#include <DIOP_Acceptor.h>
Public Member Functions | |
| TAO_DIOP_Acceptor (void) | |
| Constructor. | |
| ~TAO_DIOP_Acceptor (void) | |
| Destructor. | |
| const ACE_INET_Addr & | address (void) const |
| const ACE_INET_Addr * | endpoints (void) |
| Returns the array of endpoints in this acceptor. | |
| const ACE_INET_Addr & | default_address (void) const |
| Returns address for default endpoint. | |
| void | set_default_address (const ACE_INET_Addr &addr) |
| Set address for default endpoint. | |
| virtual int | hostname (TAO_ORB_Core *orb_core, ACE_INET_Addr &addr, char *&host, const char *specified_hostname=0) |
| int | dotted_decimal_address (ACE_INET_Addr &addr, char *&host) |
The TAO_Acceptor Methods | |
Please check the documentation in Transport_Acceptor.h for details. | |
| virtual int | open (TAO_ORB_Core *orb_core, ACE_Reactor *reactor, int version_major, int version_minor, const char *address, const char *options=0) |
| Method to initialize acceptor for address. | |
| virtual int | open_default (TAO_ORB_Core *orb_core, ACE_Reactor *reactor, int version_major, int version_minor, const char *options=0) |
| virtual int | close (void) |
| Closes the acceptor. | |
| virtual int | create_profile (const TAO::ObjectKey &object_key, TAO_MProfile &mprofile, CORBA::Short priority) |
| virtual int | is_collocated (const TAO_Endpoint *endpoint) |
| Return 1 if the endpoint has the same address as the acceptor. | |
| virtual CORBA::ULong | endpoint_count (void) |
| virtual int | object_key (IOP::TaggedProfile &profile, TAO::ObjectKey &key) |
Protected Member Functions | |
| int | parse_address (const char *address, ACE_INET_Addr &addr, ACE_CString &specified_hostname, int *def_type=0) |
| virtual int | open_i (const ACE_INET_Addr &addr, ACE_Reactor *reactor) |
| int | probe_interfaces (TAO_ORB_Core *orb_core, int def_type=AF_UNSPEC) |
| virtual int | parse_options (const char *options) |
| Parse protocol specific options. | |
| int | create_new_profile (const TAO::ObjectKey &object_key, TAO_MProfile &mprofile, CORBA::Short priority) |
| int | create_shared_profile (const TAO::ObjectKey &object_key, TAO_MProfile &mprofile, CORBA::Short priority) |
Protected Attributes | |
| ACE_INET_Addr * | addrs_ |
| char ** | hosts_ |
| CORBA::ULong | endpoint_count_ |
| TAO_GIOP_Message_Version | version_ |
| TAO_ORB_Core * | orb_core_ |
| ORB Core. | |
| ACE_INET_Addr | default_address_ |
| Address for default endpoint. | |
Private Attributes | |
| TAO_DIOP_Connection_Handler * | connection_handler_ |
The DIOP-specific bridge class for the concrete acceptor.
Definition at line 46 of file DIOP_Acceptor.h.
| TAO_DIOP_Acceptor::TAO_DIOP_Acceptor | ( | void | ) |
Constructor.
Definition at line 31 of file DIOP_Acceptor.cpp.
: TAO_Acceptor (TAO_TAG_DIOP_PROFILE), addrs_ (0), hosts_ (0), endpoint_count_ (0), version_ (TAO_DEF_GIOP_MAJOR, TAO_DEF_GIOP_MINOR), orb_core_ (0), #if defined (ACE_HAS_IPV6) default_address_ (static_cast<unsigned short> (0), ACE_IPV6_ANY, AF_INET6), #else default_address_ (static_cast<unsigned short> (0), static_cast<ACE_UINT32> (INADDR_ANY)), #endif /* ACE_HAS_IPV6 */ connection_handler_ (0) { }
| TAO_DIOP_Acceptor::~TAO_DIOP_Acceptor | ( | void | ) |
Destructor.
Definition at line 47 of file DIOP_Acceptor.cpp.
{
// Make sure we are closed before we start destroying the
// strategies.
this->close ();
delete [] this->addrs_;
for (CORBA::ULong i = 0; i < this->endpoint_count_; ++i)
CORBA::string_free (this->hosts_[i]);
delete [] this->hosts_;
}
| const ACE_INET_Addr & TAO_DIOP_Acceptor::address | ( | void | ) | const |
@ Helper method for the implementation repository, should go away
Definition at line 8 of file DIOP_Acceptor.inl.
{
ACE_ASSERT (this->addrs_ != 0);
// @@ This is busted.
// The Implementation Repository will have to start supporting
// IORs with multiple profiles. For now, we just return the
// first addr.
// -Ossama
return this->addrs_[0];
}
| int TAO_DIOP_Acceptor::close | ( | void | ) | [virtual] |
Closes the acceptor.
Implements TAO_Acceptor.
Definition at line 239 of file DIOP_Acceptor.cpp.
{
return 0;
}
| int TAO_DIOP_Acceptor::create_new_profile | ( | const TAO::ObjectKey & | object_key, | |
| TAO_MProfile & | mprofile, | |||
| CORBA::Short | priority | |||
| ) | [protected] |
Helper method to add a new profile to the mprofile for each endpoint.
Definition at line 83 of file DIOP_Acceptor.cpp.
{
// Adding this->endpoint_count_ to the TAO_MProfile.
int count = mprofile.profile_count ();
if ((mprofile.size () - count) < this->endpoint_count_
&& mprofile.grow (count + this->endpoint_count_) == -1)
return -1;
// Create a profile for each acceptor endpoint.
for (CORBA::ULong i = 0; i < this->endpoint_count_; ++i)
{
// Skip if the host name
if (i > 0
&& (this->addrs_[i].get_port_number () == this->addrs_[0].get_port_number ())
&& ACE_OS::strcmp (this->hosts_[i], this->hosts_[0]) == 0)
continue;
TAO_DIOP_Profile *pfile = 0;
ACE_NEW_RETURN (pfile,
TAO_DIOP_Profile (this->hosts_[i],
this->addrs_[i].get_port_number (),
object_key,
this->addrs_[i],
this->version_,
this->orb_core_),
-1);
pfile->endpoint ()->priority (priority);
if (mprofile.give_profile (pfile) == -1)
{
pfile->_decr_refcnt ();
pfile = 0;
return -1;
}
// Do not add any tagged components to the profile if configured
// by the user not to do so, or if an IIOP 1.0 endpoint is being
// created (IIOP 1.0 did not support tagged components).
if (this->orb_core_->orb_params ()->std_profile_components () == 0
|| (this->version_.major == 1 && this->version_.minor == 0))
continue;
pfile->tagged_components ().set_orb_type (TAO_ORB_TYPE);
TAO_Codeset_Manager *csm = this->orb_core_->codeset_manager ();
if (csm)
csm->set_codeset (pfile->tagged_components ());
}
return 0;
}
| int TAO_DIOP_Acceptor::create_profile | ( | const TAO::ObjectKey & | object_key, | |
| TAO_MProfile & | mprofile, | |||
| CORBA::Short | priority | |||
| ) | [virtual] |
Create the corresponding profile for this endpoint. If share_profile is set to true, the pluggable protocol implementation should try to add the endpoint to a profile in the mprofile that is of the same type. Currently, this is used when RT CORBA is enabled.
Implements TAO_Acceptor.
Definition at line 65 of file DIOP_Acceptor.cpp.
{
// Sanity check.
if (this->endpoint_count_ == 0)
return -1;
// Check if multiple endpoints should be put in one profile or if
// they should be spread across multiple profiles.
if (priority == TAO_INVALID_PRIORITY &&
this->orb_core_->orb_params ()->shared_profile () == 0)
return this->create_new_profile (object_key, mprofile, priority);
else
return this->create_shared_profile (object_key, mprofile, priority);
}
| int TAO_DIOP_Acceptor::create_shared_profile | ( | const TAO::ObjectKey & | object_key, | |
| TAO_MProfile & | mprofile, | |||
| CORBA::Short | priority | |||
| ) | [protected] |
Helper method to create a profile that contains all of our endpoints.
Definition at line 138 of file DIOP_Acceptor.cpp.
{
CORBA::ULong index = 0;
TAO_DIOP_Profile *diop_profile = 0;
// First see if <mprofile> already contains a DIOP profile.
for (TAO_PHandle i = 0; i != mprofile.profile_count (); ++i)
{
TAO_Profile *pfile = mprofile.get_profile (i);
if (pfile->tag () == TAO_TAG_DIOP_PROFILE)
{
diop_profile = dynamic_cast<TAO_DIOP_Profile *> (pfile);
break;
}
}
// If <mprofile> doesn't contain a DIOP_Profile, we need to create
// one.
if (diop_profile == 0)
{
ACE_NEW_RETURN (diop_profile,
TAO_DIOP_Profile (this->hosts_[0],
this->addrs_[0].get_port_number (),
object_key,
this->addrs_[0],
this->version_,
this->orb_core_),
-1);
diop_profile->endpoint ()->priority (priority);
if (mprofile.give_profile (diop_profile) == -1)
{
diop_profile->_decr_refcnt ();
diop_profile = 0;
return -1;
}
if (this->orb_core_->orb_params ()->std_profile_components () != 0
&& (this->version_.major >= 1 && this->version_.minor >= 1))
{
diop_profile->tagged_components ().set_orb_type (TAO_ORB_TYPE);
TAO_Codeset_Manager *csm = this->orb_core_->codeset_manager ();
if (csm)
csm->set_codeset (diop_profile->tagged_components ());
}
index = 1;
}
// Add any remaining acceptor endpoints to the DIOP_Profile.
for (;
index < this->endpoint_count_;
++index)
{
if (index > 0 &&
this->addrs_[index].get_port_number () == this->addrs_[0].get_port_number () &&
ACE_OS::strcmp (this->hosts_[index], this->hosts_[0]) == 0)
continue;
TAO_DIOP_Endpoint *endpoint = 0;
ACE_NEW_RETURN (endpoint,
TAO_DIOP_Endpoint (this->hosts_[index],
this->addrs_[index].get_port_number (),
this->addrs_[index]),
-1);
endpoint->priority (priority);
diop_profile->add_endpoint (endpoint);
}
return 0;
}
| const ACE_INET_Addr & TAO_DIOP_Acceptor::default_address | ( | void | ) | const |
Returns address for default endpoint.
Definition at line 29 of file DIOP_Acceptor.inl.
{
return this->default_address_;
}
| int TAO_DIOP_Acceptor::dotted_decimal_address | ( | ACE_INET_Addr & | addr, | |
| char *& | host | |||
| ) |
Set the host name for the given address using the dotted decimal format.
Definition at line 651 of file DIOP_Acceptor.cpp.
{
int result = 0;
const char *tmp = 0;
// If the IP address in the INET_Addr is the IN(6)ADDR_ANY address,
// then force the actual IP address to be used by initializing a new
// INET_Addr with the hostname from the original one. If that fails
// then something is seriously wrong with the systems networking
// setup.
if (addr.is_any ())
{
ACE_INET_Addr new_addr;
#if defined (ACE_HAS_IPV6)
result = new_addr.set (addr.get_port_number (),
addr.get_host_name (),
1, /* encode */
addr.get_type ());
#else /* ACE_HAS_IPV6 */
result = new_addr.set (addr.get_port_number (),
addr.get_host_name ());
#endif /* !ACE_HAS_IPV6 */
tmp = new_addr.get_host_addr ();
}
else
tmp = addr.get_host_addr ();
if (tmp == 0 || result != 0)
{
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - ")
ACE_TEXT ("DIOP_Acceptor::dotted_decimal_address, ")
ACE_TEXT ("%p\n\n"),
ACE_TEXT ("cannot determine hostname")));
return -1;
}
host = CORBA::string_dup (tmp);
return 0;
}
| CORBA::ULong TAO_DIOP_Acceptor::endpoint_count | ( | void | ) | [virtual] |
Returns the number of endpoints this acceptor is listening on. This is used for determining how many profiles will be generated for this acceptor.
Implements TAO_Acceptor.
Definition at line 904 of file DIOP_Acceptor.cpp.
{
return this->endpoint_count_;
}
| const ACE_INET_Addr * TAO_DIOP_Acceptor::endpoints | ( | void | ) |
Returns the array of endpoints in this acceptor.
Definition at line 21 of file DIOP_Acceptor.inl.
{
ACE_ASSERT (this->addrs_ != 0);
return this->addrs_;
}
| int TAO_DIOP_Acceptor::hostname | ( | TAO_ORB_Core * | orb_core, | |
| ACE_INET_Addr & | addr, | |||
| char *& | host, | |||
| const char * | specified_hostname = 0 | |||
| ) | [virtual] |
Set the host name for the given addr. A hostname may be forced by using specified_hostname. This is useful if the given address corresponds to more than one hostname and the desired one cannot be determined in any other way.
Definition at line 468 of file DIOP_Acceptor.cpp.
{
if (orb_core->orb_params ()->use_dotted_decimal_addresses ())
{
// If dotted decimal addresses are enabled,
// just return ours.
return this->dotted_decimal_address (addr, host);
}
else if (specified_hostname != 0)
{
// If the user specified a hostname, pass it back
// blindly as it overrides our choice of hostname.
host = CORBA::string_dup (specified_hostname);
}
else
{
char tmp_host[MAXHOSTNAMELEN + 1];
// Get the hostname associated with our address
#if defined (ACE_HAS_IPV6)
// If we have a IPv4-compatible IPv6 address don't do hostname lookup
// because that gets us into trouble. Most likely we get the same hostname
// returned as for the actual IPv4 address but resolving that into an IPv6
// address at the client will fail.
if (addr.is_ipv4_compat_ipv6 () ||
addr.get_host_name (tmp_host, sizeof (tmp_host)) != 0)
#else /* ACE_HAS_IPV6 */
if (addr.get_host_name (tmp_host, sizeof (tmp_host)) != 0)
#endif /* !ACE_HAS_IPV6 */
{
// On failure, just return the decimal address.
return this->dotted_decimal_address (addr, host);
}
else
{
host = CORBA::string_dup (tmp_host);
}
}
return 0;
}
| int TAO_DIOP_Acceptor::is_collocated | ( | const TAO_Endpoint * | endpoint | ) | [virtual] |
Return 1 if the endpoint has the same address as the acceptor.
Implements TAO_Acceptor.
Definition at line 213 of file DIOP_Acceptor.cpp.
{
const TAO_DIOP_Endpoint *endp =
dynamic_cast<const TAO_DIOP_Endpoint *> (endpoint);
// Make sure the dynamically cast pointer is valid.
if (endp == 0)
return 0;
for (CORBA::ULong i = 0; i < this->endpoint_count_; ++i)
{
// compare the port and host name. Please do *NOT* optimize
// this code by comparing the IP address instead. That would
// trigger the following bug:
//
// http://deuce.doc.wustl.edu/bugzilla/show_bug.cgi?id=1220
//
if (endp->port () == this->addrs_[i].get_port_number ()
&& ACE_OS::strcmp (endp->host (), this->hosts_[i]) == 0)
return 1; // Collocated
}
return 0; // Not collocated
}
| int TAO_DIOP_Acceptor::object_key | ( | IOP::TaggedProfile & | profile, | |
| TAO::ObjectKey & | key | |||
| ) | [virtual] |
This method fetches the key from the profile. Protocols that are pluggable can send data that are specific in the profile_data field encapsulated as a octet stream. This method allows those protocols to get the object key from the encapsulation.
Implements TAO_Acceptor.
Definition at line 910 of file DIOP_Acceptor.cpp.
{
// Create the decoding stream from the encapsulation in the buffer,
#if (TAO_NO_COPY_OCTET_SEQUENCES == 1)
TAO_InputCDR cdr (profile.profile_data.mb ());
#else
TAO_InputCDR cdr (reinterpret_cast<char*> (profile.profile_data.get_buffer ()),
profile.profile_data.length ());
#endif /* TAO_NO_COPY_OCTET_SEQUENCES == 1 */
CORBA::Octet major;
CORBA::Octet minor = CORBA::Octet();
// Read the version. We just read it here. We don't*do any*
// processing.
if (!(cdr.read_octet (major)
&& cdr.read_octet (minor)))
{
if (TAO_debug_level > 0)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - DIOP_Profile::object_key, v%d.%d\n"),
major,
minor));
}
return -1;
}
CORBA::String_var host;
CORBA::UShort port = 0;
// Get host and port. No processing here too..
if (cdr.read_string (host.out ()) == 0
|| cdr.read_ushort (port) == 0)
{
if (TAO_debug_level > 0)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - DIOP_Acceptor::object_key, ")
ACE_TEXT ("error while decoding host/port")));
}
return -1;
}
// ... and object key.
if ((cdr >> object_key) == 0)
return -1;
// We are NOT bothered about the rest.
return 1;
}
| int TAO_DIOP_Acceptor::open | ( | TAO_ORB_Core * | orb_core, | |
| ACE_Reactor * | reactor, | |||
| int | version_major, | |||
| int | version_minor, | |||
| const char * | address, | |||
| const char * | options = 0 | |||
| ) | [virtual] |
Method to initialize acceptor for address.
Implements TAO_Acceptor.
Definition at line 245 of file DIOP_Acceptor.cpp.
{
this->orb_core_ = orb_core;
if (this->hosts_ != 0)
{
// The hostname cache has already been set!
// This is bad mojo, i.e. an internal TAO error.
ACE_ERROR_RETURN ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - ")
ACE_TEXT ("DIOP_Acceptor::open, ")
ACE_TEXT ("hostname already set\n\n")),
-1);
}
if (address == 0)
return -1;
if (major >=0 && minor >= 0)
this->version_.set_version (static_cast<CORBA::Octet> (major),
static_cast<CORBA::Octet> (minor));
// Parse options
if (this->parse_options (options) == -1)
return -1;
ACE_CString specified_hostname;
ACE_INET_Addr addr;
int def_type = AF_UNSPEC;
if (this->parse_address (address,
addr,
specified_hostname,
&def_type) == -1)
return -1;
if (specified_hostname.length () == 0)
{
// The address is a port number or port name. No hostname was
// specified. The hostname for each network interface and the
// fully qualified domain name must be obtained.
// Check for multiple network interfaces.
if (this->probe_interfaces (orb_core, def_type) == -1)
return -1;
// Probe interfaces has a side effect of potentially modifying
// the default address, since that is where the address family
// is considered.
addr.set (this->default_address_);
return this->open_i (addr,
reactor);
}
#if defined (ACE_HAS_IPV6)
// Check for violation of ORBConnectIPV6Only option
if (this->orb_core_->orb_params ()->connect_ipv6_only () &&
(addr.get_type () != AF_INET6 ||
addr.is_ipv4_mapped_ipv6 ()))
{
ACE_ERROR_RETURN ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - ")
ACE_TEXT ("DIOP_Acceptor::open, ")
ACE_TEXT ("non-IPv6 endpoints not allowed when ")
ACE_TEXT ("connect_ipv6_only is set\n\n")),
-1);
}
#endif /* ACE_HAS_IPV6 */
if (TAO_debug_level > 2)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - ")
ACE_TEXT ("DIOP_Acceptor::open, specified host=%C:%d\n"),
(specified_hostname.length () == 0 ? "<null>" : specified_hostname.c_str ()),
addr.get_port_number ()));
}
this->endpoint_count_ = 1; // Only one hostname to store
ACE_NEW_RETURN (this->addrs_,
ACE_INET_Addr[this->endpoint_count_],
-1);
ACE_NEW_RETURN (this->hosts_,
char *[this->endpoint_count_],
-1);
this->hosts_[0] = 0;
if (this->hostname (orb_core,
addr,
this->hosts_[0],
specified_hostname.c_str ()) != 0)
return -1;
// Copy the addr. The port is (re)set in
// TAO_DIOP_Acceptor::open_i().
if (this->addrs_[0].set (addr) != 0)
return -1;
return this->open_i (addr,
reactor);
}
| int TAO_DIOP_Acceptor::open_default | ( | TAO_ORB_Core * | , | |
| ACE_Reactor * | reactor, | |||
| int | version_major, | |||
| int | version_minor, | |||
| const char * | options = 0 | |||
| ) | [virtual] |
Open an acceptor with the given protocol version on a default endpoint
Implements TAO_Acceptor.
Definition at line 356 of file DIOP_Acceptor.cpp.
{
this->orb_core_ = orb_core;
if (this->hosts_ != 0)
{
// The hostname cache has already been set!
// This is bad mojo, i.e. an internal TAO error.
ACE_ERROR_RETURN ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - ")
ACE_TEXT ("DIOP_Acceptor::open_default, ")
ACE_TEXT ("hostname already set\n\n")),
-1);
}
if (major >= 0 && minor >= 0)
this->version_.set_version (static_cast<CORBA::Octet> (major),
static_cast<CORBA::Octet> (minor));
// Parse options
if (this->parse_options (options) == -1)
return -1;
// Check for multiple network interfaces.
if (this->probe_interfaces (orb_core) == -1)
return -1;
// Now that each network interface's hostname has been cached, open
// an endpoint on each network interface using the INADDR_ANY
// address.
ACE_INET_Addr addr;
if (addr.set (this->default_address_) != 0)
return -1;
return this->open_i (addr, reactor);
}
| int TAO_DIOP_Acceptor::open_i | ( | const ACE_INET_Addr & | addr, | |
| ACE_Reactor * | reactor | |||
| ) | [protected, virtual] |
Implement the common part of the open*() methods. This method is virtual to allow a derived class implementation to be invoked instead.
Definition at line 399 of file DIOP_Acceptor.cpp.
{
ACE_NEW_RETURN (this->connection_handler_,
TAO_DIOP_Connection_Handler (this->orb_core_),
-1);
this->connection_handler_->local_addr (addr);
int result = this->connection_handler_->open_server ();
if (result == -1)
{
delete this->connection_handler_;
return result;
}
// Register only with a valid handle
result =
reactor->register_handler (this->connection_handler_,
ACE_Event_Handler::READ_MASK);
if (result == -1)
{
// Close the handler (this will also delete connection_handler_).
this->connection_handler_->close ();
return result;
}
// Connection handler ownership now belongs to the Reactor.
this->connection_handler_->remove_reference ();
ACE_INET_Addr address;
// We do this make sure the port number the endpoint is listening on
// gets set in the addr.
if (this->connection_handler_->peer ().get_local_addr (address) != 0)
{
if (TAO_debug_level > 0)
ACE_ERROR ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) DIOP_Acceptor::open_i, ")
ACE_TEXT ("%p"),
ACE_TEXT ("cannot get local addr\n\n")));
return -1;
}
// Set the port for each addr. If there is more than one network
// interface then the endpoint created on each interface will be on
// the same port. This is how a wildcard socket bind() is supposed
// to work.
unsigned short port = address.get_port_number ();
for (CORBA::ULong j = 0; j < this->endpoint_count_; ++j)
this->addrs_[j].set_port_number (port, 1);
this->default_address_.set_port_number (port);
if (TAO_debug_level > 5)
{
for (CORBA::ULong i = 0; i < this->endpoint_count_; ++i)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - DIOP_Acceptor::open_i, ")
ACE_TEXT ("listening on: <%C:%u>\n"),
this->hosts_[i],
this->addrs_[i].get_port_number ()));
}
}
return 0;
}
| int TAO_DIOP_Acceptor::parse_address | ( | const char * | address, | |
| ACE_INET_Addr & | addr, | |||
| ACE_CString & | specified_hostname, | |||
| int * | def_type = 0 | |||
| ) | [protected] |
Helper method Clear out 'addr' & 'specified_hostname' and initialize them based upon 'address'. If a non-zero pointer is passed in for def_type, this will be set to AF_INET6 if IPv6 support is enabled and supplied hostname is either [] or [::]. It will be set to AF_INET if the hostname is 0.0.0.0, otherwise it is set to AF_UNSPEC. This value is then passed to probe_interfaces by open.
Definition at line 514 of file DIOP_Acceptor.cpp.
{
{
ACE_INET_Addr tmp;
addr.set (tmp);
specified_hostname.clear();
}
const char *port_separator_loc = ACE_OS::strchr (address, ':');
char tmp_host[MAXHOSTNAMELEN + 1];
tmp_host[0] = '\0';
bool host_defaulted = port_separator_loc == address;
bool ipv6_in_host = false;
if (def_type)
*def_type = AF_UNSPEC;
#if defined (ACE_HAS_IPV6)
// Check if this is a (possibly) IPv6 supporting profile containing a
// numeric IPv6 address representation.
if ((this->version_.major > TAO_MIN_IPV6_IIOP_MAJOR ||
this->version_.minor >= TAO_MIN_IPV6_IIOP_MINOR) &&
address[0] == '[')
{
// In this case we have to find the end of the numeric address and
// start looking for the port separator from there.
char const * const cp_pos = ACE_OS::strchr (address, ']');
if (cp_pos == 0)
{
// No valid IPv6 address specified.
ACE_ERROR_RETURN ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - ")
ACE_TEXT ("DIOP_Acceptor::open, ")
ACE_TEXT ("invalid IPv6 decimal address specified\n\n")),
-1);
}
else
{
// Extract out just the host part of the address.
size_t const len = cp_pos - (address + 1);
if (len >= sizeof (tmp_host))
return -1;
ipv6_in_host = true;
host_defaulted = (cp_pos == address+1) ||
(cp_pos == address+3 && address[1] == ':' && address[2] == ':');
if (cp_pos[1] == ':') // Look for a port
port_separator_loc = cp_pos + 1;
else
port_separator_loc = 0;
if (def_type)
*def_type = AF_INET6;
ACE_OS::memcpy (tmp_host, address + 1, len);
tmp_host[len] = '\0';
}
}
else
#endif /* ACE_HAS_IPV6 */
if (!host_defaulted)
{
if (port_separator_loc != 0)
{
// Extract out just the host part of the address.
size_t const len = port_separator_loc - address;
if (len >= sizeof (tmp_host))
return -1;
ACE_OS::memcpy (tmp_host, address, len);
tmp_host[len] = '\0';
}
else
ACE_OS::strcpy (tmp_host, address);
}
if (!ipv6_in_host && !host_defaulted)
{
if (addr.set ((unsigned short) 0, tmp_host) != 0)
return -1;
this->default_address_.set (addr);
host_defaulted = addr.is_any ();
if (def_type)
*def_type = AF_INET;
}
if (host_defaulted)
{
// First convert the port into a usable form.
unsigned short portno = 0;
if (port_separator_loc != 0)
{
portno =
static_cast<u_short> (ACE_OS::atoi (port_separator_loc +
sizeof (':')));
}
this->default_address_.set_port_number (portno);
// Now reset the port and set the host.
if (addr.set (this->default_address_) != 0)
return -1;
}
else if (port_separator_loc == 0)
{
// The address is a hostname. No port was specified, so assume
// port zero (port will be chosen for us).
specified_hostname = tmp_host[0] == '\0' ? address : tmp_host;
if (addr.set ((unsigned short) 0,
specified_hostname.c_str ()) != 0)
return -1;
}
else
{
// Host and port were specified.
if (addr.set (address) != 0)
return -1;
if (tmp_host[0] == '\0')
{
// Extract out just the host part of the address.
size_t const len = port_separator_loc - address;
if (len >= sizeof (tmp_host))
return -1;
ACE_OS::memcpy (tmp_host, address, len);
tmp_host[len] = '\0';
}
specified_hostname = tmp_host;
}
return 1;
}
| int TAO_DIOP_Acceptor::parse_options | ( | const char * | options | ) | [protected, virtual] |
Parse protocol specific options.
Definition at line 965 of file DIOP_Acceptor.cpp.
{
if (str == 0)
return 0; // No options to parse. Not a problem.
// Use an option format similar to the one used for CGI scripts in
// HTTP URLs.
// e.g.: option1=foo&option2=bar
const ACE_CString options (str);
const size_t len = options.length ();
static const char option_delimiter = '&';
// Count the number of options.
CORBA::ULong option_count = 1;
// Only check for endpoints after the protocol specification and
// before the object key.
for (size_t i = 0; i < len; ++i)
if (options[i] == option_delimiter)
++option_count;
// The idea behind the following loop is to split the options into
// (option, name) pairs.
// For example,
// `option1=foo&option2=bar'
// will be parsed into:
// `option1=foo'
// `option2=bar'
ACE_CString::size_type begin = 0;
ACE_CString::size_type end = 0;
for (CORBA::ULong j = 0; j < option_count;)
{
if (j < option_count - 1)
end = options.find (option_delimiter, begin);
else
end = len;
++j; // In this way we fight MS VS warning about unreachable code.
if (end == begin)
{
ACE_ERROR_RETURN ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - Zero length DIOP option.\n")),
-1);
}
else if (end != ACE_CString::npos)
{
ACE_CString opt = options.substring (begin, end - begin);
ACE_CString::size_type const slot = opt.find ("=");
if (slot == len - 1
|| slot == ACE_CString::npos)
ACE_ERROR_RETURN ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - DIOP option <%C> is ")
ACE_TEXT ("missing a value.\n"),
opt.c_str ()),
-1);
ACE_CString name = opt.substring (0, slot);
ACE_CString value = opt.substring (slot + 1);
begin = end + 1;
if (name.length () == 0)
ACE_ERROR_RETURN ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - Zero length DIOP ")
ACE_TEXT ("option name.\n")),
-1);
if (name == "priority")
{
ACE_ERROR_RETURN ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - Invalid DIOP endpoint format: ")
ACE_TEXT ("endpoint priorities no longer supported.\n")),
-1);
}
else
{
ACE_ERROR_RETURN ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - Invalid DIOP option: <%C>\n"),
name.c_str ()),
-1);
}
}
else
{
break; // No other options.
}
}
return 0;
}
| int TAO_DIOP_Acceptor::probe_interfaces | ( | TAO_ORB_Core * | orb_core, | |
| int | def_type = AF_UNSPEC | |||
| ) | [protected] |
Probe the system for available network interfaces, and initialize the <addrs_> array with an ACE_INET_Addr for each network interface. The port for each initialized ACE_INET_Addr will be set in the open_i() method. This method only gets invoked when no explicit hostname is provided in the specified endpoint.
The optional argument def_type is used to constrain the resulting list of interfaces to be either only IPv6 or IPv4, or both, when ACE_HAS_IPV6 is enabled and the source endpoint was an explicitly declared wildcard.
Definition at line 695 of file DIOP_Acceptor.cpp.
{
// Extract the hostname for each network interface, and then cache
// it. The hostnames will then be used when creating a
// TAO_DIOP_Profile for each endpoint setup on the probed
// network interfaces.
ACE_INET_Addr *if_addrs = 0;
size_t if_cnt = 0;
if (ACE::get_ip_interfaces (if_cnt,
if_addrs) != 0
&& errno != ENOTSUP)
{
// In the case where errno == ENOTSUP, if_cnt and if_addrs will
// not be modified, and will each remain equal to zero. This
// causes the default interface to be used.
return -1;
}
if (if_cnt == 0 || if_addrs == 0)
{
if (TAO_debug_level > 0)
{
ACE_DEBUG ((LM_WARNING,
ACE_TEXT ("TAO (%P|%t) - Unable to probe network ")
ACE_TEXT ("interfaces. Using default.")));
}
if_cnt = 1; // Force the network interface count to be one.
delete [] if_addrs;
ACE_NEW_RETURN (if_addrs,
ACE_INET_Addr[if_cnt],
-1);
}
// Scan for the loopback interface since it shouldn't be included in
// the list of cached hostnames unless it is the only interface.
size_t lo_cnt = 0; // Loopback interface count
for (size_t j = 0; j < if_cnt; ++j)
if (if_addrs[j].is_loopback ())
lo_cnt++;
#if defined (ACE_HAS_IPV6)
size_t ipv4_cnt = 0;
size_t ipv4_lo_cnt = 0;
size_t ipv6_ll = 0;
bool ipv6_non_ll = false;
// Scan for IPv4 interfaces since these should not be included
// when IPv6-only is selected.
for (size_t j = 0; j < if_cnt; ++j)
if (if_addrs[j].get_type () != AF_INET6 ||
if_addrs[j].is_ipv4_mapped_ipv6 ())
{
++ipv4_cnt;
if (if_addrs[j].is_loopback ())
++ipv4_lo_cnt; // keep track of IPv4 loopback ifs
}
else if (!if_addrs[j].is_linklocal () &&
!if_addrs[j].is_loopback())
{
ipv6_non_ll = true; // we have at least 1 non-local IPv6 if
}
else if (!orb_core->orb_params ()->use_ipv6_link_local () &&
if_addrs[j].is_linklocal ())
{
++ipv6_ll; // count link local addrs to exclude them afterwards
}
#endif /* ACE_HAS_IPV6 */
// The instantiation for this template is in
// tao/DIOP_Connector.cpp.
ACE_Auto_Basic_Array_Ptr<ACE_INET_Addr> safe_if_addrs (if_addrs);
#if defined (ACE_HAS_IPV6)
bool ipv4_only = def_type == AF_INET;
bool ipv6_only = (def_type == AF_INET6) ||
orb_core->orb_params ()->connect_ipv6_only ();
#if defined (ACE_WIN32)
if (this->default_address_.get_type () == AF_INET)
ipv4_only = true;
else
ipv6_only = true;
#endif /* ACE_WIN32 */
// If the loopback interface is the only interface then include it
// in the list of interfaces to query for a hostname, otherwise
// exclude it from the list.
bool ignore_lo;
if (ipv6_only)
// only exclude loopback if non-local if exists
ignore_lo = ipv6_non_ll;
else if (ipv4_only)
ignore_lo = ipv4_cnt != ipv4_lo_cnt;
else
ignore_lo = if_cnt != lo_cnt;
// Adjust counts for IPv6 only if required
size_t if_ok_cnt = if_cnt;
if (ipv6_only)
{
if_ok_cnt -= ipv4_cnt;
lo_cnt -= ipv4_lo_cnt;
ipv4_lo_cnt = 0;
}
else if (ipv4_only)
{
if_ok_cnt = ipv4_cnt;
lo_cnt = ipv4_lo_cnt;
}
// In case there are no non-local IPv6 ifs in the list only exclude
// IPv4 loopback.
// IPv6 loopback will be needed to successfully connect IPv6 clients
// in a localhost environment.
if (!ipv4_only && !ipv6_non_ll)
lo_cnt = ipv4_lo_cnt;
if (!ignore_lo)
this->endpoint_count_ = static_cast<CORBA::ULong> (if_ok_cnt - ipv6_ll);
else
this->endpoint_count_ = static_cast<CORBA::ULong> (if_ok_cnt - ipv6_ll - lo_cnt);
#else /* ACE_HAS_IPV6 */
// If the loopback interface is the only interface then include it
// in the list of interfaces to query for a hostname, otherwise
// exclude it from the list.
bool ignore_lo;
ignore_lo = if_cnt != lo_cnt;
if (!ignore_lo)
this->endpoint_count_ = static_cast<CORBA::ULong> (if_cnt);
else
this->endpoint_count_ = static_cast<CORBA::ULong> (if_cnt - lo_cnt);
#endif /* !ACE_HAS_IPV6 */
if (this->endpoint_count_ == 0)
{
if (TAO_debug_level > 0)
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT("(%P|%t) - DIOP_Acceptor::probe_interfaces, ")
ACE_TEXT("found no usable addresses, def_type = %d\n"),
def_type));
return -1;
}
ACE_NEW_RETURN (this->addrs_,
ACE_INET_Addr[this->endpoint_count_],
-1);
ACE_NEW_RETURN (this->hosts_,
char *[this->endpoint_count_],
-1);
ACE_OS::memset (this->hosts_, 0, sizeof (char*) * this->endpoint_count_);
// The number of hosts/interfaces we want to cache may not be the
// same as the number of detected interfaces so keep a separate
// count.
size_t host_cnt = 0;
for (size_t i = 0; i < if_cnt; ++i)
{
#if defined (ACE_HAS_IPV6)
// Ignore any loopback interface if there are other
// non-loopback interfaces.
if (ignore_lo &&
if_addrs[i].is_loopback () &&
(ipv4_only ||
ipv6_non_ll ||
if_addrs[i].get_type () != AF_INET6))
continue;
// Ignore any non-IPv4 interfaces when so required.
if (ipv4_only &&
(if_addrs[i].get_type () != AF_INET))
continue;
// Ignore any non-IPv6 interfaces when so required.
if (ipv6_only &&
(if_addrs[i].get_type () != AF_INET6 ||
if_addrs[i].is_ipv4_mapped_ipv6 ()))
continue;
// Ignore all IPv6 link local interfaces when so required.
if (!orb_core->orb_params ()->use_ipv6_link_local () &&
if_addrs[i].is_linklocal ())
continue;
#else /* ACE_HAS_IPV6 */
// Ignore any loopback interface if there are other
// non-loopback interfaces.
if (ignore_lo &&
if_addrs[i].is_loopback ())
continue;
#endif /* !ACE_HAS_IPV6 */
if (this->hostname (orb_core,
if_addrs[i],
this->hosts_[host_cnt]) != 0)
return -1;
// Copy the addr. The port is (re)set in
// TAO_DIOP_Acceptor::open_i().
if (this->addrs_[host_cnt].set (if_addrs[i]) != 0)
return -1;
host_cnt++;
}
return 0;
}
| void TAO_DIOP_Acceptor::set_default_address | ( | const ACE_INET_Addr & | addr | ) |
Set address for default endpoint.
Definition at line 35 of file DIOP_Acceptor.inl.
{
this->default_address_.set (addr);
}
ACE_INET_Addr* TAO_DIOP_Acceptor::addrs_ [protected] |
Array of ACE_INET_Addr instances, each one corresponding to a given network interface.
Definition at line 172 of file DIOP_Acceptor.h.
Definition at line 202 of file DIOP_Acceptor.h.
ACE_INET_Addr TAO_DIOP_Acceptor::default_address_ [protected] |
Address for default endpoint.
Definition at line 198 of file DIOP_Acceptor.h.
CORBA::ULong TAO_DIOP_Acceptor::endpoint_count_ [protected] |
The number of host names cached in the hosts_ array (equivalent to the number of endpoints opened by this Acceptor).
Definition at line 185 of file DIOP_Acceptor.h.
char** TAO_DIOP_Acceptor::hosts_ [protected] |
Cache the information about the endpoints serviced by this acceptor. There may in fact be multiple hostnames for this endpoint. For example, if the IP address is INADDR_ANY (0.0.0.0) then there will be possibly a different hostname for each interface.
Definition at line 181 of file DIOP_Acceptor.h.
TAO_ORB_Core* TAO_DIOP_Acceptor::orb_core_ [protected] |
ORB Core.
Definition at line 195 of file DIOP_Acceptor.h.
TAO_GIOP_Message_Version TAO_DIOP_Acceptor::version_ [protected] |
The GIOP version for this endpoint @ Theoretically they shouldn't be here!! We need to look at a way to move this out
Definition at line 192 of file DIOP_Acceptor.h.
1.7.0
