TAO: orbconf.h File Reference

Policies that are accessed on the critical path and need to be incur minimal retrieval overhead.

00709 {
00710   TAO_CACHED_POLICY_UNCACHED = -1,
00711   TAO_CACHED_POLICY_PRIORITY_MODEL = 0,
00712   TAO_CACHED_POLICY_THREADPOOL,
00713   TAO_CACHED_POLICY_RT_SERVER_PROTOCOL,
00714   TAO_CACHED_POLICY_RT_CLIENT_PROTOCOL,
00715   TAO_CACHED_POLICY_RT_PRIVATE_CONNECTION,
00716   TAO_CACHED_POLICY_RT_PRIORITY_BANDED_CONNECTION,
00717
00718   TAO_CACHED_POLICY_LIFESPAN,
00719   TAO_CACHED_POLICY_ID_UNIQUENESS,
00720   TAO_CACHED_POLICY_ID_ASSIGNMENT,
00721
00722 #if (TAO_HAS_MINIMUM_POA == 0)
00723   TAO_CACHED_POLICY_THREAD,
00724   TAO_CACHED_POLICY_IMPLICIT_ACTIVATION,
00725   TAO_CACHED_POLICY_SERVANT_RETENTION,
00726   TAO_CACHED_POLICY_REQUEST_PROCESSING,
00727 #endif /* TAO_HAS_MINIMUM_POA == 0 */
00728
00729 #if (TAO_HAS_SYNC_SCOPE_POLICY == 1)
00730   TAO_CACHED_POLICY_SYNC_SCOPE,
00731 #endif /* TAO_HAS_SYNC_SCOPE_POLICY == 1 */
00732
00733 #if (TAO_HAS_RELATIVE_ROUNDTRIP_TIMEOUT_POLICY == 1)
00734   TAO_CACHED_POLICY_RELATIVE_ROUNDTRIP_TIMEOUT,
00735 #endif /* TAO_HAS_RELATIVE_ROUNDTRIP_TIMEOUT_POLICY == 1 */
00736
00737 #if (TAO_HAS_BUFFERING_CONSTRAINT_POLICY == 1)
00738   TAO_CACHED_POLICY_BUFFERING_CONSTRAINT,
00739 #endif /* TAO_HAS_BUFFERING_CONSTRAINT_POLICY == 1 */
00740
00741 #if (TAO_HAS_CONNECTION_TIMEOUT_POLICY == 1)
00742   TAO_CACHED_POLICY_CONNECTION_TIMEOUT,
00743 #endif /* TAO_HAS_CONNECTION_TIMEOUT_POLICY == 1 */
00744
00745   TAO_CACHED_POLICY_BIDIRECTIONAL_GIOP,
00746
00747   TAO_CACHED_POLICY_SERVER_NETWORK_PRIORITY,
00748
00749   TAO_CACHED_POLICY_CLIENT_NETWORK_PRIORITY,
00750
00751   TAO_CACHED_POLICY_NETWORK_PRIORITY,
00752
00753   TAO_CACHED_POLICY_ENDPOINT,
00754
00755   /// NOTE: The "TAO_CACHED_POLICY_MAX_CACHED" should always be the last.
00756   ///       This value is used as the cached_policies_ array size in TAO_Policy_Set,
00757   ///       Any policy type defined after "TAO_CACHED_POLICY_MAX_CACHED" will cause
00758   ///       the policy access beyond bound problem.
00759   TAO_CACHED_POLICY_MAX_CACHED
00760 };
00761


Defines
#define	TAO_INVALID_PRIORITY -1
#define	TAO_REACTOR ACE_Select_Reactor
#define	TAO_NULL_LOCK_REACTOR ACE_Select_Reactor_T< ACE_Reactor_Token_T<ACE_Noop_Token> >
#define	TAO_SYNCH_MUTEX ACE_SYNCH_MUTEX
#define	TAO_SYNCH_RECURSIVE_MUTEX ACE_SYNCH_RECURSIVE_MUTEX
#define	TAO_SYNCH_RW_MUTEX ACE_SYNCH_RW_MUTEX
#define	TAO_SYNCH_CONDITION ACE_SYNCH_CONDITION
#define	POA_NO_TIMESTAMP 0
#define	TAO_USE_DOTTED_DECIMAL_ADDRESSES 1
#define	TAO_NEGOTIATE_CODESETS 1
#define	TAO_DEFAULT_SERVER_ACTIVE_OBJECT_MAP_SIZE 64
#define	TAO_DEFAULT_SERVER_POA_MAP_SIZE 24
#define	TAO_DEFAULT_SERVICE_RESOLUTION_TIMEOUT 10
#define	TAO_DEFAULT_SERVER_PORT 0
#define	TAO_MAXBUFSIZE 1024
#define	TAO_CONNECTION_PURGING_STRATEGY TAO_Resource_Factory::LRU
#define	TAO_PURGE_PERCENT 20
#define	TAO_CONNECTION_CACHE_MAXIMUM (ACE::max_handles () / 2)
#define	TAO_NAMESPACE_STORAGE_CLASS extern TAO_EXPORT_MACRO
#define	TAO_NAMESPACE_INLINE_FUNCTION TAO_NAMESPACE_STORAGE_CLASS
#define	TAO_NO_COPY_OCTET_SEQUENCES 1
#define	TAO_HAS_EXCEPTIONS
#define	TAO_ENCAP_BYTE_ORDER
#define	RETSIGTYPE void
#define	HAVE_VPRINTF 1
#define	TAO_EXPORT_NESTED_MACRO
#define	TAO_DEFAULT_ROOTPOA_NAME "RootPOA"
#define	TAO_DEFAULT_ROOTPOAMANAGER_NAME "RootPOAManager"
#define	TAO_DEFAULT_LANE "default lane"
#define	TAO_HAS_IIOP 1
	Default IIOP settings.
#define	TAO_HAS_DIOP 1
	Default DIOP settings.
#define	TAO_HAS_UIOP 1
#define	TAO_HAS_SHMIOP 1
#define	TAO_HAS_NAMED_RT_MUTEXES 0
#define	TAO_HAS_MINIMUM_POA 0
#define	TAO_HAS_MINIMUM_POA_MAPS 0
#define	TAO_HAS_CORBA_MESSAGING 1
#define	TAO_DISABLE_CORBA_MESSAGING_POLICIES 0
#define	TAO_HAS_REBIND_POLICY 1
#define	TAO_HAS_SYNC_SCOPE_POLICY 1
#define	TAO_HAS_PRIORITY_POLICIES 1
#define	TAO_HAS_REQUEST_START_TIME_POLICY 1
#define	TAO_HAS_REQUEST_END_TIME_POLICY 1
#define	TAO_HAS_REPLY_START_TIME_POLICY 1
#define	TAO_HAS_REPLY_END_TIME_POLICY 1
#define	TAO_HAS_RELATIVE_REQUEST_TIMEOUT_POLICY 1
#define	TAO_HAS_RELATIVE_ROUNDTRIP_TIMEOUT_POLICY 1
#define	TAO_HAS_CONNECTION_TIMEOUT_POLICY 1
#define	TAO_HAS_ROUTING_POLICY 1
#define	TAO_HAS_MAX_HOPS_POLICY 1
#define	TAO_HAS_QUEUE_ORDER_POLICY 1
#define	TAO_HAS_BUFFERING_CONSTRAINT_POLICY 1
#define	TAO_HAS_AMI_CALLBACK 1
#define	TAO_HAS_SENDFILE 0
#define	TAO_HAS_EXTENDED_FT_INTERCEPTORS 0
#define	TAO_RT_SERVER_PROTOCOL_POLICY_TYPE 42
#define	TAO_POLICY_DEFAULT_SCOPE
#define	TAO_DEF_GIOP_MAJOR 1
#define	TAO_DEF_GIOP_MINOR 2
#define	TAO_MIN_IPV6_IIOP_MAJOR 1
#define	TAO_MIN_IPV6_IIOP_MINOR 2
#define	TAO_CONNECTION_HANDLER_STACK_BUF_SIZE 1024
#define	TAO_STD_PROFILE_COMPONENTS
#define	TAO_DEFAULT_IOR_SIZE 1024
#define	TAO_DEFAULT_THREAD_PER_CONNECTION_TIMEOUT "5000"
#define	TAO_USE_MUXED_TRANSPORT_MUX_STRATEGY 1
	By default we use Muxed Transports.
#define	TAO_DEFAULT_INIT_REFERENCE_INITIALIZER "mcast://:::"
	By default we use multicast lookup.
#define	TAO_USE_LAZY_RESOURCE_USAGE_STRATEGY 0
	By default we dont use lazy strategy.
#define	TAO_USE_LOCAL_MEMORY_POOL 1
#define	TAO_USE_OUTPUT_CDR_MMAP_MEMORY_POOL 0
#define	TAO_HAS_DDL_PARSER 1
#define	TAO_HAS_FILE_PARSER 1
#define	TAO_HAS_CORBALOC_PARSER 1
#define	TAO_HAS_CORBANAME_PARSER 1
#define	TAO_HAS_HTTP_PARSER 1
#define	TAO_HAS_MCAST_PARSER 1
Enumerations
enum	TAO_Cached_Policy_Type { TAO_CACHED_POLICY_UNCACHED = -1, TAO_CACHED_POLICY_PRIORITY_MODEL = 0, TAO_CACHED_POLICY_THREADPOOL, TAO_CACHED_POLICY_RT_SERVER_PROTOCOL, TAO_CACHED_POLICY_RT_CLIENT_PROTOCOL, TAO_CACHED_POLICY_RT_PRIVATE_CONNECTION, TAO_CACHED_POLICY_RT_PRIORITY_BANDED_CONNECTION, TAO_CACHED_POLICY_LIFESPAN, TAO_CACHED_POLICY_ID_UNIQUENESS, TAO_CACHED_POLICY_ID_ASSIGNMENT, TAO_CACHED_POLICY_THREAD, TAO_CACHED_POLICY_IMPLICIT_ACTIVATION, TAO_CACHED_POLICY_SERVANT_RETENTION, TAO_CACHED_POLICY_REQUEST_PROCESSING, TAO_CACHED_POLICY_SYNC_SCOPE, TAO_CACHED_POLICY_RELATIVE_ROUNDTRIP_TIMEOUT, TAO_CACHED_POLICY_BUFFERING_CONSTRAINT, TAO_CACHED_POLICY_CONNECTION_TIMEOUT, TAO_CACHED_POLICY_BIDIRECTIONAL_GIOP, TAO_CACHED_POLICY_SERVER_NETWORK_PRIORITY, TAO_CACHED_POLICY_CLIENT_NETWORK_PRIORITY, TAO_CACHED_POLICY_NETWORK_PRIORITY, TAO_CACHED_POLICY_ENDPOINT, TAO_CACHED_POLICY_MAX_CACHED }
enum	TAO_Policy_Scope { TAO_POLICY_OBJECT_SCOPE = 0x01, TAO_POLICY_THREAD_SCOPE = 0x02, TAO_POLICY_ORB_SCOPE = 0x04, TAO_POLICY_POA_SCOPE = 0x08, TAO_POLICY_CLIENT_EXPOSED = 0x10 }
Variables
const size_t	TAO_DEFAULT_ORB_TABLE_SIZE = 16
const size_t	TAO_DEFAULT_ADAPTER_REGISTRY_SIZE = 16
const size_t	TAO_RD_TABLE_SIZE = 16
const size_t	TAO_DEFAULT_POLICY_FACTORY_REGISTRY_SIZE = 64
const size_t	TAO_DEFAULT_OBJECT_REF_TABLE_SIZE = 256
const size_t	TAO_DEFAULT_VALUE_FACTORY_TABLE_SIZE = 128
