TAO_CosEvent: TAO_CEC_MT_Dispatching Class Reference

This strategy uses a single queue, serviced by one or more threads. It's main purpose is to decouple the suppliers from the client execution time, specially in the collocated case.

Constructor & Destructor Documentation

TAO_BEGIN_VERSIONED_NAMESPACE_DECL TAO_CEC_MT_Dispatching::TAO_CEC_MT_Dispatching	(	int	nthreads,
		int	thread_creation_flags,
		int	thread_priority,
		int	force_activate
	)

Constructor It will create <nthreads> servicing threads...

Definition at line 12 of file CEC_MT_Dispatching.cpp.

00016   :  nthreads_ (nthreads),
00017      thread_creation_flags_ (thread_creation_flags),
00018      thread_priority_ (thread_priority),
00019      force_activate_ (force_activate),
00020      task_ (&this->thread_manager_),
00021      active_ (0)
00022 {
00023 }

Member Function Documentation

void TAO_CEC_MT_Dispatching::activate ( void ) [virtual]

Initialize all the data structures, activate any internal threads, etc.

Implements TAO_CEC_Dispatching.

Definition at line 26 of file CEC_MT_Dispatching.cpp.

References ACE_ERROR, ACE_GUARD, active_, LM_ERROR, TAO_SYNCH_MUTEX, and THR_BOUND.

Referenced by push_nocopy().

00027 {
00028   ACE_GUARD (TAO_SYNCH_MUTEX, ace_mon, this->lock_);
00029
00030   if (this->active_ != 0)
00031     return;
00032
00033   this->active_ = 1;
00034
00035   if (this->task_.activate (this->thread_creation_flags_,
00036                             this->nthreads_,
00037                             1,
00038                             this->thread_priority_) == -1)
00039     {
00040       if (this->force_activate_ != 0)
00041         {
00042           if (this->task_.activate (THR_BOUND, this->nthreads_) == -1)
00043             ACE_ERROR ((LM_ERROR,
00044                         "EC (%P|%t) cannot activate dispatching queue"));
00045         }
00046     }
00047 }

void TAO_CEC_MT_Dispatching::push	(	TAO_CEC_ProxyPushSupplier *	proxy,
		const CORBA::Any &	event
	)			`[virtual]`

The consumer represented by <proxy> should receive <event>.

Implements TAO_CEC_Dispatching.

Definition at line 65 of file CEC_MT_Dispatching.cpp.

References push_nocopy().

00067 {
00068   CORBA::Any event_copy = event;
00069   this->push_nocopy (proxy, event_copy);
00070 }

void TAO_CEC_MT_Dispatching::push_nocopy	(	TAO_CEC_ProxyPushSupplier *	proxy,
		CORBA::Any &	event
	)			`[virtual]`

Implements TAO_CEC_Dispatching.

Definition at line 73 of file CEC_MT_Dispatching.cpp.

References activate(), TAO_CEC_Dispatching_Task::push(), and task_.

Referenced by push().

00075 {
00076   // Double checked locking....
00077   if (this->active_ == 0)
00078     this->activate ();
00079
00080   this->task_.push (proxy, event);
00081 }

void TAO_CEC_MT_Dispatching::shutdown ( void ) [virtual]

Deactivate any internal threads and cleanup internal data structures, it should only return once the threads have finished their jobs.

Implements TAO_CEC_Dispatching.

Definition at line 50 of file CEC_MT_Dispatching.cpp.

References ACE_GUARD, nthreads_, TAO_SYNCH_MUTEX, thread_manager_, and ACE_Thread_Manager::wait().

00051 {
00052   ACE_GUARD (TAO_SYNCH_MUTEX, ace_mon, this->lock_);
00053
00054   if (this->active_ == 0)
00055     return;
00056
00057   for (int i = 0; i < this->nthreads_; ++i)
00058     {
00059       this->task_.putq (new TAO_CEC_Shutdown_Task_Command);
00060     }
00061   this->thread_manager_.wait ();
00062 }

Member Data Documentation

int TAO_CEC_MT_Dispatching::active_ [private]

Are the threads running?

Definition at line 89 of file CEC_MT_Dispatching.h.

Referenced by activate().

int TAO_CEC_MT_Dispatching::force_activate_ [private]

If activation at the requested priority fails then we fallback on the defaults for thread activation.

Definition at line 80 of file CEC_MT_Dispatching.h.

TAO_SYNCH_MUTEX TAO_CEC_MT_Dispatching::lock_ [private]

Synchronize access to internal data.

Definition at line 86 of file CEC_MT_Dispatching.h.

int TAO_CEC_MT_Dispatching::nthreads_ [private]

The number of active tasks.

Definition at line 69 of file CEC_MT_Dispatching.h.

Referenced by shutdown().

TAO_CEC_Dispatching_Task TAO_CEC_MT_Dispatching::task_ [private]

The dispatching task.

Definition at line 83 of file CEC_MT_Dispatching.h.

Referenced by push_nocopy().

int TAO_CEC_MT_Dispatching::thread_creation_flags_ [private]

The flags (THR_BOUND, THR_NEW_LWP, etc.) used to create the dispatching threads.

Definition at line 73 of file CEC_MT_Dispatching.h.

ACE_Thread_Manager TAO_CEC_MT_Dispatching::thread_manager_ [private]

Use our own thread manager.

Definition at line 66 of file CEC_MT_Dispatching.h.

Referenced by shutdown().

int TAO_CEC_MT_Dispatching::thread_priority_ [private]

The priority of the dispatching threads.

Definition at line 76 of file CEC_MT_Dispatching.h.

TAO_CEC_MT_Dispatching Class Reference

Public Member Functions

Private Attributes

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation


Public Member Functions
	TAO_CEC_MT_Dispatching (int nthreads, int thread_creation_flags, int thread_priority, int force_activate)
virtual void	activate (void)
virtual void	shutdown (void)
virtual void	push (TAO_CEC_ProxyPushSupplier *proxy, const CORBA::Any &event)
	The consumer represented by <proxy> should receive <event>.
virtual void	push_nocopy (TAO_CEC_ProxyPushSupplier *proxy, CORBA::Any &event)
Private Attributes
ACE_Thread_Manager	thread_manager_
	Use our own thread manager.
int	nthreads_
	The number of active tasks.
int	thread_creation_flags_
int	thread_priority_
	The priority of the dispatching threads.
int	force_activate_
TAO_CEC_Dispatching_Task	task_
	The dispatching task.
TAO_SYNCH_MUTEX	lock_
	Synchronize access to internal data.
int	active_
	Are the threads running?
