  4 The 2D Fourier Transform


  • Adopt the representation of Bracewell:

  • Angular coordinates x,y (radians) are in a tangent plane relative to the phase center, thus spatial frequency coordinates u,v are in units of wavelengths

  • The Fourier shift theorem describes how to relate observations with one phase center relative to another:

  • A multiplication in one domain is a convolution in the other:
