edu.nrao.widar.gui.widget
Class LogPane

java.lang.Object
  java.awt.Component
      java.awt.Container
          javax.swing.JComponent
              javax.swing.JPanel
                  edu.nrao.widar.gui.widget.BlankPanel
                      edu.nrao.widar.gui.widget.LogPane

All Implemented Interfaces:

java.awt.event.ActionListener, java.awt.event.WindowListener, java.awt.image.ImageObserver, java.awt.MenuContainer, java.io.Serializable, java.util.EventListener, javax.accessibility.Accessible

public class LogPane
extends BlankPanel
implements java.awt.event.ActionListener, java.awt.event.WindowListener

LogPane.
LogPane is a small JTextArea in a JScrollPane that can be added to a GUI to facilitate reading and writing a server resident log. It's intended use is to facilitate communication between GUI users in the case where more than one user is connected to the same device.

Every device in the WIDAR correlator that is served by the REST-based interface system contains an online log that is memory resident (it gets reset when the server is restarted). This includes each of the Station and Baseline Boards CMIBs as well as the CPCC and MCCC and likely the CBE computers. Each log is for a single device.
LogPane automatically makes a server log entry when a GUI connects to it or disconnects from it so that it is not dependent on a human having to remember to do so. A user may also enter additional information into the log that others will see when they connect.
Finally, the pane preovides a drop down choice field to allow a user to set a lock state on the device. This is not a working lock but meant to let others know, at a glance, what the useable state of the board is without having to search through log text.
Programmers note 1:
LogPane knows when its parent window is opened and closed by listening to WindowEvents. The events are dispatched by the 'system' for all cases except when a program explicitly calls System.exit(). This is normally the case when the default close operation is set to EXIT_ON_CLOSE and the user selected 'Quit' from a menu. (Clicking the 'X' (or red button for OS-X) on the window frame causes proper event dispatching). So, in order for proper operation of LogPane when quitting the GUI application using the System.exit() method, the program must first explicitly dispatch a WINDOW_CLOSING event using the following method:

   dispatchEvent(new WindowEvent(this, WindowEvent.WINDOW_CLOSING));

before calling System.exit().
Programmers note 2:
It's a good idea to refresh LogPane whenever the GUI iteslf is refreshed. This can be done in one of two ways:

1) Add LogPane to the GUI's RefreshPanel (or ServerPanel) ActionListener list so that it will automatically be notified with an ActionEvent:

refreshPanel.addActionListener(logPane);

2) Explicitly call LogPane's public refresh method everytime the GUI itself is refreshed.

Since:

1.5

Author:

KJRyan

See Also:

Serialized Form

Created:

2008.08.29

Nested Class Summary

Nested classes/interfaces inherited from class javax.swing.JPanel

javax.swing.JPanel.AccessibleJPanel

Nested classes/interfaces inherited from class javax.swing.JComponent

javax.swing.JComponent.AccessibleJComponent

Nested classes/interfaces inherited from class java.awt.Container

java.awt.Container.AccessibleAWTContainer

Nested classes/interfaces inherited from class java.awt.Component

java.awt.Component.AccessibleAWTComponent, java.awt.Component.BaselineResizeBehavior, java.awt.Component.BltBufferStrategy, java.awt.Component.FlipBufferStrategy

Field Summary

static java.awt.Color	LOCK_DONT_USE
static java.awt.Color	LOCK_IN_USE
static java.awt.Color	LOCK_OKAY_TO_USE
java.lang.Runnable	scrollDown

Fields inherited from class edu.nrao.widar.gui.widget.BlankPanel

bigLabelFont, defaultFont, fieldFont, LABEL_POS_BOTTOM, LABEL_POS_LEFT, LABEL_POS_RIGHT, LABEL_POS_TOP

Fields inherited from class javax.swing.JComponent

accessibleContext, listenerList, TOOL_TIP_TEXT_KEY, ui, UNDEFINED_CONDITION, WHEN_ANCESTOR_OF_FOCUSED_COMPONENT, WHEN_FOCUSED, WHEN_IN_FOCUSED_WINDOW

Fields inherited from class java.awt.Component

BOTTOM_ALIGNMENT, CENTER_ALIGNMENT, LEFT_ALIGNMENT, RIGHT_ALIGNMENT, TOP_ALIGNMENT

Fields inherited from interface java.awt.image.ImageObserver

ABORT, ALLBITS, ERROR, FRAMEBITS, HEIGHT, PROPERTIES, SOMEBITS, WIDTH

Constructor Summary

LogPane(int w, int h, javax.swing.JTextField ipField)
Create a LogPane of a specified size with a specified JTextField supplying the IP address of the server.

LogPane(int w, int h, java.lang.String ipString)
Create a LogPane of a specified size with a specified String supplying the IP address of the server.

Method Summary

void	actionPerformed(java.awt.event.ActionEvent e)
void	addMessage(java.lang.String message)
void	addNotify()
void	paintComponent(java.awt.Graphics g)
void	refresh() Refresh.
void	removeNotify()
void	windowActivated(java.awt.event.WindowEvent e)
void	windowClosed(java.awt.event.WindowEvent e)
void	windowClosing(java.awt.event.WindowEvent e)
void	windowDeactivated(java.awt.event.WindowEvent e)
void	windowDeiconified(java.awt.event.WindowEvent e)
void	windowIconified(java.awt.event.WindowEvent e)
void	windowOpened(java.awt.event.WindowEvent e)

Methods inherited from class edu.nrao.widar.gui.widget.BlankPanel

add, add, add, add, add, add, add, add, add, add, add, add, add, add, addButton, addComponent, addComponent, addComponent, addComponent, addComponent, addComponent, addLabel, addPanel, drawGrid, drawGrid, fixMarginsAndGetDimension, getComponent, getField, getFieldText, getValue, setAndAlarm, setField

Methods inherited from class javax.swing.JPanel

getAccessibleContext, getUI, getUIClassID, paramString, setUI, updateUI

Methods inherited from class javax.swing.JComponent

addAncestorListener, addVetoableChangeListener, computeVisibleRect, contains, createToolTip, disable, enable, firePropertyChange, firePropertyChange, firePropertyChange, fireVetoableChange, getActionForKeyStroke, getActionMap, getAlignmentX, getAlignmentY, getAncestorListeners, getAutoscrolls, getBaseline, getBaselineResizeBehavior, getBorder, getBounds, getClientProperty, getComponentGraphics, getComponentPopupMenu, getConditionForKeyStroke, getDebugGraphicsOptions, getDefaultLocale, getFontMetrics, getGraphics, getHeight, getInheritsPopupMenu, getInputMap, getInputMap, getInputVerifier, getInsets, getInsets, getListeners, getLocation, getMaximumSize, getMinimumSize, getNextFocusableComponent, getPopupLocation, getPreferredSize, getRegisteredKeyStrokes, getRootPane, getSize, getToolTipLocation, getToolTipText, getToolTipText, getTopLevelAncestor, getTransferHandler, getVerifyInputWhenFocusTarget, getVetoableChangeListeners, getVisibleRect, getWidth, getX, getY, grabFocus, isDoubleBuffered, isLightweightComponent, isManagingFocus, isOpaque, isOptimizedDrawingEnabled, isPaintingForPrint, isPaintingTile, isRequestFocusEnabled, isValidateRoot, paint, paintBorder, paintChildren, paintImmediately, paintImmediately, print, printAll, printBorder, printChildren, printComponent, processComponentKeyEvent, processKeyBinding, processKeyEvent, processMouseEvent, processMouseMotionEvent, putClientProperty, registerKeyboardAction, registerKeyboardAction, removeAncestorListener, removeVetoableChangeListener, repaint, repaint, requestDefaultFocus, requestFocus, requestFocus, requestFocusInWindow, requestFocusInWindow, resetKeyboardActions, reshape, revalidate, scrollRectToVisible, setActionMap, setAlignmentX, setAlignmentY, setAutoscrolls, setBackground, setBorder, setComponentPopupMenu, setDebugGraphicsOptions, setDefaultLocale, setDoubleBuffered, setEnabled, setFocusTraversalKeys, setFont, setForeground, setInheritsPopupMenu, setInputMap, setInputVerifier, setMaximumSize, setMinimumSize, setNextFocusableComponent, setOpaque, setPreferredSize, setRequestFocusEnabled, setToolTipText, setTransferHandler, setUI, setVerifyInputWhenFocusTarget, setVisible, unregisterKeyboardAction, update

Methods inherited from class java.awt.Container

add, add, add, add, add, addContainerListener, addImpl, addPropertyChangeListener, addPropertyChangeListener, applyComponentOrientation, areFocusTraversalKeysSet, countComponents, deliverEvent, doLayout, findComponentAt, findComponentAt, getComponent, getComponentAt, getComponentAt, getComponentCount, getComponents, getComponentZOrder, getContainerListeners, getFocusTraversalKeys, getFocusTraversalPolicy, getLayout, getMousePosition, insets, invalidate, isAncestorOf, isFocusCycleRoot, isFocusCycleRoot, isFocusTraversalPolicyProvider, isFocusTraversalPolicySet, layout, list, list, locate, minimumSize, paintComponents, preferredSize, printComponents, processContainerEvent, processEvent, remove, remove, removeAll, removeContainerListener, setComponentZOrder, setFocusCycleRoot, setFocusTraversalPolicy, setFocusTraversalPolicyProvider, setLayout, transferFocusBackward, transferFocusDownCycle, validate, validateTree

Methods inherited from class java.awt.Component

action, add, addComponentListener, addFocusListener, addHierarchyBoundsListener, addHierarchyListener, addInputMethodListener, addKeyListener, addMouseListener, addMouseMotionListener, addMouseWheelListener, bounds, checkImage, checkImage, coalesceEvents, contains, createImage, createImage, createVolatileImage, createVolatileImage, disableEvents, dispatchEvent, enable, enableEvents, enableInputMethods, firePropertyChange, firePropertyChange, firePropertyChange, firePropertyChange, firePropertyChange, firePropertyChange, getBackground, getBounds, getColorModel, getComponentListeners, getComponentOrientation, getCursor, getDropTarget, getFocusCycleRootAncestor, getFocusListeners, getFocusTraversalKeysEnabled, getFont, getForeground, getGraphicsConfiguration, getHierarchyBoundsListeners, getHierarchyListeners, getIgnoreRepaint, getInputContext, getInputMethodListeners, getInputMethodRequests, getKeyListeners, getLocale, getLocation, getLocationOnScreen, getMouseListeners, getMouseMotionListeners, getMousePosition, getMouseWheelListeners, getName, getParent, getPeer, getPropertyChangeListeners, getPropertyChangeListeners, getSize, getToolkit, getTreeLock, gotFocus, handleEvent, hasFocus, hide, imageUpdate, inside, isBackgroundSet, isCursorSet, isDisplayable, isEnabled, isFocusable, isFocusOwner, isFocusTraversable, isFontSet, isForegroundSet, isLightweight, isMaximumSizeSet, isMinimumSizeSet, isPreferredSizeSet, isShowing, isValid, isVisible, keyDown, keyUp, list, list, list, location, lostFocus, mouseDown, mouseDrag, mouseEnter, mouseExit, mouseMove, mouseUp, move, nextFocus, paintAll, postEvent, prepareImage, prepareImage, processComponentEvent, processFocusEvent, processHierarchyBoundsEvent, processHierarchyEvent, processInputMethodEvent, processMouseWheelEvent, remove, removeComponentListener, removeFocusListener, removeHierarchyBoundsListener, removeHierarchyListener, removeInputMethodListener, removeKeyListener, removeMouseListener, removeMouseMotionListener, removeMouseWheelListener, removePropertyChangeListener, removePropertyChangeListener, repaint, repaint, repaint, resize, resize, setBounds, setBounds, setComponentOrientation, setCursor, setDropTarget, setFocusable, setFocusTraversalKeysEnabled, setIgnoreRepaint, setLocale, setLocation, setLocation, setName, setSize, setSize, show, show, size, toString, transferFocus, transferFocusUpCycle

Methods inherited from class java.lang.Object

clone, equals, finalize, getClass, hashCode, notify, notifyAll, wait, wait, wait

Field Detail

LOCK_IN_USE

public static final java.awt.Color LOCK_IN_USE

LOCK_DONT_USE

public static final java.awt.Color LOCK_DONT_USE

LOCK_OKAY_TO_USE

public static final java.awt.Color LOCK_OKAY_TO_USE

scrollDown

public java.lang.Runnable scrollDown

Constructor Detail

LogPane

public LogPane(int w,
               int h,
               java.lang.String ipString)

Create a LogPane of a specified size with a specified String supplying the IP address of the server. The same IP address is used for the remainder of the life of this LogPane.

Parameters:

w - width, in pixels, of the GUI pane

h - height, in pixels, of the GUI pane

ipString - IP address String of the server that the GUI is connected to

LogPane

public LogPane(int w,
               int h,
               javax.swing.JTextField ipField)

Create a LogPane of a specified size with a specified JTextField supplying the IP address of the server. The JTextField is read before each get/set of the server to facilitate GUIs that can dynamically change the servers to which they are attached.

Parameters:

w - width, in pixels, of the GUI pane

h - height, in pixels, of the GUI pane

ipField - JTextField containing the IP address of the server that the GUI is connected to. When this constructor is used, LogPane will fetch the IP from the field before each server access so that, if the GUI changes servers, LogPane will access the correct one.

Method Detail

paintComponent

public void paintComponent(java.awt.Graphics g)

Overrides:

paintComponent in class javax.swing.JComponent

addMessage

public void addMessage(java.lang.String message)

refresh

public void refresh()

Refresh. This is the public method used to refresh the log pane. If LogPane is not added to the RefreshPanel or ServerPanel list of ActionListeners, then this method should be called explicitly whenever the GUI itelf is being refreshed.

windowActivated

public void windowActivated(java.awt.event.WindowEvent e)

Specified by:

windowActivated in interface java.awt.event.WindowListener

windowClosed

public void windowClosed(java.awt.event.WindowEvent e)

Specified by:

windowClosed in interface java.awt.event.WindowListener

windowClosing

public void windowClosing(java.awt.event.WindowEvent e)

Specified by:

windowClosing in interface java.awt.event.WindowListener

windowDeactivated

public void windowDeactivated(java.awt.event.WindowEvent e)

Specified by:

windowDeactivated in interface java.awt.event.WindowListener

windowDeiconified

public void windowDeiconified(java.awt.event.WindowEvent e)

Specified by:

windowDeiconified in interface java.awt.event.WindowListener

windowIconified

public void windowIconified(java.awt.event.WindowEvent e)

Specified by:

windowIconified in interface java.awt.event.WindowListener

windowOpened

public void windowOpened(java.awt.event.WindowEvent e)

Specified by:

windowOpened in interface java.awt.event.WindowListener

addNotify

public void addNotify()

Overrides:

addNotify in class javax.swing.JComponent

removeNotify

public void removeNotify()

Overrides:

removeNotify in class javax.swing.JComponent

actionPerformed

public void actionPerformed(java.awt.event.ActionEvent e)

Specified by:

actionPerformed in interface java.awt.event.ActionListener
