Per-ORB TAO Connector Registry. More...
#include <Connector_Registry.h>
Public Member Functions | |
| TAO_Connector_Registry (void) | |
| Default constructor. | |
| ~TAO_Connector_Registry (void) | |
| Default destructor. | |
| TAO_Connector * | get_connector (CORBA::ULong tag) const |
| Return the connector bridges. | |
| int | open (TAO_ORB_Core *orb_core) |
| Initialize all registered connectors. | |
| int | close_all (void) |
| Close all open connectors. | |
| int | make_mprofile (const char *ior, TAO_MProfile &mprofile) |
| TAO_Profile * | create_profile (TAO_InputCDR &cdr) |
| Create a profile based on the contents of cdr. | |
| char | object_key_delimiter (const char *ior) |
| TAO_ConnectorSetIterator | begin (void) const |
| TAO_ConnectorSetIterator | end (void) const |
Private Member Functions | |
| TAO_Connector_Registry (const TAO_Connector_Registry &) | |
| void | operator= (const TAO_Connector_Registry &) |
Private Attributes | |
| TAO_Connector ** | connectors_ |
| List of connectors that are currently open. | |
| size_t | size_ |
| Number of connectors that are currently open. | |
Per-ORB TAO Connector Registry.
Connector Registry and Generic Connector interface definitions. All loaded ESIOP or GIOP connector bridges must register with this object. This class is able to dynamically load a set of concrete protocol connectors which have registered with the service configurator and added their Factory name to the Resource_Factory line of the svc.conf file.
Definition at line 52 of file Connector_Registry.h.
| TAO_Connector_Registry::TAO_Connector_Registry | ( | void | ) |
Default constructor.
Definition at line 25 of file Connector_Registry.cpp.
: connectors_ (0), size_ (0) { }
| TAO_Connector_Registry::~TAO_Connector_Registry | ( | void | ) |
Default destructor.
Definition at line 31 of file Connector_Registry.cpp.
{
this->close_all ();
delete [] this->connectors_;
}
| TAO_Connector_Registry::TAO_Connector_Registry | ( | const TAO_Connector_Registry & | ) | [private] |
| TAO_ConnectorSetIterator TAO_Connector_Registry::begin | ( | void | ) | const |
Definition at line 8 of file Connector_Registry.inl.
{
return this->connectors_;
}
| int TAO_Connector_Registry::close_all | ( | void | ) |
Close all open connectors.
Definition at line 100 of file Connector_Registry.cpp.
{
const TAO_ConnectorSetIterator end = this->end ();
for (TAO_ConnectorSetIterator i = this->begin ();
i != end;
++i)
{
if (*i == 0)
continue;
(*i)->close ();
delete *i;
}
this->size_ = 0;
return 0;
}
| TAO_Profile * TAO_Connector_Registry::create_profile | ( | TAO_InputCDR & | cdr | ) |
Create a profile based on the contents of cdr.
Definition at line 170 of file Connector_Registry.cpp.
{
CORBA::ULong tag = 0;
// If there is an error we abort.
if ((cdr >> tag) == 0)
return 0;
TAO_Connector *connector =
this->get_connector (tag);
if (connector == 0)
{
if (TAO_debug_level > 0)
{
ACE_DEBUG ((LM_DEBUG,
ACE_TEXT ("TAO (%P|%t) - TAO_Connector_Registry::")
ACE_TEXT ("create_profile: Unknown profile tag 0x%x\n"),
tag));
}
TAO_ORB_Core *orb_core = cdr.orb_core ();
if (orb_core == 0)
{
orb_core = TAO_ORB_Core_instance ();
if (TAO_debug_level > 0)
{
ACE_DEBUG ((LM_WARNING,
ACE_TEXT ("TAO (%P|%t) - TAO_Connector_Registry")
ACE_TEXT ("::create_profile: ")
ACE_TEXT ("WARNING: extracting object from ")
ACE_TEXT ("default ORB_Core\n")));
}
}
TAO_Profile *pfile = 0;
ACE_NEW_RETURN (pfile,
TAO_Unknown_Profile (tag,
orb_core),
0);
if (pfile->decode (cdr) == -1)
{
pfile->_decr_refcnt ();
pfile = 0;
}
return pfile;
}
// OK, we've got a known profile. It's going to be encapsulated
// ProfileData. Create a new decoding stream and context for it,
// and skip the data in the parent stream
// ProfileData is encoded as a sequence of octet. So first get the
// length of the sequence.
CORBA::ULong encap_len = 0;
if ((cdr >> encap_len) == 0)
return 0;
// Create the decoding stream from the encapsulation in the buffer,
// and skip the encapsulation.
TAO_InputCDR str (cdr, encap_len);
if (str.good_bit () == 0
|| cdr.skip_bytes (encap_len) == 0)
return 0;
return connector->create_profile (str);
}
| TAO_ConnectorSetIterator TAO_Connector_Registry::end | ( | void | ) | const |
Definition at line 14 of file Connector_Registry.inl.
{
return this->connectors_ + this->size_;
}
| TAO_Connector * TAO_Connector_Registry::get_connector | ( | CORBA::ULong | tag | ) | const |
Return the connector bridges.
Definition at line 39 of file Connector_Registry.cpp.
{
const TAO_ConnectorSetIterator end = this->end ();
for (TAO_ConnectorSetIterator connector = this->begin ();
connector != end;
++connector)
{
if ((*connector)->tag () == tag)
return *connector;
}
return 0;
}
| int TAO_Connector_Registry::make_mprofile | ( | const char * | ior, | |
| TAO_MProfile & | mprofile | |||
| ) |
Parse a string containing a URL style IOR and return an MProfile.
Definition at line 122 of file Connector_Registry.cpp.
{
if (!ior)
// Failure: Null IOR string pointer
throw ::CORBA::INV_OBJREF (
CORBA::SystemException::_tao_minor_code (
0,
EINVAL),
CORBA::COMPLETED_NO);
const TAO_ConnectorSetIterator first_connector = this->begin ();
const TAO_ConnectorSetIterator last_connector = this->end ();
for (TAO_ConnectorSetIterator connector = first_connector;
connector != last_connector;
++connector)
{
if (*connector)
{
const int mp_result =
(*connector)->make_mprofile (ior,
mprofile
);
if (mp_result == 0)
return 0; // Success
}
else
// Failure: Null pointer to connector in connector registry.
throw ::CORBA::INV_OBJREF (
CORBA::SystemException::_tao_minor_code (
0,
EINVAL),
CORBA::COMPLETED_NO);
}
// Failure: None of the connectors were able to parse the URL style
// IOR into an MProfile.
throw ::CORBA::INV_OBJREF (
CORBA::SystemException::_tao_minor_code (
TAO_CONNECTOR_REGISTRY_NO_USABLE_PROTOCOL,
0),
CORBA::COMPLETED_NO);
}
| char TAO_Connector_Registry::object_key_delimiter | ( | const char * | ior | ) |
Obtain the object key delimiter used by the protocol specified in the provided URL style IOR.
Definition at line 242 of file Connector_Registry.cpp.
{
if (!ior)
{
errno = EINVAL;
return 0; // Failure: Null IOR string pointer
}
const TAO_ConnectorSetIterator first_connector = this->begin ();
const TAO_ConnectorSetIterator last_connector = this->end ();
for (TAO_ConnectorSetIterator connector = first_connector;
connector != last_connector;
++connector)
{
if (*connector)
{
if ((*connector)->check_prefix (ior) == 0)
return (*connector)->object_key_delimiter ();
}
}
// Failure: None of the connectors were able to match their protocol
// against the provided string.
return 0;
}
| int TAO_Connector_Registry::open | ( | TAO_ORB_Core * | orb_core | ) |
Initialize all registered connectors.
Definition at line 55 of file Connector_Registry.cpp.
{
TAO_ProtocolFactorySet * const pfs =
orb_core->protocol_factories ();
// The array containing the TAO_Connectors will never contain more
// than the number of loaded protocols in the ORB core.
if (this->connectors_ == 0)
ACE_NEW_RETURN (this->connectors_,
TAO_Connector *[pfs->size ()],
-1);
// Open one connector for each loaded protocol!
const TAO_ProtocolFactorySetItor end = pfs->end ();
for (TAO_ProtocolFactorySetItor factory = pfs->begin ();
factory != end;
++factory)
{
auto_ptr <TAO_Connector> connector (
(*factory)->factory ()->make_connector ());
if (connector.get ())
{
if (connector->open (orb_core) != 0)
{
ACE_ERROR_RETURN ((LM_ERROR,
ACE_TEXT ("TAO (%P|%t) - TAO_Connector_Registry")
ACE_TEXT ("::open: unable to open connector for ")
ACE_TEXT ("<%C>.\n"),
(*factory)->protocol_name ().c_str ()),
-1);
}
this->connectors_[this->size_++] =
connector.release ();
}
else
return -1;
}
return 0;
}
| void TAO_Connector_Registry::operator= | ( | const TAO_Connector_Registry & | ) | [private] |
TAO_Connector** TAO_Connector_Registry::connectors_ [private] |
List of connectors that are currently open.
Definition at line 94 of file Connector_Registry.h.
size_t TAO_Connector_Registry::size_ [private] |
Number of connectors that are currently open.
Definition at line 97 of file Connector_Registry.h.
