ACE_Shared_Memory_SV Class Reference

Shared memory wrapper based on System V shared memory. More...

#include <Shared_Memory_SV.h>

Inheritance diagram for ACE_Shared_Memory_SV:

Collaboration diagram for ACE_Shared_Memory_SV:

List of all members.

Public Types
enum	{ ACE_CREATE = IPC_CREAT, ACE_OPEN = 0 }
Public Member Functions
	ACE_Shared_Memory_SV (void)
	ACE_Shared_Memory_SV (key_t id, size_t length, int create=ACE_Shared_Memory_SV::ACE_OPEN, int perms=ACE_DEFAULT_FILE_PERMS, void *addr=0, int flags=0)
int	open (key_t id, size_t length, int create=ACE_Shared_Memory_SV::ACE_OPEN, int perms=ACE_DEFAULT_FILE_PERMS, void *addr=0, int flags=0)
virtual int	close (void)
	Close down the shared memory segment.
virtual int	remove (void)
	Remove the underlying shared memory segment.
virtual void *	malloc (size_t=0)
	Create a new chuck of memory containing size bytes.
virtual int	free (void *p)
	Free a chuck of memory allocated by <ACE_Shared_Memory_SV::malloc>.
virtual size_t	get_segment_size (void) const
	Return the size of the shared memory segment.
virtual ACE_HANDLE	get_id (void) const
void	dump (void) const
	Dump the state of an object.
Public Attributes
	ACE_ALLOC_HOOK_DECLARE
	Declare the dynamic allocation hooks.
Private Attributes
ACE_SV_Shared_Memory	shared_memory_

---

Detailed Description

Shared memory wrapper based on System V shared memory.

This class provides a very simple-minded shared memory manager. We strongly recommend that you do NOT use this class. Instead, please use ACE_Malloc, which has much more powerful capabilities.

Definition at line 37 of file Shared_Memory_SV.h.

---

Member Enumeration Documentation

anonymous enum

Enumerator:

ACE_CREATE
ACE_OPEN

Definition at line 40 of file Shared_Memory_SV.h.

    {
      ACE_CREATE = IPC_CREAT,
      ACE_OPEN = 0
    };

---

Constructor & Destructor Documentation

ACE_Shared_Memory_SV::ACE_Shared_Memory_SV

(

void

)

Definition at line 25 of file Shared_Memory_SV.inl.

{
  ACE_TRACE ("ACE_Shared_Memory_SV::ACE_Shared_Memory_SV");
}

ACE_Shared_Memory_SV::ACE_Shared_Memory_SV	(	key_t	id,
		size_t	length,
		int	create = ACE_Shared_Memory_SV::ACE_OPEN,
		int	perms = ACE_DEFAULT_FILE_PERMS,
		void *	addr = 0,
		int	flags = 0
	)

Definition at line 27 of file Shared_Memory_SV.cpp.

  : shared_memory_ (id, length, create, perms, addr, flags)
{
  ACE_TRACE ("ACE_Shared_Memory_SV::ACE_Shared_Memory_SV");
}

---

Member Function Documentation

int ACE_Shared_Memory_SV::close

(

void

)

[virtual]

Close down the shared memory segment.

Implements ACE_Shared_Memory.

Definition at line 61 of file Shared_Memory_SV.cpp.

{
  ACE_TRACE ("ACE_Shared_Memory_SV::close");
  return shared_memory_.detach ();
}

void ACE_Shared_Memory_SV::dump

(

void

)

const

Dump the state of an object.

int ACE_Shared_Memory_SV::free

(

void *

p

)

[virtual]

Free a chuck of memory allocated by <ACE_Shared_Memory_SV::malloc>.

Implements ACE_Shared_Memory.

Definition at line 82 of file Shared_Memory_SV.cpp.

{
  ACE_TRACE ("ACE_Shared_Memory_SV::free");
  return p != 0;
}

ACE_HANDLE ACE_Shared_Memory_SV::get_id

(

void

)

const [virtual]

Return the ID of the shared memory segment (i.e., a System V shared memory internal id).

Implements ACE_Shared_Memory.

Definition at line 75 of file Shared_Memory_SV.cpp.

{
  ACE_TRACE ("ACE_Shared_Memory_SV::get_id");
  return this->shared_memory_.get_id ();
}

size_t ACE_Shared_Memory_SV::get_segment_size

(

void

)

const [virtual]

Return the size of the shared memory segment.

Implements ACE_Shared_Memory.

Definition at line 41 of file Shared_Memory_SV.cpp.

{
  ACE_TRACE ("ACE_Shared_Memory_SV::get_segment_size");
  // This cast is ok since the 'open' method for this class allows only
  // an 'int' size. Therefore, this case should not lose information.
  return this->shared_memory_.get_segment_size ();
}

void * ACE_Shared_Memory_SV::malloc

(

size_t

= 0

)

[virtual]

Create a new chuck of memory containing size bytes.

Implements ACE_Shared_Memory.

Definition at line 68 of file Shared_Memory_SV.cpp.

{
  ACE_TRACE ("ACE_Shared_Memory_SV::malloc");
  return this->shared_memory_.get_segment_ptr ();
}

int ACE_Shared_Memory_SV::open	(	key_t	id,
		size_t	length,
		int	create = ACE_Shared_Memory_SV::ACE_OPEN,
		int	perms = ACE_DEFAULT_FILE_PERMS,
		void *	addr = 0,
		int	flags = 0
	)

Definition at line 10 of file Shared_Memory_SV.inl.

{
  ACE_TRACE ("ACE_Shared_Memory_SV::open");
  return shared_memory_.open_and_attach (id, length, create,
                                         perms, addr, flags);
}

int ACE_Shared_Memory_SV::remove

(

void

)

[virtual]

Remove the underlying shared memory segment.

Implements ACE_Shared_Memory.

Definition at line 52 of file Shared_Memory_SV.cpp.

{
  ACE_TRACE ("ACE_Shared_Memory_SV::remove");
  return shared_memory_.remove ();
}

---

Member Data Documentation

ACE_Shared_Memory_SV::ACE_ALLOC_HOOK_DECLARE

Declare the dynamic allocation hooks.

Definition at line 86 of file Shared_Memory_SV.h.

ACE_SV_Shared_Memory ACE_Shared_Memory_SV::shared_memory_ [private]

This version is implemented with System V shared memory segments.

Definition at line 91 of file Shared_Memory_SV.h.

---

The documentation for this class was generated from the following files:

• Shared_Memory_SV.h
• Shared_Memory_SV.cpp
• Shared_Memory_SV.inl
