TAO_DynamicInterface: TAO::DII_Invocation

TAO::DII_Invocation_Adapter::DII_Invocation_Adapter	(	CORBA::Object *	target,
		Argument **	args,
		int	arg_number,
		const char *	operation,
		size_t	op_len,
		CORBA::ExceptionList *	exception,
		CORBA::Request *	r,
		Invocation_Mode	mode = `TAO_DII_INVOCATION`
	)

Parameters:

	target	Points to the object on which this invocation is being invoked.
	args	Array of pointers to the argument list in the operation declaration. this includes the return, inout and out arguments.
	arg_number	Number of arguments in the above array. This is the number of elements in the above array.
	operation	The name of the operation being invoked.
	op_len	Number of characters in the operation name. This is an optimization which helps us to avoid calling strlen () while creating a message format.
	mode	Invocation mode. This information is also available in the IDL file and in the generated code.

Definition at line 30 of file DII_Invocation_Adapter.cpp.

00039     : Invocation_Adapter (target,
00040                           args,
00041                           arg_number,
00042                           operation,
00043                           op_len,
00044                           0, // Collocation Proxy broker pointer
00045                           TAO_TWOWAY_INVOCATION,
00046                           mode)
00047       , exception_list_ (excp)
00048       , request_ (r)
00049       , ex_data_ (0)
00050   {
00051   }

TAO::DII_Invocation_Adapter::~DII_Invocation_Adapter ( void ) [virtual]

Definition at line 53 of file DII_Invocation_Adapter.cpp.

References ex_data_.

00054   {
00055     delete[] ex_data_;
00056   }

TAO::DII_Invocation_Adapter::DII_Invocation_Adapter ( void ) [private]

Dont allow default initializations.

TAO::DII_Invocation_Adapter::DII_Invocation_Adapter ( const DII_Invocation_Adapter & ) [private]

void TAO::DII_Invocation_Adapter::invoke	(	TAO::Exception_Data *	ex,
		unsigned long	ex_count
	)			`[virtual]`

Invoke the target.

Reimplemented from TAO::Invocation_Adapter.

Definition at line 59 of file DII_Invocation_Adapter.cpp.

References ACE_NEW_THROW_EX, CORBA::ExceptionList::count(), ex_data_, and exception_list_.

00061   {
00062     // Convert DII exception list to a form the invocation can use
00063     // to filter raised user exceptions.
00064     ex_count = this->exception_list_->count ();
00065     ACE_NEW_THROW_EX (this->ex_data_,
00066                       TAO::Exception_Data[ex_count],
00067                       CORBA::NO_MEMORY ());
00068     for (unsigned long l=0; l<ex_count ;++l)
00069     {
00070       CORBA::TypeCode_var xtc = this->exception_list_->item (l);
00071       this->ex_data_[l].id = xtc->id ();
00072       this->ex_data_[l].alloc = 0;
00073 #if TAO_HAS_INTERCEPTORS == 1
00074       this->ex_data_[l].tc_ptr = xtc.in ();
00075 #endif
00076     }
00077
00078     Invocation_Adapter::invoke (this->ex_data_, ex_count);
00079   }

Invocation_Status TAO::DII_Invocation_Adapter::invoke_collocated_i	(	TAO_Stub *	stub,
		TAO_Operation_Details &	details,
		CORBA::Object_var &	effective_target,
		Collocation_Strategy	strat
	)			`[protected, virtual]`

Reimplemented from TAO::Invocation_Adapter.

Definition at line 82 of file DII_Invocation_Adapter.cpp.

References TAO_Operation_Details::cac(), and ACE_Dynamic_Service< TYPE >::instance().

00087   {
00088     TAO_DII_Arguments_Converter_Impl* dii_arguments_converter
00089       = ACE_Dynamic_Service<TAO_DII_Arguments_Converter_Impl>::instance (
00090         "DII_Arguments_Converter");
00091     details.cac (dii_arguments_converter);
00092
00093     return Invocation_Adapter::invoke_collocated_i (stub,
00094                                                     details,
00095                                                     effective_target,
00096                                                     strat);
00097   }

Invocation_Status TAO::DII_Invocation_Adapter::invoke_twoway	(	TAO_Operation_Details &	op,
		CORBA::Object_var &	effective_target,
		Profile_Transport_Resolver &	r,
		ACE_Time_Value *&	max_wait_time
	)			`[protected, virtual]`

Reimplemented from TAO::Invocation_Adapter.

Reimplemented in TAO::DII_Asynch_Invocation_Adapter.

Definition at line 100 of file DII_Invocation_Adapter.cpp.

References CORBA::Request::_tao_byte_order(), CORBA::SystemException::_tao_minor_code(), CORBA::COMPLETED_NO, TAO_Transport::messaging_object(), CORBA::OMGVMCID, TAO_GIOP_Message_Base::out_stream(), request_, ACE_OutputCDR::reset_byte_order(), TAO::Profile_Transport_Resolver::stub(), TAO::TAO_DII_INVOCATION, TAO::TAO_INVOKE_RESTART, TAO::TAO_TWOWAY_INVOCATION, TAO::Profile_Transport_Resolver::transport(), and TAO::VMCID.

00105   {
00106     // Simple sanity check
00107     if (this->mode_ != TAO_DII_INVOCATION ||
00108         this->type_ != TAO_TWOWAY_INVOCATION)
00109       {
00110         throw ::CORBA::INTERNAL (
00111           CORBA::SystemException::_tao_minor_code (
00112             TAO::VMCID,
00113             EINVAL),
00114           CORBA::COMPLETED_NO);
00115       }
00116
00117     TAO_Transport* const transport = r.transport ();
00118
00119     if (!transport)
00120       {
00121         // Way back, we failed to find a profile we could connect to.
00122         // We've come this far only so we reach the interception points
00123         // in case they can fix things. Time to bail....
00124         throw CORBA::TRANSIENT (CORBA::OMGVMCID | 2, CORBA::COMPLETED_NO);
00125       }
00126
00127     transport->messaging_object ()->out_stream ().reset_byte_order (
00128         request_->_tao_byte_order ());
00129
00130     TAO::DII_Invocation synch (this->target_,
00131                                r,
00132                                op,
00133                                this->exception_list_,
00134                                this->request_);
00135
00136
00137     Invocation_Status status = synch.remote_invocation (max_wait_time);
00138
00139     if (status == TAO_INVOKE_RESTART &&
00140         (synch.reply_status () == GIOP::LOCATION_FORWARD ||
00141          synch.reply_status () == GIOP::LOCATION_FORWARD_PERM))
00142       {
00143         CORBA::Boolean const permanent_forward =
00144           (synch.reply_status () == GIOP::LOCATION_FORWARD_PERM);
00145
00146         effective_target = synch.steal_forwarded_reference ();
00147
00148         this->object_forwarded (effective_target,
00149                                 r.stub (),
00150                                 permanent_forward);
00151       }
00152     return status;
00153   }

DII_Invocation_Adapter& TAO::DII_Invocation_Adapter::operator= ( const DII_Invocation_Adapter & ) [private]

TAO::Exception_Data* TAO::DII_Invocation_Adapter::ex_data_ [private]

Definition at line 119 of file DII_Invocation_Adapter.h.

Referenced by invoke(), and ~DII_Invocation_Adapter().

CORBA::ExceptionList* TAO::DII_Invocation_Adapter::exception_list_ [private]

Definition at line 115 of file DII_Invocation_Adapter.h.

Referenced by invoke().

CORBA::Request* TAO::DII_Invocation_Adapter::request_ [private]

Definition at line 117 of file DII_Invocation_Adapter.h.

Referenced by invoke_twoway().


Public Member Functions
	DII_Invocation_Adapter (CORBA::Object target, Argument args, int arg_number, const char operation, size_t op_len, CORBA::ExceptionList exception, CORBA::Request r, Invocation_Mode mode=TAO_DII_INVOCATION)
virtual	~DII_Invocation_Adapter (void)
virtual void	invoke (TAO::Exception_Data *ex, unsigned long ex_count)
	Invoke the target.
Protected Member Functions
virtual Invocation_Status	invoke_twoway (TAO_Operation_Details &op, CORBA::Object_var &effective_target, Profile_Transport_Resolver &r, ACE_Time_Value *&max_wait_time)
virtual Invocation_Status	invoke_collocated_i (TAO_Stub *stub, TAO_Operation_Details &details, CORBA::Object_var &effective_target, Collocation_Strategy strat)
Private Member Functions
	DII_Invocation_Adapter (void)
	Dont allow default initializations.
	DII_Invocation_Adapter (const DII_Invocation_Adapter &)
DII_Invocation_Adapter &	operator= (const DII_Invocation_Adapter &)
Private Attributes
CORBA::ExceptionList *	exception_list_
CORBA::Request *	request_
TAO::Exception_Data *	ex_data_

TAO::DII_Invocation_Adapter Class Reference

Public Member Functions

Protected Member Functions

Private Member Functions

Private Attributes

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation
