ca.nrc.widar.mccc.crmGui
Class CrmGuiOutput

java.lang.Object
  ca.nrc.widar.mccc.crmGui.CrmGuiOutput

public class CrmGuiOutput
extends java.lang.Object

WIDAR/EVLA - Crm GUI: CrmGuiOutput Class

A static class, containing variables and methods useful and common to the output and display of data for all classes within the package

Copyright: National Research Council of Canada and Associated Universities Inc., 2010, 2011, 2012

Since:

1.0

Author:

Dave Del Rizzo (Dave.DelRizzo@nrc.gc.ca)

Field Summary

static java.lang.String	blbDefault
static java.text.DecimalFormat	blbFormat
static java.lang.String	CLASSNAME
static javax.xml.bind.JAXBContext	crmJaxbContext
static java.text.DecimalFormat	dpFormat
static int	N_DP
static int	N_F
static int	N_SB
static int	N_STAGES
static java.text.DecimalFormat	qFormat
static java.text.DecimalFormat	sbFormat
static java.lang.String	stbDefault
static java.text.DecimalFormat	stbFormat
static java.lang.String	wDefault
static java.text.DecimalFormat	wFormat
static java.lang.String	xbDefault
static java.text.DecimalFormat	xbLFormat
static java.text.DecimalFormat	xbUFormat

Constructor Summary

CrmGuiOutput()

Method Summary

static java.lang.String	composeCsdReport(ca.nrc.widar.jaxb.crm.CsdErrorReport cerXml) Takes information from the supplied CsdErrorReport JAXB object and forms a string to be returned to the caller with the relevant information.
static java.lang.String	formatBlbAddress(java.lang.Integer r, java.lang.Integer c, java.lang.Integer s) Based on provided component coordinates for a BlB within the EVLA correlator, constructs and returns a String describing the location of the component
static java.lang.String	formatBlbAddress(java.lang.Integer r, java.lang.Integer c, java.lang.Integer s, java.lang.Integer q, java.lang.Integer sb, java.lang.Integer w) Based on provided component coordinates for a BlB within the EVLA correlator, constructs and returns a String describing the location of the component, including quadrant, subband and wafer information
static java.lang.String	formatBlbAddressHtml(java.lang.Integer r, java.lang.Integer c, java.lang.Integer s) Based on provided component coordinates for a BlB within the EVLA correlator, constructs and returns a String describing the location of the component
static java.lang.String	formatBlbAddressHtml(java.lang.Integer r, java.lang.Integer c, java.lang.Integer s, java.lang.Integer q, java.lang.Integer sb, java.lang.Integer w) Based on provided component coordinates for a BlB within the EVLA correlator, constructs and returns a String describing the location of the component, including quadrant, subband and wafer ID, surrounded by HTML tags
static java.lang.String	formatBlbHstResultsToHtml(ca.nrc.widar.jaxb.crm.Diagnostic diagXml) A static method that returns a formatted HTML string with the results of the Hardware Self-Test (BLB)
static java.lang.String	formatBlbHstResultsToString(ca.nrc.widar.jaxb.crm.Diagnostic diagXml) A static method that returns a formatted string with the results of the Hardware Self-Test (BLB) intended for output to ASCII file
static java.lang.String	formatCsdTest(ca.nrc.widar.jaxb.crm.CsdModeType m, int id) Takes the supplied CSD mode and ID, and returns a formatted string indicating the CSD mode
static java.lang.String	formatCsdTestHtml(ca.nrc.widar.jaxb.crm.CsdModeType m, int id) Takes the supplied CSD mode and ID, and returns a formatted string indicating the CSD mode, surrounded by HTML tags
static java.lang.String	formatStbAddress(java.lang.Integer r, java.lang.Integer c, java.lang.Integer s) Based on provided component coordinates for a StB within the EVLA correlator, constructs and returns a String describing the location of the component
static java.lang.String	formatStbAddressHtml(java.lang.Integer r, java.lang.Integer c, java.lang.Integer s) Based on provided component coordinates for a StB within the EVLA correlator, constructs and returns a String describing the location of the component surrounded by HTML tags
static java.lang.String	formatStbHstResultsToHtml(ca.nrc.widar.jaxb.crm.Diagnostic diagXml) Returns a String containing the results of an StbHST diagnostic that is formatted in HTML and intended to display to the end user.
static java.lang.String	formatStbHstResultsToString(ca.nrc.widar.jaxb.crm.Diagnostic diagXml) Returns a String containing the results of an StbHST diagnostic that is formatted for VT100 display and intended to display to the end user.
static void	main(java.lang.String[] args)

Methods inherited from class java.lang.Object

clone, equals, finalize, getClass, hashCode, notify, notifyAll, toString, wait, wait, wait

Field Detail

CLASSNAME

public static final java.lang.String CLASSNAME

See Also:

Constant Field Values

N_DP

public static final int N_DP

See Also:

Constant Field Values

N_F

public static final int N_F

See Also:

Constant Field Values

N_STAGES

public static final int N_STAGES

See Also:

Constant Field Values

N_SB

public static final int N_SB

See Also:

Constant Field Values

crmJaxbContext

public static javax.xml.bind.JAXBContext crmJaxbContext

stbDefault

public static final java.lang.String stbDefault

See Also:

Constant Field Values

blbDefault

public static final java.lang.String blbDefault

See Also:

Constant Field Values

xbDefault

public static final java.lang.String xbDefault

See Also:

Constant Field Values

wDefault

public static final java.lang.String wDefault

See Also:

Constant Field Values

xbUFormat

public static java.text.DecimalFormat xbUFormat

xbLFormat

public static java.text.DecimalFormat xbLFormat

sbFormat

public static java.text.DecimalFormat sbFormat

wFormat

public static java.text.DecimalFormat wFormat

qFormat

public static java.text.DecimalFormat qFormat

dpFormat

public static java.text.DecimalFormat dpFormat

stbFormat

public static java.text.DecimalFormat stbFormat

blbFormat

public static java.text.DecimalFormat blbFormat

Constructor Detail

CrmGuiOutput

public CrmGuiOutput()

Method Detail

formatStbAddress

public static java.lang.String formatStbAddress(java.lang.Integer r,
                                                java.lang.Integer c,
                                                java.lang.Integer s)

Based on provided component coordinates for a StB within the EVLA correlator, constructs and returns a String describing the location of the component

Parameters:

r - The integer rack ID (0-8)

c - The integer crate ID (0-1)

s - The integer slot ID (0-8)

Returns:

A String in the standard EVLA format describing component location

formatStbAddressHtml

public static java.lang.String formatStbAddressHtml(java.lang.Integer r,
                                                    java.lang.Integer c,
                                                    java.lang.Integer s)

Based on provided component coordinates for a StB within the EVLA correlator, constructs and returns a String describing the location of the component surrounded by HTML tags

Parameters:

r - The integer rack ID (0-8)

c - The integer crate ID (0-1)

s - The integer slot ID (0-8)

Returns:

A String in the standard EVLA format describing component location containing HTML tags

formatBlbAddress

public static java.lang.String formatBlbAddress(java.lang.Integer r,
                                                java.lang.Integer c,
                                                java.lang.Integer s)

Based on provided component coordinates for a BlB within the EVLA correlator, constructs and returns a String describing the location of the component

Parameters:

r - The integer rack ID (101-108)

c - The integer crate ID (0-1)

s - The integer slot ID (0-8)

Returns:

A String in the standard EVLA format describing component location

formatBlbAddress

public static java.lang.String formatBlbAddress(java.lang.Integer r,
                                                java.lang.Integer c,
                                                java.lang.Integer s,
                                                java.lang.Integer q,
                                                java.lang.Integer sb,
                                                java.lang.Integer w)

Based on provided component coordinates for a BlB within the EVLA correlator, constructs and returns a String describing the location of the component, including quadrant, subband and wafer information

Parameters:

r - The integer rack ID (101-108)

c - The integer crate ID (0-1)

s - The integer slot ID (0-8)

q - The quadrant ID (0-3)

sb - The subband ID (0-15)

w - The wafer ID (0-31)

Returns:

A String in the standard EVLA format describing component location

formatBlbAddressHtml

public static java.lang.String formatBlbAddressHtml(java.lang.Integer r,
                                                    java.lang.Integer c,
                                                    java.lang.Integer s,
                                                    java.lang.Integer q,
                                                    java.lang.Integer sb,
                                                    java.lang.Integer w)

Based on provided component coordinates for a BlB within the EVLA correlator, constructs and returns a String describing the location of the component, including quadrant, subband and wafer ID, surrounded by HTML tags

Parameters:

r - The integer rack ID (101-108)

c - The integer crate ID (0-1)

s - The integer slot ID (0-8)

q - The quadrant ID (0-3)

sb - The subband ID (0-15)

w - The wafer ID (0-31)

Returns:

A String in the standard EVLA format describing component location containing HTML tags

formatBlbAddressHtml

public static java.lang.String formatBlbAddressHtml(java.lang.Integer r,
                                                    java.lang.Integer c,
                                                    java.lang.Integer s)

Based on provided component coordinates for a BlB within the EVLA correlator, constructs and returns a String describing the location of the component

Parameters:

r - The integer rack ID (101-108)

c - The integer crate ID (0-1)

s - The integer slot ID (0-8)

Returns:

A String in the standard EVLA format describing component location containing HTML tags

composeCsdReport

public static java.lang.String composeCsdReport(ca.nrc.widar.jaxb.crm.CsdErrorReport cerXml)

Takes information from the supplied CsdErrorReport JAXB object and forms a string to be returned to the caller with the relevant information.

Parameters:

cerXml - A CsdErrorReport JAXB object

Returns:

A String statement based on the supplied CsdErrorReport

formatCsdTest

public static java.lang.String formatCsdTest(ca.nrc.widar.jaxb.crm.CsdModeType m,
                                             int id)

Takes the supplied CSD mode and ID, and returns a formatted string indicating the CSD mode

Parameters:

m - The CsdModeType for this CSD mode

id - The CSD Mode ID for this CSD mode

Returns:

A String describing the CSD mode for display

formatCsdTestHtml

public static java.lang.String formatCsdTestHtml(ca.nrc.widar.jaxb.crm.CsdModeType m,
                                                 int id)

Takes the supplied CSD mode and ID, and returns a formatted string indicating the CSD mode, surrounded by HTML tags

Parameters:

m - The CsdModeType for this CSD mode

id - The CSD Mode ID for this CSD mode

Returns:

A String describing the CSD mode for display including HTML tags

formatBlbHstResultsToHtml

public static java.lang.String formatBlbHstResultsToHtml(ca.nrc.widar.jaxb.crm.Diagnostic diagXml)

A static method that returns a formatted HTML string with the results of the Hardware Self-Test (BLB)

Parameters:

diagXml - A diagnostic XML element presumeably containing a Result element

Returns:

An HTML formatted string with the contents of the Result element

formatBlbHstResultsToString

public static java.lang.String formatBlbHstResultsToString(ca.nrc.widar.jaxb.crm.Diagnostic diagXml)

A static method that returns a formatted string with the results of the Hardware Self-Test (BLB) intended for output to ASCII file

Parameters:

diagXml - A diagnostic XML element presumeably containing a Result element

Returns:

A formatted string with the contents of the Result element

formatStbHstResultsToHtml

public static java.lang.String formatStbHstResultsToHtml(ca.nrc.widar.jaxb.crm.Diagnostic diagXml)

Returns a String containing the results of an StbHST diagnostic that is formatted in HTML and intended to display to the end user.

Parameters:

diagXml - The Diagnostic containing the results of an Stb HST

Returns:

An HTML formatted string

formatStbHstResultsToString

public static java.lang.String formatStbHstResultsToString(ca.nrc.widar.jaxb.crm.Diagnostic diagXml)

Returns a String containing the results of an StbHST diagnostic that is formatted for VT100 display and intended to display to the end user.

Parameters:

diagXml - The Diagnostic containing the results of an Stb HST

Returns:

An formatted string

main

public static void main(java.lang.String[] args)
                 throws java.io.IOException

Throws:

java.io.IOException
