ());
return buf;
}
CORBA::ULong TAO_IIOP_Profile::count_ [protected] |
Number of endpoints in the list headed by <endpoint_>.
Definition at line 191 of file IIOP_Profile.h.
TAO_IIOP_Endpoint TAO_IIOP_Profile::endpoint_ [protected] |
Head of this profile's list of endpoints. This endpoint is not dynamically allocated because a profile always contains at least one endpoint.
Currently, a profile contains more than one endpoint, i.e., list contains more than just the head, only for two cases (1) when RTCORBA is enabled and (2) the ORB is initialized with -ORBPreferredInterfaces option. However, in the near future, this will be used in for mode as well, e.g., to support TAG_ALTERNATE_IIOP_ADDRESS feature.
This is probably as good a place to discuss how the list of endpoints is used for #2. If the ORB is configured to use preferred interfaces for invocation, TAO creates an endpoint per preferred interface. To be clear, every tuple <destination:target> will have an endpoint. What TAO essentially does is that creates it multiple endpoints so that the invocation code path can use existing iterating techniques to try one preferred interface after another (if the first did not work). If the ORB is configured with -ORBEnforcePreferredInterface set to false in addition to the ORBPreferredInterfaces option , TAO creates another endpoint with the preferred bit set to null, so that the invocation code can fall back to a TCP stack returned local address. Addressing info of the default endpoint, i.e., head of the list, is transmitted using standard IIOP ProfileBody components. See <encode_endpoints> method documentation above for how the rest of the endpoint list is transmitted.
Definition at line 185 of file IIOP_Profile.h.
TAO_IIOP_Endpoint* TAO_IIOP_Profile::last_endpoint_ [protected] |
For efficient insertion at the end of the list.
Definition at line 188 of file IIOP_Profile.h.
const char TAO_IIOP_Profile::object_key_delimiter_ = '/' [static] |
Definition at line 49 of file IIOP_Profile.h.
1.7.0
