RTCORBA ORB initializer. More...
#include <RT_ORBInitializer.h>
Public Types | |
| enum | { TAO_PRIORITY_MAPPING_CONTINUOUS, TAO_PRIORITY_MAPPING_LINEAR, TAO_PRIORITY_MAPPING_DIRECT } |
Priority mapping types. More... | |
| enum | { TAO_NETWORK_PRIORITY_MAPPING_LINEAR } |
| enum | TAO_RTCORBA_DT_LifeSpan { TAO_RTCORBA_DT_INFINITIVE, TAO_RTCORBA_DT_IDLE, TAO_RTCORBA_DT_FIXED } |
Public Member Functions | |
| TAO_RT_ORBInitializer (int priority_mapping_type, int network_priority_mapping_type, int ace_sched_policy, long sched_policy, long scope_policy, TAO_RT_ORBInitializer::TAO_RTCORBA_DT_LifeSpan lifespan, ACE_Time_Value const &dynamic_thread_time) | |
| virtual void | pre_init (PortableInterceptor::ORBInitInfo_ptr info) |
| virtual void | post_init (PortableInterceptor::ORBInitInfo_ptr info) |
Private Member Functions | |
| void | register_policy_factories (PortableInterceptor::ORBInitInfo_ptr info) |
| Register RTCORBA policy factories. | |
Private Attributes | |
| PortableInterceptor::PolicyFactory_var | policy_factory_ |
| Instance of the RTCorba policy factory. | |
| int const | priority_mapping_type_ |
| Priority mapping type. | |
| int const | network_priority_mapping_type_ |
| Network Priority mapping type. | |
| int const | ace_sched_policy_ |
| Scheduling policy. | |
| long const | sched_policy_ |
| Scheduling policy flag. | |
| long const | scope_policy_ |
| Scheduling scope flag. | |
| TAO_RT_ORBInitializer::TAO_RTCORBA_DT_LifeSpan | lifespan_ |
| Dynamic thread lifespan policy. | |
| ACE_Time_Value const | dynamic_thread_time_ |
| Dynamic thread time. | |
Definition at line 42 of file RT_ORBInitializer.h.
| anonymous enum |
Priority mapping types.
Definition at line 48 of file RT_ORBInitializer.h.
{
TAO_PRIORITY_MAPPING_CONTINUOUS,
TAO_PRIORITY_MAPPING_LINEAR,
TAO_PRIORITY_MAPPING_DIRECT
};
| anonymous enum |
Definition at line 55 of file RT_ORBInitializer.h.
Definition at line 69 of file RT_ORBInitializer.h.
{
TAO_RTCORBA_DT_INFINITIVE,
TAO_RTCORBA_DT_IDLE,
TAO_RTCORBA_DT_FIXED
};
| TAO_RT_ORBInitializer::TAO_RT_ORBInitializer | ( | int | priority_mapping_type, | |
| int | network_priority_mapping_type, | |||
| int | ace_sched_policy, | |||
| long | sched_policy, | |||
| long | scope_policy, | |||
| TAO_RT_ORBInitializer::TAO_RTCORBA_DT_LifeSpan | lifespan, | |||
| ACE_Time_Value const & | dynamic_thread_time | |||
| ) |
Definition at line 50 of file RT_ORBInitializer.cpp.
: priority_mapping_type_ (priority_mapping_type), network_priority_mapping_type_ (network_priority_mapping_type), ace_sched_policy_ (ace_sched_policy), sched_policy_ (sched_policy), scope_policy_ (scope_policy), lifespan_ (lifespan), dynamic_thread_time_ (dynamic_thread_time) { }
| void TAO_RT_ORBInitializer::post_init | ( | PortableInterceptor::ORBInitInfo_ptr | info | ) | [virtual] |
Definition at line 217 of file RT_ORBInitializer.cpp.
{
this->register_policy_factories (info);
}
| void TAO_RT_ORBInitializer::pre_init | ( | PortableInterceptor::ORBInitInfo_ptr | info | ) | [virtual] |
Definition at line 68 of file RT_ORBInitializer.cpp.
{
//
// Register all of the RT related services.
//
// Narrow to a TAO_ORBInitInfo object to get access to the
// orb_core() TAO extension.
TAO_ORBInitInfo_var tao_info = TAO_ORBInitInfo::_narrow (info);
if (CORBA::is_nil (tao_info.in ()))
{
if (TAO_debug_level > 0)
ACE_ERROR ((LM_ERROR,
"(%P|%t) TAO_RT_ORBInitializer::pre_init:\n"
"(%P|%t) Unable to narrow "
"\"PortableInterceptor::ORBInitInfo_ptr\" to\n"
"(%P|%t) \"TAO_ORBInitInfo *.\"\n"));
throw ::CORBA::INTERNAL ();
}
// Bind the service context handler for RTCORBA
TAO_RT_Service_Context_Handler* h = 0;
ACE_NEW (h,
TAO_RT_Service_Context_Handler());
tao_info->orb_core ()->service_context_registry ().bind (IOP::RTCorbaPriority, h);
// Set the name of the Protocol_Hooks to be RT_Protocols_Hooks.
tao_info->orb_core ()->orb_params ()->protocols_hooks_name ("RT_Protocols_Hooks");
ACE_Service_Config::process_directive (ace_svc_desc_TAO_RT_Protocols_Hooks);
// Set the name of the stub factory to be RT_Stub_Factory.
tao_info->orb_core ()->orb_params ()->stub_factory_name ("RT_Stub_Factory");
ACE_Service_Config::process_directive (ace_svc_desc_TAO_RT_Stub_Factory);
// Set the name of the endpoint selector factory to be RT_Endpoint_Selector_Factory.
tao_info->orb_core ()->orb_params ()->endpoint_selector_factory_name ("RT_Endpoint_Selector_Factory");
ACE_Service_Config::process_directive (ace_svc_desc_RT_Endpoint_Selector_Factory);
// Set the name of the thread lane resources manager to be RT_Thread_Lane_Resources_Manager.
tao_info->orb_core ()->orb_params ()->thread_lane_resources_manager_factory_name ("RT_Thread_Lane_Resources_Manager_Factory");
ACE_Service_Config::process_directive (ace_svc_desc_TAO_RT_Thread_Lane_Resources_Manager_Factory);
// If the application resolves the root POA, make sure we load the RT POA.
tao_info->orb_core ()->orb_params ()->poa_factory_name (rt_poa_factory_name);
tao_info->orb_core ()->orb_params ()->poa_factory_directive (rt_poa_factory_directive);
// Create the initial priority mapping instance.
TAO_Priority_Mapping *pm = 0;
switch (this->priority_mapping_type_)
{
case TAO_PRIORITY_MAPPING_CONTINUOUS:
ACE_NEW (pm,
TAO_Continuous_Priority_Mapping (this->ace_sched_policy_));
break;
case TAO_PRIORITY_MAPPING_LINEAR:
ACE_NEW (pm,
TAO_Linear_Priority_Mapping (this->ace_sched_policy_));
break;
default:
case TAO_PRIORITY_MAPPING_DIRECT:
ACE_NEW (pm,
TAO_Direct_Priority_Mapping (this->ace_sched_policy_));
break;
}
// Set the Priority_Mapping_Manager
TAO_Priority_Mapping_Manager *manager = 0;
ACE_NEW_THROW_EX (manager,
TAO_Priority_Mapping_Manager (pm),
CORBA::NO_MEMORY (
CORBA::SystemException::_tao_minor_code (
TAO::VMCID,
ENOMEM),
CORBA::COMPLETED_NO));
TAO_Priority_Mapping_Manager_var safe_manager = manager;
info->register_initial_reference ("PriorityMappingManager", manager);
// Create the initial priority mapping instance.
TAO_Network_Priority_Mapping *npm = 0;
switch (this->network_priority_mapping_type_)
{
default:
case TAO_NETWORK_PRIORITY_MAPPING_LINEAR:
ACE_NEW (npm,
TAO_Linear_Network_Priority_Mapping (this->ace_sched_policy_));
break;
}
// Set the Priority_Mapping_Manager
TAO_Network_Priority_Mapping_Manager * network_manager = 0;
// @@ There is a potential memory leak here. If the new() below
// throws an exception, the memory for the network priority
// mapping allocated above will be leaked. Use an auto_ptr<> or
// the appropriate memory management tool.
ACE_NEW_THROW_EX (network_manager,
TAO_Network_Priority_Mapping_Manager (npm),
CORBA::NO_MEMORY (
CORBA::SystemException::_tao_minor_code (
TAO::VMCID,
ENOMEM),
CORBA::COMPLETED_NO));
TAO_Network_Priority_Mapping_Manager_var safe_network_manager =
network_manager;
info->register_initial_reference ("NetworkPriorityMappingManager",
network_manager);
// Create the RT_ORB.
CORBA::Object_ptr rt_orb = CORBA::Object::_nil ();
ACE_NEW_THROW_EX (rt_orb,
TAO_RT_ORB (tao_info->orb_core (),
lifespan_,
dynamic_thread_time_),
CORBA::NO_MEMORY (
CORBA::SystemException::_tao_minor_code (
TAO::VMCID,
ENOMEM),
CORBA::COMPLETED_NO));
CORBA::Object_var safe_rt_orb = rt_orb;
info->register_initial_reference (TAO_OBJID_RTORB, rt_orb);
// Create the RT_Current.
CORBA::Object_ptr current = CORBA::Object::_nil ();
ACE_NEW_THROW_EX (current,
TAO_RT_Current (tao_info->orb_core ()),
CORBA::NO_MEMORY (
CORBA::SystemException::_tao_minor_code (
TAO::VMCID,
ENOMEM),
CORBA::COMPLETED_NO));
CORBA::Object_var safe_rt_current = current;
info->register_initial_reference (TAO_OBJID_RTCURRENT, current);
tao_info->orb_core ()->orb_params ()->scope_policy (this->scope_policy_);
tao_info->orb_core ()->orb_params ()->sched_policy (this->sched_policy_);
tao_info->orb_core ()->orb_params ()->ace_sched_policy (this->ace_sched_policy_);
}
| void TAO_RT_ORBInitializer::register_policy_factories | ( | PortableInterceptor::ORBInitInfo_ptr | info | ) | [private] |
Register RTCORBA policy factories.
Definition at line 223 of file RT_ORBInitializer.cpp.
{
// The RTCorba policy factory is stateless and reentrant, so share a
// single instance between all ORBs.
if (CORBA::is_nil (this->policy_factory_.in ()))
{
PortableInterceptor::PolicyFactory_ptr policy_factory;
ACE_NEW_THROW_EX (policy_factory,
TAO_RT_PolicyFactory,
CORBA::NO_MEMORY (
CORBA::SystemException::_tao_minor_code (
TAO::VMCID,
ENOMEM),
CORBA::COMPLETED_NO));
this->policy_factory_ = policy_factory;
}
// Bind the same policy factory to all RTCORBA related policy
// types since a single policy factory is used to create each of
// the different types of RTCORBA policies.
static CORBA::PolicyType const type[] = {
RTCORBA::PRIORITY_MODEL_POLICY_TYPE,
RTCORBA::THREADPOOL_POLICY_TYPE,
RTCORBA::SERVER_PROTOCOL_POLICY_TYPE,
RTCORBA::CLIENT_PROTOCOL_POLICY_TYPE,
RTCORBA::PRIVATE_CONNECTION_POLICY_TYPE,
RTCORBA::PRIORITY_BANDED_CONNECTION_POLICY_TYPE
};
const CORBA::PolicyType *end =
type + sizeof (type) / sizeof (type[0]);
for (CORBA::PolicyType const * i = type;
i != end;
++i)
{
try
{
info->register_policy_factory (*i, this->policy_factory_.in ());
}
catch (const ::CORBA::BAD_INV_ORDER& ex)
{
if (ex.minor () == (CORBA::OMGVMCID | 16))
{
// The factory is already there, it happens because the
// magic initializer in PortableServer.cpp registers
// with the ORB multiple times. This is an indication
// that we should do no more work in this
// ORBInitializer.
return;
}
throw;
}
}
}
int const TAO_RT_ORBInitializer::ace_sched_policy_ [private] |
Scheduling policy.
Scheduling policy specified by the user through the -ORBSchedPolicy option. This value is typically used by functions like ACE_OS::thr_setprio() and ACE_Sched_Params::priority_min(). Legal values are ACE_SCHED_RR, ACE_SCHED_FIFO, and ACE_SCHED_OTHER.
Definition at line 115 of file RT_ORBInitializer.h.
ACE_Time_Value const TAO_RT_ORBInitializer::dynamic_thread_time_ [private] |
Dynamic thread time.
When using thread pool a certain number of dynamic threads can be created. By default these threads are created when needed but never end. Optionally a time can be specified
Definition at line 144 of file RT_ORBInitializer.h.
Dynamic thread lifespan policy.
Definition at line 136 of file RT_ORBInitializer.h.
int const TAO_RT_ORBInitializer::network_priority_mapping_type_ [private] |
Network Priority mapping type.
Definition at line 105 of file RT_ORBInitializer.h.
Instance of the RTCorba policy factory.
The RTCorba policy factory is stateless and reentrant, so share a single instance between all ORBs.
Definition at line 99 of file RT_ORBInitializer.h.
int const TAO_RT_ORBInitializer::priority_mapping_type_ [private] |
Priority mapping type.
Definition at line 102 of file RT_ORBInitializer.h.
long const TAO_RT_ORBInitializer::sched_policy_ [private] |
Scheduling policy flag.
Scheduling policy specified by the user through the -ORBSchedPolicy option. This value is typically used by ACE thread creation functions. Legal values are THR_SCHED_RR, THR_SCHED_FIFO, and THR_SCHED_DEFAULT.
Definition at line 124 of file RT_ORBInitializer.h.
long const TAO_RT_ORBInitializer::scope_policy_ [private] |
Scheduling scope flag.
Scheduling policy specified by the user through the -ORBScopePolicy option. This value is typically used by ACE thread creation functions. Legal values are THR_SCOPE_SYSTEM and THR_SCOPE_PROCESS.
Definition at line 133 of file RT_ORBInitializer.h.
